Erbauer ERT1029GMT Original Instructions Manual

36v 4-in-1 multi-t

Hide thumbs

Table Of Contents

Quick Links

Download this manual

ORIGINAL INSTRUCTIONS

IMPORTANT - These instructions are for your safety.

Please read through them thoroughly prior to handling

the product and retain them for future reference.

MNL_ERT1029GMT_EN_V01_241017

EN 36V 4-in-1

Multi-Tool

ERT1029GMT

5059340904740

5059340904504

5063022544537

Table of Contents

Need help?

Do you have a question about the ERT1029GMT and is the answer not in the manual?

Questions and answers

Summary of Contents for Erbauer ERT1029GMT

Page 1 EN 36V 4-in-1 Multi-Tool ERT1029GMT ORIGINAL INSTRUCTIONS 5059340904740 IMPORTANT - These instructions are for your safety. 5059340904504 Please read through them thoroughly prior to handling the product and retain them for future reference. 5063022544537 MNL_ERT1029GMT_EN_V01_241017...
Page 2: Table Of Contents
EN Parts 01. x1 02. x1 03. x1 04. x1 05. x1 06. x1 07. x1 08. x1 09. x1 10. x1 EN You will need EN Contents Product description Safety Technical specification Before you start Functions & Settings Operation Care and maintenance Guarantee Declaration of conformity...
Page 3: Product Description
EN Product Description 18 19 25 26 27 Coupler Blade sheath Speed Mode Switch Chain-tensioning screw Handle/Grasping surface Oil tank Wing Knob Oil-tank cap Lock-off Button Guide bar Variable Speed Trigger Saw chain battery docking port Side-cover knob Trimmer head Side cover Grass trimmer attachment shaft Pole saw Attachment shaft...
Page 4: Electrical Safety
EN Safety General power machine safety warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this machine. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference The term “machine”...
Page 5: Personal Safety
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the machine.
Page 6 Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the machine. Carrying machines with your finger on the switch or energising machines that have the switch on invites accidents.
Page 7 on and off. Any machine that cannot be controlled with the switch is dangerous and must be repaired. Disconnect the plug from the power source and/ or remove the battery pack, if detachable, from the machine before making any adjustments, changing accessories, or storing machines.
Page 8 Battery machine use and care Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Use machines only with specifically designated battery packs.
Page 9 improperly or at temperatures outside the specified range may damage the battery and increase the risk of fire. Service Have your machine serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the machine is maintained. Never service damaged battery packs.
Page 10 he rated rotational speed of the blade must be at f) T least equal to the maximum rotational speed marked on the machine. Blades running faster than their rated rotational speed can break and fly apart. Wear eye, ear, head and hand protection. Adequate protective equipment will reduce personal injury by flying debris or accidental contact with the cutting line or blade.
Page 11 Do not operate the machine on excessively steep slopes. This reduces the risk of loss of control, slipping and falling which may result in personal injury. When working on slopes, always be sure of your footing, always work across the face of slopes, never up or down and exercise extreme caution when changing direction.
Page 12 Carry the machine with the machine switched off and away from your body. Proper handling of the machine will reduce the likelihood of accidental contact with a moving cutter, line or blade When transporting or storing the machine, always fit the cover on metal blades. Proper handling of the machine will reduce the likelihood of accidental contact with the blade.
Page 13: Hedge Trimmer Safety Warnings
Blade thrust can increase the risk of injury due to the machine moving unexpectedly. Blade thrust can be controlled by the operator if proper precautions are taken. If the blade binds, or when interrupting a cut for any reason, switch the machine off and hold the machine motionless in the material until the blade comes to a complete stop.
Page 14 Keep all power cords and cables away from cutting area. Power cords or cables may be hidden in hedges or bushes and can be accidentally cut by the blade. Wear ear protection. Adequate protective equipment will reduce the risk of hearing loss. Hold the hedge trimmer by insulated gripping surfaces only, because the blade may contact hidden wiring.
