VINGLI FILE CABINET

ASSEMBLY INSTRUCTION FOR MODELS: FC0WVLW

2PERS

Please contact us via email if parts are missing or damaged,we will

gladly ship your replacement parts free of charge.Please attach your

Order ID so that we can assist you better.

support@vingli.com

Tool Required Not Provided

Thank you for purchasing from VINGLI!

www.vingli.com

/ FC0W1BB

WEBSITE

IMPORTANT

THIS NSTRUCTION BOOKLET

CONTAINS IMPORTANT SAFETY

INFORMATION.PLEASE READ

AND KEEP FOR FUTURE

REFERENCE.

Need help?

Do you have a question about the FC0WVLW and is the answer not in the manual?

Questions and answers

Summary of Contents for VINGLI FC0WVLW

Page 1 VINGLI FILE CABINET ASSEMBLY INSTRUCTION FOR MODELS: FC0WVLW / FC0W1BB Tool Required Not Provided 2PERS Thank you for purchasing from VINGLI! Please contact us via email if parts are missing or damaged,we will gladly ship your replacement parts free of charge.Please attach your Order ID so that we can assist you better.
Page 5 MODEL&ASSEMBLY TIPS OVERALL SIZE:...
Page 6 IDENTIFY PARTS 1 case shipment...
Page 7 PART LIST Top Panel Separate Panel Upper Left Panel Bottom Panel Upper Right Panel Adjustable Shelf Back Connecting Strip Fixed Shelf Lower Right Panel Upper Back Panel Back Support Panel Lower Left Panel Lower Back Panel Iron Side Frame Iron Brace Door Panel Drawer Back Panel Drawer Support Panel...
Page 8 PART LIST Cx20(+2) Dx11(+1) 4x35mm 4x35mm M6x40mm 6x30mm Wood Dowel Screw Screw Screw Hx12(+1) 3.5x12mm M6x30mm Screw Screw Adjustable Leveler Drawer Slide Lx12 Hexagon wrench Mending Wedge Anti-tipping Device Shelf Support Peg Ox12 3.5x16mm 3x16mm Screw File Lock Screw Screw Arched Handle 6x30mm Expansion Screw Hinge...
Page 9 ASSEBMLY STEPS...
Page 10 ASSEMBLY STEPS STEP 1 Fix the Anti-tipping Device(M-1) on Panel #3 with Screw(M-2) Screw the Cam Bolt(A) to Panel #1 6x35mm...
Page 11 ASSEMBLY STEPS STEP 2 Screw the cam bolt (A) onto the panels # 4 and # 5 6x35mm...
Page 12 ASSEMBLY STEPS STEP 3 Insert Wood Dowel(C) into Panel #6 #9 first,and then connect Panel #5 to them with Cam Lock(B) 15x10mm 6x30mm...
Page 13 ASSEMBLY STEPS STEP 4 Insert Wood Dowel(C) into Panel #6 #9 first,and then connect Panel #4 to them with Cam Lock(B) 15x10mm 6x30mm...
Page 14 ASSEMBLY STEPS STEP 5 Insert the Wood Dowel(C) into Panel #4 #5 first, and then connect Panel #2 to them with Screw(D) 4x35mm 6x30mm...
Page 15 ASSEMBLY STEPS STEP 6 First, clip two Panel #10 and Back Connecting Strip #8 together, and then push them in along the grooves on Panel #4 #5...
Page 16 ASSEMBLY STEPS STEP 7 Insert Wood Dowel(C) into the top of Panel #4 #5 first and then connect Panel #1 to the cabinet body with Cam Lock(B) 15x10mm 6x30mm...
Page 17 ASSEMBLY STEPS STEP 8 Screw the Cam Bolt(A) onto Panel #2 6x35mm...
Page 18 ASSEMBLY STEPS STEP 9 Attach the drawer slides to Panel #11 #12 with Screw(H) Kind Tips: The pre-drilled holes for locating the drawer slides are relatively small, look carefully. Please don't worry, they are there Screw the Cam Bolt (A) onto Panel #11 #12 Front View Back View 6x35mm...
Page 19 ASSEMBLY STEPS STEP 10 Insert Wood Dowel(C) into Panel #3 first,and then connect Panel #11 #12 to it with Cam Lock(B) 15x10mm 6x30mm...
