- Page 1 EN 18V 33cm Cordless Grass Trimmer ERI1022GGT ORIGINAL INSTRUCTIONS 5059340904795 IMPORTANT - These instructions are for your safety. 5059340904429 Please read through them thoroughly prior to handling the product and retain them for future reference. 5063022544483 MNL_ERI1022GGT_EN_V01_241021...
-
Page 2: Table Of Contents
EN Parts 01. x1 02. x1 03. x2 04. x1 05. x1 EN You will need EN Contents Product description Safety Technical specification Before you start Functions & Settings Operation Care and maintenance Guarantee... -
Page 3: Product Description
EN Product Description 16b 16c Trimmer head Rear handle Cutting line Bump knob Safety guard Line-cutting blade Lower shaft Battery docking port Hinge and coupler 16*. Battery pack Coupler lock screw a.Battery release button Front handle b.Power bar button Front handle stop c.Power bar Trigger switch 17*. -
Page 4: Safety
EN Safety General power machine safety warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this machine. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. - Page 5 b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. c) Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock.
- Page 6 b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the machine.
- Page 7 Machine use and care a) Do not force the machine. Use the correct machine for your The correct machine will do the job better and application. safer at the rate for which it was designed. b) Do not use the machine if the switch does not turn it on and Any machine that cannot be controlled with the switch off.
- Page 8 h) Keep handles and grasping surfaces dry, clean and free from Slippery handles and grasping surfaces do oil and grease. not allow for safe handling and control of the machine in unexpected situations. Battery machine use and care a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack.
-
Page 9: Grass Trimmer Safety Warnings
Charging improperly or at temperatures the instructions. outside the specified range may damage the battery and increase the risk of fire. Service a) Have your machine serviced by a qualified repair person This will ensure that using only identical replacement parts. the safety of the machine is maintained. - Page 10 f) Wear eye, head and hand protection. Adequate protective equipment will reduce personal injury by flying debris or accidental contact with the cutting line or blade. g) While operating the machine, always wear non-slip and protective footwear. Do not operate the machine when barefoot or wearing open sandals.
- Page 11 n) When working on slopes, always be sure of your footing, always work across the face of slopes, never up or down and exercise extreme caution when changing direction. This reduces the risk of loss of control, slipping and falling which may result in personal injury.
- Page 12 t) Carry the machine with the machine switched off and away from your body. Proper handling of the machine will reduce the likelihood of accidental contact with a moving cutter, line or blade. u) Only use replacement cutters, lines, cutting heads and blades specified by the manufacturer.
-
Page 13: Vibration And Noise Reduction
f) Do not charge battery in a damp or wet location. Following this rule will reduce the risk of electric shock. g) Do not disassemble the battery and avoid mechanical damage to the battery. Risk of short circuit and fumes may be emitted. Ensure fresh air and seek medical assistance in the event of discomfort. -
Page 14: Residual Risks
7. Prolonged use of the product exposes the user to vibrations that can cause a range of conditions collectively known as hand-arm vibration syndrome (HAVS) e.g. fingers going white; as well as specific diseases such as carpal tunnel syndrome. To reduce this risk when using the product, always wear protective gloves and keep your hands warm. - Page 15 1. Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. 2. Injuries and damage to property due to broken accessories or the sudden impact of hidden objects during use.
- Page 16 Symbols On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations. Familiarise yourself with them to reduce hazards like personal injuries and damage to property. Volt, (direct current voltage) /min or min Per minute Milliampere per hour Millimetre...
- Page 17 Wear a mask Do not install round cutting blades. Do not use metal blades. WARNING – Disconnect battery before maintenance Switch the product off before assembly, cleaning, adjustments, maintenance, storage and transportation. Objects thrown by the product could hit the user or other bystanders. Always ensure that other people and pets remain at a safe distance from the product when it is in operation.
- Page 18 The product complies with the applicable Your product European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation Cordless Grass Trimmer: ERI1022GGT ER = Brand name (Erbauer) I = 18V Lithium-Ion 1022 = Serial number...
-
Page 19: Cutting Line
1.2 kg NOTE: This equipment is compatible with the Erbauer EXT 18V/36V dual-voltage lithium-ion battery range, and Erbauer EXT 18V lithium-ion battery range. For optimal performance, use 1X 18V/36V 6.0Ah/3.0Ah battery, or 1X 18V 5.0Ah battery. Charger for battery pack (may not be included) >... -
Page 20: Before You Start
The sound value(s) have been determined according to noise test code given in EN IEC 62841- 1 and EN ISO 11806-1 using the basic standards EN ISO 22868 and EN ISO 3744.The sound intensity level for the operator may exceed 80 dB(A) and ear protection measures are necessary. The declared total vibration value(s) and the declared noise emission value(s) have been measured in accordance with a standard test method and may be used for comparing one tool with another;... - Page 21 EN Assembly WARNING! The product must be fully assembled before operation! Do not use a product that is only partly assembled or assembled with damaged parts! WARNING! Disconnect the battery pack from the machine before making any assembly, adjustments, changing accessories, cleaning, or storing machine. Such preventive safety measures reduce the risk of starting the machine accidentally.
-
Page 22: Mounting The Guard
Mounting and adjusting the front handle Push the front handle (7) onto the shaft, mount the lock bolt, and tighten it by using the wing nut (Fig. 3). Adjust the front handle position to make sure your front arm is straight when using the trimmer before you fix the handle firmly. -
Page 23: Battery Pack
Battery pack Attaching / releasing the battery pack Slide the battery pack into the battery docking port (15) until it is securely locked in position. Depress the battery pack release button (16a) to release and slide the battery pack out from your tool. -
Page 24: Battery Storage
Battery storage WARNING! Always charge the battery pack before storage! Please charge the battery pack to 3 bars on the battery light indicator. If the tool will not be used for long periods of time, charge the battery pack every 3-6 months. It is important to disconnect the charger from the power supply after charging has finished. -
Page 25: Functions & Settings
EN Functions & settings Intended use This grass trimmer ERI1022GGT is designated with a rated voltage of 18 V . It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. - Page 26 WARNING! The product will continue to work for some time even after the motor has been switched off! Wait until it comes to a complete stop before you put the product down! WARNING! Always remove the battery pack from the grass trimmer during work breaks and after finishing work.