Page 15: Pole Saw Safety Warnings
Additional safety instructions for pole hedge trimmers Pole hedge trimmer safety warnings: lways use head protection when operating the pole a) A hedge trimmer overhead. Falling debris can result in serious personal injury. Always use two hands when operating the pole hedge trimmer.
Page 16 by the operator, if proper precautions are taken. Do not let go of the pole saw. When cutting a branch be alert for kickback. When the branch is broached it can bend down and jam the saw chain. Carry the pole saw switched off, always with both hands and the saw chain with bar cover fitted, away from you.
Page 17: Causes And Operator Prevention Of Kickback
Causes and operator prevention of kickback: Kickback may occur when the nose or tip of the guide bar touches an object, or when the wood closes in and pinches the saw chain in the cut. Tip contact in some cases may cause a sudden reverse reaction, kicking the guide bar up and back towards the operator.
Page 18 Some regions have regulations that restrict the use of the product. Check with your local authority for advice. Additional safety warnings for multi tool. a) Damage to Trimmer - If you strike a foreign object with the trimmer or it becomes entangled, stop the machine immediately, check for damage and have any damage repaired before further operation is attempted.
Page 19 inspect the cutting accessory or cutting head and clean all the foreign objects which cause blockage. This blockage situation may cause overheating of the motor. i) Need daily inspection before use and after dropping or other impacts to identify any significant defects. j) Follow the corresponding figures for correct working posture, need rest and changing working positions regularly.
Page 20 f) Do not charge battery in a damp or wet location. Following this rule will reduce the risk of electric shock. g) Do not disassemble the battery and avoid mechanical damage to the battery. Risk of short circuit and fumes may be emitted. Ensure fresh air and seek medical assistance in the event of discomfort.
Page 21: Residual Risks
The European Physical Agents (Vibration) Directive has been brought in to help reduce hand arm vibration syndrome injuries to users of products with vibration emission. The directive requires manufacturers and suppliers to provide indicative vibration test results to enable users to make informed decisions as to the period of time a product can be used safely on a daily basis and the choice of tool.
Page 22 1. Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. 2. Injuries and damage to property due to broken accessories or the sudden impact of hidden objects during use.
Page 23 Symbols On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations. Familiarise yourself with them to reduce hazards like personal injuries and damage to property. Volt, (direct current voltage) km/h Kilometre/Per hour Milliampere per hour Millimetre...
Page 24 WARNING –Disconnect battery before maintenance Do not use metal blades. Keep sufficient distance away from electrical power lines. Objects thrown by the product could hit the user or other bystanders. Always ensure that other people and pets remain at a safe distance from the product when it is in operation.
Page 25 The product complies with the applicable Your product European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation Cordless multi-tool: ERT1029GMT ER = Brand name (Erbauer) T = 36V Lithium-lon 1029 = Serial number GMT = Garden multi-tool...
Page 26: Technical Specification
EN Technical specifications General: > Rated voltage > Extension pole length 750mm For Grass trimmer: > Max speed (two speed switch) n 5000/5900/min > Trimming line Non-metallic(nylon),2.0mm > Cutting width 33cm > Total length of cutting line 2m x 2 >...
Page 27 5°C to 40°C 5°C to 40°C battery and charger to use. NOTE: This equipment is compatible with the Erbauer EXT 18V/36V dual-voltage lithium-ion battery range. For optimal performance, use 1X 4.0Ah battery. Sound values(For Grass trimmer): > Sound pressure level L 83dB(A) >...
Page 28 > Rear handle vibration value a 1.86 m/s² > Uncertainty K 1.5m/s Sound values (For pole saw): > Sound pressure level L 93dB(A) > Uncertainty K 3 dB(A) > Measured sound power level L 99 dB(A) > Uncertainty K 0.8 dB(A) >...