Page 20 ASSEMBLY STEPS STEP 11 Build the iron frame part M6x40mm...
Page 21 ASSEMBLY STEPS STEP 12 Connect the iron frame part to Panel #3 with Screw(E G) Note to use the correct screws 4x35mm M6x30mm...
Page 22 ASSEMBLY STEPS STEP 13 Connect the Adjustable Levelers to the bottom...
Page 23 ASSEMBLY STEPS STEP 14 Insert Panel #13 along with the groove...
Page 24 ASSEMBLY STEPS STEP 15 Insert the Wood Dowel(C) into the top of Panel #11 #12, and then connect the upper and lower parts together with the Cam Lock(B) 15x10mm 6x30mm...
Page 25 ASSEMBLY STEPS STEP 16 Fix the Mending Wedge(L) with Screw(O) as picture shows for more stability 3x16mm Ox12 Lx12...
Page 26 ASSEMBLY STEPS STEP 17 Drill holes in the wall, insert Expansion Screw(W), and fix the item to the wall with Screw(D) for safe use WALL WALL WALL drilling hole 6x30mm WALL 6x30mm 4x35mm...
Page 27 ASSEMBLY STEPS STEP 18 Insert the Shelf Support Peg(N) as needed and place the Adjustable Shelf #7 accordingly...
Page 28 ASSEMBLY STEPS STEP 19 Fasten hinge and handle to door panel # 16 as shown 4x14mm Xx12...
Page 29 ASSEMBLY STEPS STEP 20 Fasten the door hinge to the cabinet with Screw(X). Adjust the hinge to even the doors without protruding from the cabinet Turn to the page #37 to see "Guide to Hinge Adjustment" 4x14mm Xx24...
Page 30 ASSEMBLY STEPS STEP 21 Confirm where the doors collide with panel #6 by opening and closing the doors, and attach the anti-collision rubber pads in places to reduce noise...
Page 31 ASSEMBLY STEPS STEP 22 Time to assemble the drawer! Connect the Drawer Slide(J-2) to Panel #21 #22 with Screw(H) Front Back 3.5x12mm J-2x2...
Page 32 ASSEMBLY STEPS STEP 23 Screw Cam Bolt(A) to Panel #17; Fix Lock and Handles to Panel #17 as picture shows 3.5x16mm 6x35mm...
Page 33 ASSEMBLY STEPS STEP 24 Connect the Drawer Back Panel #18 to the Drawer Support Panel #20 with Screw (D). Note to distinguish the front and back of the Drawer Support Panel 4x35mm...
Page 34 ASSEMBLY STEPS STEP 25 First pass the Long Hanging Rod(U) through the end of the Movable Hanging Rod(T) with loop first, then insert the Long Hanging Rod(U) into the drawer side panels while securing Panel #21 #22 to Panel #18 with Screw (D) 4x35mm...
Page 35 ASSEMBLY STEPS STEP 26 Insert Panel #19 along with the groove; Insert the Short Hanging Rod(V) into Panel #18 before next step...
Page 36 ASSEMBLY STEPS STEP 27 Attach Panel #17 to the drawer body with Cam Lock(B) 15x10mm...
Page 37 ASSEMBLY STEPS STEP 28 Pull Drawer Slide(J-1) out first, and the ball along with it to the front; Keep the drawer level and insert the drawer with the slides aligned.Note! Failure to level may result in damage to the slides...
Page 38 ASSEMBLY STEPS STEP 29 The installation is complete WALL...
Page 39 GUlDE TO HINGE ADJUSTMENT...
Page 40 OPTIONS OF FILE STORAGE Option 1 Option 2 Letter Letter Option 3 Legal Option 4 Legal Place the Movable Hanging Rods as needed...
Page 41 FAQS 1.What should I do when I received a defected item or missing parts? Please feel free to contact VINGLI customer service via the link where you purchased this item with your order ID, pictures & sticker number of the defective/missing parts to us. We are eager to help you to make it right.
