MUCAR VO7 S
1. Product Overview
1. Bluetooth Diagnostic Dongle: Green: device is powered on, blue: bluetooth is
connected, red: there is a fault code.
2. Touch Screen: 7 inches (1280*720).
3. On/Off key: Long press to switch on/off , click to rest the screen.
4. Charging Port: TYPE-C charging port & development system debugging USB port.
5. Camera: Support 1300W pixel camera for taking pictures.
Tip:
Support CANFD protocol
2.Connect the mucar vo7 with your vehicle through the OBDII
port
Usually, the OBD port is located under the dashboard, above the pedal on the driver's side.
The five locations shown lite the picture are common OBDII port locations.
3. Turn on the mucar vo7 S
Advertisement
Related Manuals for MUCAR VO7 S
Summary of Contents for MUCAR VO7 S
- Page 1 5. Camera: Support 1300W pixel camera for taking pictures. Tip: Support CANFD protocol 2.Connect the mucar vo7 with your vehicle through the OBDII port Usually, the OBD port is located under the dashboard, above the pedal on the driver’s side.
-
Page 2: Functions Description
After connecting with the car, the screen will display as shown like the picture. 4.Connect Wi-Fi The system will automatically search all available Wi-Fi networks and you can choose the “Wi-Fi” needed. Notice the “Wi-Fi” must be set before use. 5.Human online customer service Pull down the task bar, fifi nd the customer service icon, click on it, and then human online customer service will appear to answer the questions you encounter during the use of the... - Page 3 The MUCAR VO7 S main unit has the following 10 functions: 6.1 Scan: This module has auto search (automatic scanning of car models' VIN), car model lists, Demo (demonstration of the diagnosis process), History (diagnosis records), OBD&IM (9 emission-related module diagnosis) 6.2 OBD: Support OBD II and EOBD protocols after 1996.
- Page 4 6.8 Store: Display related products, please contact the dealer if necessary. 6.9 update: This module allows you to update the diagnostic software & App and set frequently used software. If you did not download the software at registration or some software is newly updated, you may use this option to download it or keep it synchronized with the latest version.
-
Page 5: Warranty Terms
The compensation for dashboard damage caused by the defect of this equipment is limited to repair or replacement. MUCAR TECH does not bear any indirect and incidental losses. MUCAR TECH will judge the nature of the equipment damage according to its prescribed inspection methods.