Page 29: Before You Start
EN Before you start Unpacking Unpack all parts and lay them on a flat, stable surface. Remove all packing materials and shipping devices if applicable. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact your dealer.
Page 30 EN Assembly WARNING! The product must be fully assembled before operation! Do not use a product that is only partly assembled or assembled with damaged parts! WARNING! Disconnect the battery pack from the machine before making any assembly, adjustments, changing accessories, or storing machine. Such preventive safety measures reduce the risk of starting the machine accidentally.
Page 31 Power-Head Shaft Groove 1 Coupler Groove 2 Wing Knob Groove 1 Attachment Shaft Removing the attachment from the power head (Fig. 2c) Remove the battery pack. Loosen the wing knob. Press down the spring-loaded pin and pull the attachment shaft out of the coupler. Refer to Installing/Removing a Power Head Attachment for extension pole Installing/Removing Mounting and Adjusting the Front-Assist Handle (Fig.
Page 32: Shoulder Strap
Front-Assist Handle Wing Mounting Hex Bolt Zone Shoulder strap The shoulder strap (35) helps the operator carry this product. a) Place the shoulder strap (35) over your left shoulder so that it runs over the left shoulder, crossing the chest and back. (Fig. 4). b) Fasten the snap hook on the securing clip on the shaft (Fig.
Page 33 Grass Trimmer: MOUNTING THE GUARD (FIG. 5a&5b&5c) Lift the trimmer head (8) and face it downward. Slide the big guard into the slot on the trimmer head ensuring that the mounting holes align. (Fig.5a) Slide the small guard into the slot on the trimmer head and ensuring that it engages with big guard.(Fig.5b) Lock the guard in place with the 2 screws supplied.
Page 34 Installing the Barrier WARNING! • Install the guard before the attachment is connected to the power head. • To reduce the risk of injury to persons, do not operate without guards in place. The guard must always be on the tool to protect the user. 1.
Page 35 Folding the attachment Ensure that the blade sheath (21) is in place and the battery pack is disconnected from the power head. Hold the handle (19), squeeze the locking levers (18) and (15) together, and hold them in position.(Fig.8a) Fold the cutting head (17) next to the shaft.(Fig.8b) Release the locking levers.
Page 36 Pole saw: Filling Oil tank with Bar and Chain Lubricant The pole saw is not filled with oil at the time of purchase. It is essential to fill the tank with oil before use. Operating the pole saw without chain oil or when the oil level is below the minimum mark will result in damage to the saw.
Page 37: Battery Pack
empty the oil tank after each use, and then run the saw for one minute. When storing the tool for a long period of time, be sure the chain is lightly lubricated; this will prevent rust on the chain and bar sprocket. To preserve natural resources, please recycle or dispose of oil properly.
Page 38: Functions & Settings
EN Functions & settings Intended use The product is multifunctional and can be used as grass trimmer, brush cutter, pole saw and pole hedge trimmer according to the intended operation with the desired tool attachments. Grass trimmer: with the trimming head attached, the product is intended for cutting weed, grass or similar soft vegetation.
Page 39 Power head Switching on/off WARNING! Never operate the power head without an attachment. Do not attempt to start the power head without an attachment. To start the power head To turn the power head ON, push the lock-off button to the left or right and then depress the variable-speed trigger.
Page 40: Operation
EN Operation General operation Check the product, its battery packs and charger as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. Double check that the accessories and attachments are properly fixed. Always hold the product by its handles.
Page 41 Trimming: Attach the grass trimmer attachment shaft. Hold the product firmly with a gap between the product and your right side Stand upright, do not lean forward and pay attention to posture. Keep both feet apart to help retain your balance. Hold the cutting head just above the ground at an angle of approximately 30°...
