VINGLI TV CABINET OR FIREPLACE CABINET
ASSEMBLY INSTRUCTION FOR MODEL FTS0WSRW
Scheme I
Scheme II
OR
Tool Recommended (Not Included)
2PERS
Thank you for purchasing from VINGLI!
Please contact us via email if parts are missing or damaged,we will
gladly ship your replacement parts free of charge.Please attach your
Order ID so that we can assist you better.
EMAIL
WEBSITE
IMPORTANT
!
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
support@vingli.com
www.vingli.com
INFORMATION.PLEASE READ
AND KEEP FOR FUTURE
REFERENCE.
Advertisement
Related Manuals for VINGLI FTS0WSR
Summary of Contents for VINGLI FTS0WSR
- Page 1 VINGLI TV CABINET OR FIREPLACE CABINET ASSEMBLY INSTRUCTION FOR MODEL FTS0WSRW Scheme I Scheme II Tool Recommended (Not Included) 2PERS Thank you for purchasing from VINGLI! Please contact us via email if parts are missing or damaged,we will gladly ship your replacement parts free of charge.Please attach your Order ID so that we can assist you better.
- Page 2 2 hours 30 -Do not allow children to climb on unit. -Avoid sharp objects or corrosive chemicals to prevent damage to the product. -During assembly, keep parts and packaging materials away from children and pets as there could be potential injury and choking hazards.
- Page 3 MODEL&ASSEMBLY TIPS Applicable Model Scheme I OVERALL SIZE: 47.24''W x 15.7''D x 31.77''H FEATURES: Barn Door Can use as TV cabinet or fireplace cabinet Scheme II Estimated Time for Assembly 180mins Caution: 1. This product is designed for home use and not intended for commercial use. 2.
-
Page 4: Part List
PART LIST Ø6x35mm Ø15x10mm Ø4x35mm Ø6x30mm Ax23(+2) Bx23(+2) Cx31(+2) Dx16(+1) Ø3x16mm Kx20(+2) Hx12 Lx20(+2) Ø4x12mm Ø6x30mm Tx22... -
Page 5: Identify Parts
IDENTIFY PARTS 1 case shipment... - Page 6 ASSEBMLY STEPS STEP 1 Lock the CAM bolt (A) in the corresponding positions of plates 1,8 and 4,13 as shown. Ø6x35mm A x23...
- Page 7 ASSEBMLY STEPS STEP 2 Connect 15 to 16 with screw E as shown, and lock it with a hex wrench Insert wood dowel C at correcsponding position of board STEP 3 No.4, and then use Cam lock B to connect board 4 & 15 as shown Ø15x10mm Ø6x30mm...
- Page 8 ASSEBMLY STEPS STEP 4 Insert wood dowel C at correcsponding position of board No.4, and then use Screw D to connect board 3 to 4 as shown Ø4x35mm Ø6x30mm STEP 5 Insert wood dowel C at corresponding position of board No.10 &...
- Page 9 ASSEBMLY STEPS Insert wood dowel C at correcsponding position of board No.4, and STEP 6 then use Cam lock B to connect board 10 & 12 to Board No.4, as shown Ø6x30mm Ø15x10mm STEP 7 Connect Board 17 with middle legs 19 with Screw D Ø4x35mm...
- Page 10 ASSEBMLY STEPS STEP 8 Insert wood dowel C at correcsponding position of board No.17, and then use Screw D to connect board 10 & 12 to Board No.17, as shown Ø4x35mm Ø6x30mm STEP 9 STEP 9 Insert Panel #5 along with the groove...
- Page 11 ASSEBMLY STEPS Insert wood dowel C at correcsponding position of board No.8 S S T T EP EP 10 & 13, and then use Cam lock B to connect board 8 and 13 with Board No.17 and 4 respectively Ø6x30mm Ø15x10mm Cx10 Bx10...
- Page 12 ASSEBMLY STEPS Connect the Iron Door Wheel 16 to Door Panels 18 & 20 STEP 12 respectively with Screw I as shown Put the Level adjuster O on the middle foot end, and the STEP 13 Foot Pad P on the 4 corner legs; and then connect Board 17 with the Assembled unit by using Screw F as shown...
- Page 13 ASSEBMLY STEPS STEP 14 Insert Panel #2 along with the groove STEP 15 Insert wood dowel C at end side of board No.8,3 & 13, and then use Cam lock B to connect the Top panel Board No.1 with the assembled unit Ø15x10mm Ø6x30mm...
- Page 14 ASSEBMLY STEPS STEP 16 Use Screw R to fix the safety fitting Q on the Back Panel Ø4x12mm STEP 17 Adding Mending Wedges K to back board 2 & 5 by using Screw L Ø3x16mm Kx20 Lx20...
- Page 15 ASSEBMLY STEPS STEP 18 As shown in the figure, insert one end of the laminate support into the corresponding position of the middle partition, and the No.9 panel is on the laminate support.
- Page 16 ASSEBMLY STEPS The user is requested to choose the TV cabinet in Scheme I or the fireplace in Scheme II according to their own needs. For the TV cabinet in Scheme I, please continue to install 19 to 20steps, and for the fireplace cabinet in Scheme II, use the matching fireplace, and continue to install 21 to 22 steps, Scheme I...
- Page 17 ASSEBMLY STEPS STEP 19 Insert the layer support (H) into the corresponding position, and then place the No. 11 movable layer board on the layer support (H),as shown. Scheme I...
- Page 18 ASSEBMLY STEPS Connect the upper and lower 6 # backplanes to 7 # backplanes; STEP 20 Use screws (T) to lock the two 6 # midplanes to the corresponding positions in the cabinet, as shown in the figure. Scheme I Tx22...
- Page 19 ASSEBMLY STEPS STEP 21 Push the fireplace into the cabinet,as shown. Use screws (U) to lock the fireplace to plates 14,21,as shown. Scheme II Matching fireplace...
- Page 20 ASSEBMLY STEPS STEP 22 Connect the upper and lower 6 # backplanes to the 7# backplane bones, and use screws (T) to lock the two 6 # backplanes in the corresponding positions of the cabinet, as shown in the figure. Scheme II Tx22...
- Page 21 A A SS SSE E B B M M L L Y Y S S TEPS TEPS STEP 23 Drill holes on the wall first,and insert Expension Screw S, then fix the unit with the wall by using Screw D for safe using Scheme I&...
- Page 22 ASSEBMLY STEPS STEP 24 Scheme I Scheme II...
- Page 23 1.What should I do when there are accessories or hardware missing? Pls feel free to contact VINGLI customer service via www.vingli.com with your order ID, the quan�ty, and corresponding listing number of missing part. We will send out for you as soon as possible.