-
Page 27: Operation
EN Operation General operation Check the product, its battery pack and charger as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. Double check that accessories or attachments are properly fixed. Always hold the product by its handles. - Page 28 Take regular rest periods during operation. NOTE: The trimmer head is parallel to the ground at a proper cutting distance without operator bending over. Avoid pressing it against the ground as this can ruin the lawn and damage the product. Move the product with a slow regular arc from left to right before moving it back to the starting position and trimming the next area (Fig.
-
Page 29: Replacing The Cutting Line
Adjusting cutting line length The grass trimmer allows the operator to release more cutting line (2) without stopping the motor. As line becomes frayed or worn, additional line can be released by lightly tapping the bump knob (13) on the ground while operating the trimmer (Fig. 10). WARNING! Do not remove or alter the line-cutting blade assembly. -
Page 30: Operating Hours
Push the bump knob (13) down while pulling on both ends of the line to manually advance the line and to check for proper assembly of the trimmer head. Cutting line maintenance Should the cutting line breaks from the eyelet or the cutting line is not released when the trimmer head is tapped, you will need to remove the remaining cutting line from the trimmer head and follow the steps below to reload the line. -
Page 31: After Use
After use Switch the product off and move the grass trimmer away from cutting area. Remove the battery pack and let the product cool down. Check, clean and store the product as described below. -
Page 32: Care And Maintenance
EN Care and maintenance The golden rules for care WARNING! Always switch the product off, remove the battery pack and let the product cool down before performing inspection, maintenance and cleaning work! Keep the product clean. Remove debris from it after each use and before storage. Regular and proper cleaning will help ensure safe use and prolong the life of the product. -
Page 33: Replacing The Line Spool
Replacing the line spool WARNING! Always use original spare parts for replacement. Do not attach any other type of cutting device! Remove the battery pack. Press the release tabs and remove the cover of the trimmer head by pulling it straight out (Fig. - Page 34 With one hand holding the trimmer, use another hand to grasp the cover and align the slots in the trimmer head case with the release tabs. Press the cover until it snaps into place, at which time you will hear a distinct click sound (Fig. 17). Follow the instructions in the “Replacing the cutting line”...
-
Page 35: Troubleshooting
Transportation Switch the product off and remove the battery pack. Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles. Secure the product to prevent it from slipping or falling over. Troubleshooting Suspected malfunctions are often due to causes that the users can fix themselves. Therefore check the product using this section. -
Page 36: Recycling And Disposal
Recycling and disposal This symbol is known as the 'Crossed-out Wheelie Bin Symbol'. When this symbol is marked on a product or battery, it means that it should not be disposed of with your general household waste. Some chemicals contained within electrical/electronic products or batteries can be harmful to health and the environment. -
Page 37: Guarantee
Guarantee related queries should be addressed to a store affiliated with the distributor from where you purchased the Erbauer power tool. Erbauer battery and charger are guaranteed for 2 years and covered by all others terms within the above guarantee. -
Page 38: Availability Of Spare Parts
EN Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power... - Page 39 • Cordless Grass Trimmer/ Coupe-bordure Sans Fil/ Bezprzewodowe Nożyce Do Trawy/ Trimer Pentru Iarbă Fără Fir/ Cortacésped De Filamento Inalámbrico/ Aparador De Relva Sem Fios • 81002.1/ERI1022GGT • Serial number 00001-99999 Name and address of the manufacturer or his authorised representative: Nom et adresse du fabricant ou de son mandataire: Nazwa i adres producenta lub jego upoważnionego przedstawiciela:...
- Page 40 2006/42/EC as amended Machinery Directive 2014/30/EU as amended Directive Electromagnetic compatibility 2000/14/EC as amended Outdoor Noise Directive 2011/65/EU as amended Directive Restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2006/42/CE relative aux machines 2014/30 / UE telle que modifiée Directive Compatibilité électromagnétique Directive 2000/14/CE relative aux émissions sonores extérieures Directive 2011/65/UE relative à...
- Page 41 References to the relevant harmonised standards used or references to the other technical specifications in relation to which conformity is declared: Références des normes harmonisées pertinentes appliquées, y compris la date de celles-ci, ou des autres specifications techniques, y compris la date de celles-ci, par rapport auxquelles la conformité est déclarée: Odwołania do odnośnych norm zharmonizowanych, które zastosowano, wraz z datą...
- Page 42 Authorised signatory and technical file holder/signataire et responsable de la documentation technique authorisé/ podmiot uprawniony do wystawienia i adres prezechowywania dokumentacji technicznej/ semnatar autorizat și deținător al dosarului tehnic/firmante autorizado y titular del expediente tecnico/ signatário autorizado e detentor da ficha técnica Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam,...
- Page 43 (UK) DECLARATION OF CONFORMITY Product • Grass Trimmer • 81002.1/ERI1022GGT • Serial number 00001-99999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited 1 Paddington Square London W2 1GG United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer.
- Page 44 Authorised signatory and technical file holder: Kingfisher International Products Limited 1 Paddington Square London W2 1GG United Kingdom David Awe Group Quality Director On:30/07/2024...
- Page 48 Manufacturer : EN www.diy.com UK Manufacturer: To view instruction manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom EU Manufacturer: Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands...