Page 42 Brush cutter: Using the Brush Cutter: WARNING! To avoid serious personal injury, wear goggles or safety glasses at all times when operating this unit. Wear a face mask or dust mask in dusty locations. Wear proper clothing and footwear during operation to reduce the risk of injury that may be caused by flying debris.
Page 43 WARNING! Improper use of a brush cutter blade may cause it to crack, chip, or shatter. Resharpen the blade regularly (when it has dulled noticeably) and have it balanced if necessary (performed by a qualified service technician). With particular emphasis on the effects of blade thrust behaviour that may result if specifications are not followed.
Page 44: Using The Hedge Trimmer
Using the Hedge Trimmer WARNING! • If any parts are missing, damaged or broken, do not operate your trimmer until they have been replaced. Failure to do so could result in possibly serious personal injury. • To prevent serious personal injury, always use both the front-assist handle and the rear handle to hold the hedge trimmer during operation.
Page 45 easily by using a sawing (back-and-forth) motion. • Always cut stems or twigs that are less than 20 mm thick. Use a non-powered hand saw or pruning saw to trim larger stems. The maximum cutting capacity must be observed. Do not cut branches exceeding the stated maximum capacity.
Page 46 • Saw with the guide bar at a flat angle. • Always hold the product firmly with both hands. Pruning MAX.60° Always hold the product firmly with both hands on gripping surface and assistant handle. Never operate this product using only one hand (Fig. 19a). Maintain a firm grip with your thumbs and fingers encircling the handles.
Page 47 Use the product only with secure footing. Hold the product at the right-hand side of your body. Regularly change the working position and include rest periods during operation. Do not operate the product with arms fully extended or attempt to cut areas which are difficult to reach.
Page 48: After Use
Cut into the branch from the top outside at the same height the branch is sawn from top (Fig. 19h). Last, cut off the stump with one clean cut from top to bottom (Fig. 19i). You might want to seal the cut with a suitable compound. NOTE: Remove the branches lying on the floor regularly to avoid stumbling hazards.
Page 49: Care And Maintenance
EN Care and maintenance The golden rules for care WARNING! Always switch the product off, remove the battery pack and let the product cool down before performing inspection, maintenance and cleaning work! Keep the product clean. Remove debris from it after each use and before storage. Regular and proper cleaning will help ensure safe use and prolong the life of the product.
Page 50: Brush Cutter
Turn the bumper clockwise to wind the trimming line in (step ③ ) until around 175 mm of trimming line remains on each side. Tighten the trimmer head anti-clockwise on the spindle and remove the locking pin afterwards. Brush cutter: Changing the Blade WARNING! Do not attempt to straighten or weld a bent or cracked blade as it might break.
Page 51 Blade nut Blade retainer Outer flange Spindle Transmission Gears Lubrication The transmission gears in the gear case need be lubricated periodically with gear grease. Check the gear case grease level about every 50 hours of operation by removing the sealing screw on the side of the gear case.
Page 52: Replacing The Bar And Chain
Pole saw: WARNING! • Before cleaning or performing any maintenance, remove the battery pack from the power head. For safe and proper operation, always keep the tool and its ventilation slots clean. • When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage.
Page 53 ASSEMBLING THE NEW BAR AND CHAIN Perform the steps “Disassembling the Worn Bar and Chain” above. Lay the new saw chain in a loop on a flat surface and straighten any kinks. The cutters should face in the direction of chain rotation, if they face backwards, turn the loop over (Fig.
Page 54: Adjusting The Chain Tension
Adjusting the Chain Tension Stop the saw, allow the saw to cool and remove the battery pack before adjusting the chain tension. Loosen but do not remove the side-cover knob. Rotate the chain tensioning screw (22) using the included hex key (33) to tension the chain.
Page 55 Use only low-kickback chain on this saw. This fast-cutting chain will provide kickback reduction when properly maintained. A properly sharpened saw chain cuts through wood effortlessly, even with very little pressure. Never use a dull or damaged saw chain. A dull saw chain cutter leads to increased physical strain, increased vibration load, unsatisfactory cutting results and increased wear.
