Rainfresh SM4 Assembly And Operation Instructions Manual

Gravity drinking water system

Advertisement

Available languages

Available languages

Quick Links

Thank you for purchasing a Rainfresh Product.
We are committed to ensuring that you are totally satisfied.
For any questions, please contact customer service.
Customer Service • 001 (905) 884 9388
Canada Toll Free • 1800 667 8072 (Mon to Fri 8:30 AM to 5:00 PM EST)
E-Mail: info@rainfresh.ca • Web: www.rainfresh.ca
CONTENTS
A. Introduction
B. Notes & Warnings
C. Assembly
D. Operation
E. Cartridge Cleaning
F. Cartridge Life
G. Parts List
H. Warranty
A) INTRODUCTION
Rainfresh SM4 Stainless Steel Gravity Water Filter is designed to provide
microbiologically safe drinking water from virtually any water source
(lake, river, pond, stream, well etc.) without the use of pumps or electricity.
It utilizes Rainfresh's unique self-disinfecting, silver-impregnated ceramic filtration technology to trap & kill >99.9999%
pathogenic bacteria (e.g. E. coli) and >99.95% protozoan cysts (e.g. Cryptosporidium & Giardia) in addition to reducing
sediment and suspended matter down to 0.3 micron absolute (1 micron = 1/1000 mm). It also reduces chlorine and improves
water taste and odour.
This unit includes four ceramic cartridges (model 7500G) which are cleanable and reusable (See section E – Cartridge Cleaning).
HOW IT WORKS
The unit has two separate water containers, one (top) for the untreated water and the other (bottom) for safe drinking water.
Both containers are constructed from sturdy, non-magnetized, polished stainless steel.
The upper container holds about 8.5 liters of untreated water. It also holds the four ceramic cartridges through which the
untreated water flows under gravity and gets collected in the bottom treated water container. As water passes through the
ceramic cartridges, harmful bacteria and cysts are trapped inside the cartridges and safe drinking water passes through. Safe
water is dispensed from the spigot (included).
B) NOTES & WARNINGS:
1.
Contaminants reduced by this filter are not necessarily in your water. Individuals requiring water of specific microbiological purity
should follow the advice of their doctor or local health unit.
2.
For cold water use only
3.
Do not subject this unit to freezing temperatures or it will crack.
4.
Do not boil the cartridges to disinfect. They are self-disinfecting.
Tested and Certified by CSA Group to NSF/ANSI Standard 53 for reduction of Cyst
(e.g. Cryptosporidium & Giardia).
The standard referenced above evaluates products for use with disinfected waters.
Additional testing and verification for reduction of bacteria and particulates performed
by independent laboratory.
Gravity Drinking Water System • Model SM4
INSTALLATION VIDEO
1
1
2
3
3
3
4
Or visit the Rainfresh
4
Youtube channel
Assembly and Operation Instructions
(Please read carefully before proceeding and retain for future reference)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rainfresh SM4

  • Page 1 (lake, river, pond, stream, well etc.) without the use of pumps or electricity. It utilizes Rainfresh’s unique self-disinfecting, silver-impregnated ceramic filtration technology to trap & kill >99.9999% pathogenic bacteria (e.g. E. coli) and >99.95% protozoan cysts (e.g. Cryptosporidium & Giardia) in addition to reducing sediment and suspended matter down to 0.3 micron absolute (1 micron = 1/1000 mm).
  • Page 2 C) ASSEMBLY NOTE: Ceramic cartridges are fragile, please handle carefully. The following items are included with the SM4 system: Ceramic Filter Spigot Cartridge Gauge Scrub Pad Hole Plug Stainless Steel Containers Cartridges (854) (703-4) (811-0) (859) Lid, Top, Bottom, Rubber Base...
  • Page 3: Operation

    703-4 (Approximate): Up to 12 Months. Cartridge life is directly related to your water conditions, volume of water filtered and frequency of cleaning. Frequent cleaning ensures best efficiency. The SM4 can be kept in a cooler/refrigerator etc. while in operation.
  • Page 4: Parts List

    H) LIMITED 5 YEAR WARRANTY SM4 system is warranted, to the original purchaser/owner, for a period of five (5) years, from the date of purchase, against defects in materials or workmanship. Envirogard’s obligation under this warranty shall consist of repair, replacement or credit, at its option, of any part found by company inspection to be defective, provided that the product has not been misused, abused, altered or damaged as determined by the company and provided that only approved Envirogard replacement cartridges have been used in the housings.
  • Page 5: Comment Ça Fonctionne

    (lac, rivière, étang, ruisseau, puits, etc.) sans l'utilisation de pompes ni d'électricité. Il utilise la technologie unique de filtration en céramique auto-désinfectante et imprégnée d'argent de Rainfresh pour piéger et tuer > 99,9999 % des bactéries pathogènes (par exemple E. coli) et > 99,95 % des kystes protozoaires (par exemple Cryptosporidium &...
  • Page 6: Notice De Montage

    C) NOTICE DE MONTAGE REMARQUE : Les cartouches en céramique sont fragiles, veuillez les manipuler avec précaution. Les éléments suivants sont inclus avec le système SM4 : Cartouches filtrantes Robinet Jauge de filtre Tampon de Bouchon de trou Conteneurs en acier inoxydable en céramique...
  • Page 7: Opération

    (Approximatif ) : jusqu'à 12 mois. La durée de vie de la cartouche est directement liée aux conditions de votre eau, au volume d'eau filtrée et à la fréquence de nettoyage. Un nettoyage fréquent assure une meilleure efficacité. Le SM4 peut être conservé dans une glacière/réfrigérateur etc. pendant son fonctionnement.
  • Page 8: Liste Des Pièces

    H) GARANTIE LIMITéE DE 5 ANS Le système SM4 est garanti, à l'acheteur/propriétaire d'origine, pour une période de cinq (5) ans, à compter de la date d'achat, contre les défauts de matériaux ou de fabrication. L'obligation d'Envirogard en vertu de cette garantie consistera en la réparation, le remplacement ou le crédit, à sa discrétion, de toute pièce jugée défectueuse par l'inspection de l'entreprise, à...
