- Page 1 47" ROTARY BROOM - BX2537A BX2737- Lawn Dethatching Wheel Kit BX2761 –Hydraulic Angling Kit For BX Series Tractors SERIAL NO. 2406576 AND UP OM 0287BR-AU 05/04 MANUAL PART NUMBER 70060-02212...
-
Page 3: Table Of Contents
TABLE OF CONTENT INTRODUCTION – TO THE PURCHASER ....................3 SAFETY PRECAUTIONS ..........................4 Before Operation ..........................4 Notice ..............................5 Subframe & Rotary Broom........................5 Before Operation ........................5 Rotary Broom & Subframe Operation................6 Maintenance............................8 Storage..............................9 DECALS ..............................10 ASSEMBLY..............................11 Rotary Broom Assembly.........................11 Parking Stand ........................11 Limit Stops Installation .....................11 Rotary Broom Installation .......................12 Attaching Rotary Broom to Tractor ..................12... - Page 4 TABLE OF CONTENT PARTS..............................22 Introduction .............................22 Rotary Broom Assembly – BX2537A.....................23 Female Driveline (70060-01976)....................26 Gearbox (70060-01973) .........................27 Hydraulic Angling Kit – BX2761 (Option) ..................28 Lawn Dethatching Wheel Kit – BX2737 (Option) ................29 AVAILABLE OPTIONS ..........................30 AVAILABLE EQUIPMENT ........................31 TORQUE SPECIFICATION TABLE ......................32...
-
Page 5: Introduction - To The Purchaser
INTRODUCTION Illustrations O THE URCHASER The illustrations may not necessarily reproduce All products are designed to give safe, the full detail and the exact shape of the parts dependable service if they are operated and or depict the actual models, but are intended maintained according to instructions. -
Page 6: Before Operation
SAFETY PRECAUTIONS SAFETY FIRST This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use this rotary broom. -
Page 7: Notice
SAFETY PRECAUTIONS - continued OTICE A safe operator is the best assurance against accidents. All operators, no matter how experienced they may be, should read this operator's manual and all other related manuals before attempting to operate the rotary broom. Please read the following section and pay particular attention to all safety recommendations contained in this manual and those labeled on the rotary broom and on the tractor. -
Page 8: Rotary Broom & Subframe Operation
SAFETY PRECAUTIONS - continued Rotary Broom & Subframe Operation 1. Before leaving the tractor unattended, take 10. Do not run the engine indoors except when possible precautions. Park starting engine and transporting attachment tractor/rotary broom on level ground, place in or out of building. Carbon monoxide gas the transmission in neutral, set the parking is colorless, odorless and deadly. - Page 9 SAFETY PRECAUTIONS - continued 20. Never allow anyone to operate the rotary 33. Make sure the tractor is counterweighted broom until they have read the manual as recommended by your dealer. Weights completely and are thoroughly familiar with provide the necessary balance to improve basic tractor and rotary broom operation.
