TSB/TWE/TWP
™
Touchscreen data logger for DicksonOne
This Quick-start Guide presents an overview of the Touchscreen data logger, with setup and
connection instructions to get your device up and running on Ethernet or Wi-Fi. You can
then
register the device
in DicksonOne to view data online, configure alarms, and much
more.
What's in the box
Replaceable Sensor(s)
Touchscreen Data Logger (TSB
(Your sensor may differ and be in
AC Adapter
/ TWE / TWP)
another package)
Mounting Plate - used for
Kickstand to stand the device
mounting the Touchscreen
on a flat surface when not
Ethernet Cable
Data Logger to the wall
mounted to a wall
(for DicksonOne Units)
Touchscreen Data Logger Quick Start Guide (DicksonOne)
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TSB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dickson TSB

Summary of Contents for Dickson TSB

  • Page 1 DicksonOne to view data online, configure alarms, and much more. What’s in the box Replaceable Sensor(s) Touchscreen Data Logger (TSB (Your sensor may differ and be in AC Adapter / TWE / TWP) another package) Mounting Plate - used for...

  • Page 2: Getting Started

    Device Settings NOTE: TSB devices are configured via the touchscreen interface ONLY. TWE/TWP devices are connected to the internet via the touchscreen interface but are further configured on DicksonOne. Touch the ‘Settings’ icon on the bottom right of the device screen to access the device settings screens for device configuration and device information.
  • Page 3 This screen will not be used for standalone TSB loggers. 5. ‘Alarms’ allows you to enable the alarm (up to two per channel or one high and one low per channel).
  • Page 4 Connect via WiFi 1. Navigate to the ‘Network Settings’ screen. 2. Switch the ‘Network Adapter’ setting to WiFi. 3. Tap Scan to scan for your network. Select the appropriate network from the list. If you don’t find your network, manually enter your SSID. 4.

  • Page 5: General Settings

    DicksonOne Account Log into or create your DicksonOne account at https://www.dicksonone.com/ to get started with: ● Device management ● Adding users ● Creating alarms ● Configuring reports ● And more! Adding Locations, Users, Alarms and more To learn more about how to add locations, users, and configure alarms on your DicksonOne account please visit the knowledge center by going to https://dicksondata.com/resources/support/dicksonone/ Configure your Device Settings...

  • Page 6: Graph Settings

    Graph Settings Display View: Toggle between a Graph and Text view on the home screen. Display Statistics: Display minimum, maximum, and average on the home screen for any channels displayed on the graph. Vertical Scale Auto: Automatically scale the Y-axis based on the data or manually set the min/max values for the variables.

  • Page 7: Screen Lock Settings

    Screen Lock Settings Enabled: Toggle the Settings Lock on/off. Timeout: How long until the screen lock is enabled. Set Passcode: Set the 4-digit passcode and confirm it before it is saved. Touchscreen Data Logger Quick Start Guide (DicksonOne) Page 7...
  • Page 8 ©2025 Dickson. All rights reserved. Dickson, the Dickson logo, DicksonOne, and Touchscreen are the exclusive property of Dickson. All other brands mentioned are the property of their respective owners. This is a non-contractual document. Product photos and features may vary.