Page 56 Side Plate Angle Top Plate Left Hand Right Hand Sharpening Angles Backward Cutters Cutters More than Less than Hook Slope 30° 30° 55° 30° Correct Incorrect Incorrect Correct Incorrect Incorrect WARNING! Improper chain sharpening increases the potential of kickback. Fail- ure to replace or repair a damaged chain can cause serious injury.
Page 57: Guide-Bar Maintenance
Depth Gauge Sprocket in Clearance guide bar tip Depth Gauge Jointer 0.025" (0.6mm) Flat File Lubricating hole Guide-Bar Maintenance The bar should be cleaned every day of use and checked for wear and damage. Feathering or burring of the bar rails is a normal process of bar wear. Such faults should be smoothed with a file as soon as they occur.
Page 58 Spare parts / Replacement parts The following parts of this product may be replaced by the consumer. Spare parts are available at an authorised dealer or through our customer service. Description Model no. or Specification Trimmer head Non-metallic(nylon),2.0mm Brush cutter blade Ø250 x Ø25.4 x 1.5mm, 3Teeth Guide bar Oregon 084BXNA041...
Page 59: Troubleshooting
Troubleshooting Suspected malfunctions are often due to causes that the users can fix themselves. Therefore check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself!
Page 60: Recycling And Disposal
Recycling and disposal This symbol is known as the 'Crossed-out Wheelie Bin Symbol'. When this symbol is marked on a product or battery, it means that it should not be disposed of with your general household waste. Some chemicals contained within electrical/electronic products or batteries can be harmful to health and the environment.
Page 61: Guarantee
Guarantee related queries should be addressed to a store affiliated with the distributor from where you purchased the Erbauer power tool. Erbauer battery and charger are guaranteed for 2 years and covered by all others terms within the above guarantee.
Page 62: Availability Of Spare Parts
EN Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power...
Page 63: Declaration Of Conformity
• Cordless Multi Tool/Multi Outil Sans Fil/ Wielofunkcyjne Narzędzie Akumulatorowe/ Sculă Multifuncțională Fără Fir/ Herramienta Inalámbrica Multiusos / Ferramenta Multiusos Sem Fios • 85018 / ERT1029GMT • Serial number 00001-99999 Name and address of the manufacturer or his authorised representative: Nom et adresse du fabricant ou de son mandataire: Nazwa i adres producenta lub jego upoważnionego przedstawiciela:...
Page 64 2006/42/EC as amended Machinery Directive 2014/30/EU as amended Directive Electromagnetic compatibility 2000/14/EC as amended Outdoor Noise Directive 2011/65/EU as amended Directive Restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2006/42/CE relative aux machines 2014/30 / UE telle que modifiée Directive Compatibilité électromagnétique Directive 2000/14/CE relative aux émissions sonores extérieures Directive 2011/65/UE relative à...
Page 65 References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared: Références des normes harmonisées pertinentes appliquées, y compris la date de celles-ci, ou des autres specifications techniques, y compris la date de celles-ci, par rapport auxquelles la conformité est déclarée: Odwołania do odnośnych norm zharmonizowanych, które zastosowano, wraz z datą...
Page 66 Authorised signatory and technical file holder/signataire et responsable de la documentation technique authorisé/ podmiot uprawniony do wystawienia i adres prezechowywania dokumentacji technicznej/ semnatar autorizat și deținător al dosarului tehnic/firmante autorizado y titular del expediente tecnico/ signatário autorizado e detentor da ficha técnica Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam,...
Page 67 (UK) DECLARATION OF CONFORMITY Product • Cordless Multi Tool • 85018/ ERT1029GMT • Serial number 00001-99999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited 1 Paddington Square London W2 1GG United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer.
Page 68 Manufacturer : EN www.diy.com UK Manufacturer: To view instruction manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom EU Manufacturer: Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands...

This manual is also suitable for:

5059340904740 5059340904504 5063022544537