-
Page 10: Maintenance
SAFETY PRECAUTIONS - continued AINTENANCE ALWAYS USE GENUINE PARTS WHEN 10.Do not modify or alter this rotary broom or REPLACEMENT PARTS ARE REQUIRED components operating functions. If you have questions concerning 1. Keep the tractor and rotary broom properly modifications, consult with your dealer. maintained. -
Page 11: Storage
SAFETY PRECAUTIONS - continued TORAGE Before storing the subframe or rotary broom, certain precautions should be taken to protect it from deterioration. Clean subframe rotary broom thoroughly. 1. Make all the necessary repairs. 2. Replace all safety signs that are damaged, lost, or otherwise become illegible. -
Page 12: Decals
DECALS (For KUBOTA USA) Replace immediately if damaged KUBOTA: 70060-01035 (655657) 70060-03897 70060-03763 (660328) (660988) BX2537A 70060- 02104 (2500454) 70060-03076 (658708) 70060-03033 70060-01213 (658710) (657763) OM 0287BR-AU... -
Page 13: Assembly
ASSEMBLY OTARY BROOM SSEMBLY The rotary broom is assembled at the factory, however, parts contained in the bag must be installed. Use the present manual and lay out all parts for assembly. Separate bolts and nuts into various sizes. After assembly, torque all the bolts according to the Torque Specification Table enclosed at the end of the manual. -
Page 14: Rotary Broom Installation
ASSEMBLY OTARY BROOM NSTALLATION Figure 3 WARNING To avoid serious personal injuries: Before getting off the tractor: Park the tractor level ground, place transmission in neutral, set the parking brake, disengage the driving system, lower the nose of the male quick hitch as much as possible, place all levers including auxiliary control levers in neutral, shut off the engine and remove the ignition key. -
Page 15: Hydraulic Angling Kit - Bx2761 (Option)
ASSEMBLY - BX2761 (O YDRAULIC NGLING PTION Installation (figure 4-5) 1. Figure 4: Turn the female hitch fully to the 5. Figure 5: Using thread sealant, attach right and raise the female hitch. Stabilize each hose (item 4) to each cylinder port. with a piece of wood (item 1). - Page 16 ASSEMBLY 8. With the engine stopped, relieve pressure WARNING: avoid serious from hydraulic system by moving the valve personal injury. Escaping hydraulic/ diesel handle in all directions. fluid under pressure can penetrate the skin 9. Identify broom hydraulic h oses to female causing serious injury quick couplers using the identification rings •...
-
Page 17: Lawn Dethatching Wheel Kit - Bx2737 (Option)
ASSEMBLY - BX2737 (O ETHATCHING HEEL PTION Installation (Figure 6) Adjustment To adjust the height of the wheel (1/2" at a 1. Remove the parking stands (item 9) from time, from 3" minimum to 7" maximum) slide the supports (item 1) on each side of the the inner tube upward or downward, as broom. -
Page 18: Operation
OPERATION Brush-to-Ground Contact ENERAL REPARATION (Figure 7) 1. Check drive shaft tightening. This adjustment must be made when the 2. Make sure that the broom operates freely. broom is installed on the tractor. 3. Adjust the lawn dethatching wheels (if IMPORTANT: The pivot lock pin (item 3) installed). -
Page 19: Operation
OPERATION - MAINTENANCE PERATION General Sweeping Starting & Stopping the Rotary Broom IMPORTANT: Always use the float position Refer to tractor operator's manual for the when working with the broom. proper PTO operation. 1. Set the tractor engine RPM between low Snow Removal and mid range depending on the material to sweep. -
Page 20: Lubrication
MAINTENANCE Lubrication Use a grease gun, grease and lubricate as follows: DESCRIPTION TIME INTERVAL LUBRICATION REQUIRED Grease each universal joint 8 hours of operation (see decal #70060-03076) Driveline Separate the sliding parts and cover each one 20 hours of operation of them with grease (see decal #70060-03076 or 70001-00642) Lubricate with chain lubricant... - Page 21 MAINTENANCE Lubrication Use a grease gun, grease and lubricate as follows: DESCRIPTION TIME INTERVAL LUBRICATION REQUIRED Wheel bracket 8 hours of operation Use a good quality multipurpose lubricant Wheel support 8 hours of operation Use a good quality multipurpose lubricant Wheel 8 hours of operation Use a good quality multipurpose lubricant...
-
Page 22: Brush Replacement
MAINTENANCE Brush Replacement (Figure 8) When the brushes reach a diameter of 10", 8. Insert the first brush on the brush support it is necessary to replace them in order to by aligning the guides (item 10) on each maximize the performance of your broom. side of a brush support tube (item 11). -
Page 23: Chain Replacement
MAINTENANCE Chain Replacement Shearbolt Replacement (Figure 10) (Figure 9 &9A) Replace the chain when the distance 1. Remove the broken shearbolt (item 1) by between the spans is reduced to 1 3/4 aligning the hole of the driveline yoke with (see figure 9A) the hole of the gearbox shaft. -
Page 24: Parts
PARTS NTRODUCTION All parts are illustrated in "exploded views" which show the individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Reference Number" (REF) column, and are followed by the description and quantity required. O/L - "Obtain Locally"... -
Page 25: Rotary Broom Assembly - Bx2537A
PARTS – BX2537A OTARY ROOM SSEMBLY OM 0287BR-AU... - Page 26 PARTS – BX2537A OTARY ROOM SSEMBLY ESCRIPTION Housing 70060-01966 666918 Right side plate 70060-01954 666842 Brush support 70060-01953 666640 Retaining plate, brush 70060-01951 665650 Chain guard 70060-01955 666845 Pivot bracket 70060-01957 666852 Female hitch 70060-01958 666855 Upper coupler 70060-03829 661009...
