PRO-CHARGE
DC TO DC BATTERY CHARGER
25 Amp, 3 Stage Switchmode
P/No. PDC25
WARNING: This is a HIGH current device.
It is the installers responsibility to ensure all cabling meets the
requirements as stipulated on page 6 of this installation manual to ensure a
SAFE installation, particularly when upgrading with a higher capacity unit.
Failure to comply with the supplied installation instructions will void the warranty.
CAUTION: Surface may become hot during operation.
Avoid direct contact to prevent burns.
Advertisement
Related Manuals for Projecta PRO-CHARGE PDC25
Summary of Contents for Projecta PRO-CHARGE PDC25
- Page 1 PRO-CHARGE DC TO DC BATTERY CHARGER 25 Amp, 3 Stage Switchmode WARNING: This is a HIGH current device. It is the installers responsibility to ensure all cabling meets the requirements as stipulated on page 6 of this installation manual to ensure a SAFE installation, particularly when upgrading with a higher capacity unit.
- Page 2 WARNINGS • Explosive gases may escape from the battery during charging. Prevent flames and sparks and provide adequate ventilation. • Before charging, read the instructions. • FOR CHARGING 12 VOLT LEAD ACID BATTERIES ONLY. • Do not attempt to charge non-rechargeable batteries. •...
- Page 3 MULTI-CHEMISTRY SUPPORT The PDC25 supports Lithium , AGM, WET and CALCIUM batteries. If the calcium battery mode is selected, periodic equalisation will be provided to the calcium battery for removing acid stratification. IGNITION CONNECTION The ignition connection activates the lower input voltage operation to suit vehicles with smart (variable voltage) alternators.
- Page 4 SPECIFICATIONS Operating Conditions Alternator Input Voltage 11.9 – 32Vdc Maximum Solar Input Voltage 28Vdc Maximum Input Current Input Current (No Load) 20mA Back Drain on Auxiliary Battery 9.5 – 10.5mA External LED Output – Constant Current 4 mA Maximum Output Current Input 9–11Vdc: Input 11V-32dc: Input Fuse Rating...
- Page 5 PRODUCT OVERVIEW Battery Chemistry Selection (Mode) Button Alternator LED Battery Temperature DC leads with 50A LED Indicates Chemistry Sensing Cable HD connectors alternator input Display status Indicates selected battery chemistry type Solar LED Mounting Indicates solar Slots input status...
- Page 6 INSTALLATION MOUNTING The rugged design of the PDC25 affords it to be mounted wherever best suits the application. By using advanced potting technology the unit is resistant to shock, vibration, dust and water allowing for under-bonnet or in-vehicle installation. Clever ‘side extrusions’...
- Page 7 If your vehicle has a smart (variable voltage) alternator installed, the Ignition Override cable must be connected to the vehicle’s ignition. The PDC25 will only operate when the vehicle’s ignition is turned on (may take up to two minutes to start charging).
- Page 8 SELECTION OF AUXILIARY BATTERY TYPE Press the Mode button on the front panel until one of the Battery Chemistry LEDs is flashing (indicating the current chemistry selection), then repeatedly press the Mode button until the desired Battery Chemistry LED is flashing. There are 4 battery chemistries available: Gel, AGM, Wet and Calcium.
- Page 9 TYPICAL WIRING INSTALLATION 1. Full System LED Panel Mount Indicator For vehicles fitted with a Smart Alternator only Earth/Chassis Fuse Fuse Ground/Chassis Earth/Chassis Battery 1 Battery 2 Temp Sensor mount (Starter Battery) (Aux Battery) to battery casing 12V Solar Panel Earth/Chassis * Optional...
- Page 10 2. Alternator/Starter Battery Input Only LED Panel Mount Indicator For vehicles fitted with a Smart Alternator only Earth/Chassis Fuse Fuse Ground/Chassis Earth/Chassis Battery 1 Battery 2 Temp Sensor mount (Starter Battery) (Aux Battery) to battery casing * Optional...
- Page 11 3. Solar Battery Input Only LED Panel Mount Indicator Earth/Chassis Fuse Earth/Chassis Battery 2 Temp Sensor mount (Aux Battery) to battery casing 12V Solar Panel Earth/Chassis * Optional...
- Page 12 HOW TO READ LED DISPLAY LED Charge Indicators Charging LED Battery Type LED Charging Stage GREEN Flashing Solid BLUE Bulk Charge GREEN Flashing BLUE Flashing Absorption Charge Solid GREEN BLUE Flashing Equalization Charge Solid GREEN Solid BLUE Float Charge Power Saving Mode Indicators Alternator LED Solar LED Battery Type LED...
- Page 13 FREQUENTLY ASKED QUESTIONS Q. Is the PDC25 waterproof? A. The Projecta PDC25 is designed to be dust and weather proof. Normal use including river crossings and light engine washing will not pose any problems. Direct high pressure washing of the PDC25 unit may cause some water damage and will not be covered under warranty.
- Page 14 Q. What is Surface Charge? A. Batteries unused or left discharged for some time build up a resistance to being recharged. When the charger is first connected, these batteries will take a surface charge, and the ‘FULLY CHARGED’ LED will illuminate within a short period of time.
- Page 15 NOTES...
- Page 16 Brown & Watson International Pty. Ltd. Knoxfield Victoria 3180 Phone: (03) 9730 6000 Fax: (03) 9730 6050 National Toll Free: 1800 113 443 NEW ZEALAND OFFICE Brown & Watson International NZ Ltd. Mount Wellington, Auckland 1060 Phone: (09) 525 4575 projecta.com.au IS644 Issue 1: 17/12/2024...