- Page 27 PARTS – BX2537A OTARY ROOM SSEMBLY ESCRIPTION Cotter pin 3/32" x 3/4", PTD Hex. bolt 1/2" NC x 1 3/4" lg., gr. 5, PTD Upper bushing 70060-03278 658528 Pivot bushing 70060-03273 658532 Hex. bolt 7/16" NC X 1 3/4" lg., gr. 5, PTD Hex.
-
Page 28: Female Driveline (70060-01976)
PARTS (70060-01976) EMALE RIVELINE ESCRIPTION Inner Guard 70001-00799 664650 Nylon Repair Kit 70060-04238 661555 C.V. Centre Housing 70060-01670 658514 Cross And Bearing Kit 70060-01020 654478 Yoke Tube And Slip Sleeve 70001-00800 664651 Yoke 70060-02101 4700029 Cat 1, 50° C.V. Repair Kit 70001-00787 663632 OM 0287BR-AU... -
Page 29: Gearbox (70060-01973)
PARTS – (70060-01973) EARBOX ESCRIPTION Casing 70060-04020 661740 Hex. bolt M8 x 1.25 x 45mm 70060-01844 0200098 Hex. nut M8 x 1.25 70060-01845 0900022 Plug 3/8" (with o-ring) 70060-04019 661739 O-ring 70060-03794 661144 Oil seal 70060-04010 661730 Bearing 70060-04008 661728 Snap ring 70060-04014 661734... -
Page 30: Hydraulic Angling Kit - Bx2761 (Option)
PARTS – BX2761 (O YDRAULIC NGLING PTION ESCRIPTION UMBER Cylinder 2" x 5" 70001-00871 665433 Seal kit 70001-00872 665434 Hose clamp 70060-02106 666583 Attaching pin 3/4" x 2 1/2" 70001-00795 665235 Hose 1/4" x 100" 70001-04156 662362 Bolt hex. 3/8" NC x 1" Quick coupler 1/4"... -
Page 31: Lawn Dethatching Wheel Kit - Bx2737 (Option)
PARTS – BX2737 (O ETHATCHING HEEL PTION ESCRIPTION Wheel support LH 70060-01982 666941 Wheel support RH 70060-01983 666942 Wheel adjustment 70060-01984 666943 Wheel bracket 70060-01985 666944 Wheel bushing 70060-01986 666945 Wheel assembly 70060-01987 3800055 Serrated flange bolt 5/16" NC x 1/2" gr. 2 PTD 70060-01993 0200065 Serrated flange bolt 5/16"... -
Page 32: Available Options
AVAILABLE OPTIONS LAWN DETHATCHING WHEELS BX2737 HYDRAULIC ANGLING BX2761 (US only) BX2761A (Canada only) OM 0330 QH-A... -
Page 33: Available Equipment
AVAILABLE EQUIPMENT 50" SNOWBLOWER FRONT DOZER BLADES BX2763A – 60" (US only) BX2760A – 60" (Canada only) BX2750B TG2754 – 54" QUICK HITCH & SUBFRAME 47" ROTARY BROOM BX2751 BX2537A BX2711 OM 0330 QH-A... -
Page 34: Torque Specification Table
TORQUE SPECIFICATION TABLE GENERAL SPECIFICATION TABLE Use the following torques when special torques are not given Note: These values apply to fasteners as received from supplier, when dry. These values do not apply if lubricants are used. BOLT SIZES (SAE) TORQUE INCHES Pounds-Foot... - Page 36 Printed in Canada...
