- Page 1 Installer Manual Water Source Heat Pump P a g e Water Source Heat Pump - Installer Manual...
- Page 2 Marking CGS-72 is CE marked. The CE marking means that Zephair ensures that the product meets all regulations that are placed on it based on relevant EU directives. The CE mark is obligatory for most products sold in the EU, regardless where they are made.
-
Page 3: Safety Information
Packaging materials, such as nails and Please report to your supply authority or obtain their other metal or wooden parts may cause injuries. consent before connecting this equipment to the Do not wash the CGS-72 may receive an electric power supply system. shock Before electric... -
Page 4: Key Components
Key Components Discription Pics Item Condenser Tube in shell heat exchanger Compressor Scroll compressor Evaporator Plate to plate heat exchanger Expansion valve AC contactor Schneider and thermal relay Controller Multiple function controller High pressure switch 3.6/4.4MPa Low pressure switch 0.15/0.56MPa P a g e Water Source Heat Pump - Installer Manual... -
Page 5: Unit Design
Unit Design 1. Tube in shell evaporator 2. Water Outlet 4. Source side water outlet Plate to plate heat exchanger 5. Filter 6. Water inlet 7. Source side Water inlet 8. Liquid storage 9. Electrical expansion valve 10. Electrical box 11. - Page 6 P a g e Water Source Heat Pump - Installer Manual...
-
Page 7: Wiring Diagram
Wiring diagram Voltage phase detection Outlet gas 2 temp Outlet gas 1 temp Module outside inlet water temp Module inside inlet water temp Module outside outlet water temp Module inside outlet water temp System ambient temperature System outlet water temp* System inlet water temp* Linkage* Outside water flow switch*... -
Page 8: Temperature Sensor Installation
Temperature Sensor Installation TEMPERATURE PROBE MUST Note INSTERTED INTO THE PROBE POCKET, OR make sure reliable DRY POCKET OF THE CYLINDER. solid contact between the probe and cylinder side, the thermal paste shall be The temperature probe is used to monitor the used. - Page 9 6. User Registration – Guarantee Card Please spend time on registering your new CGS-72 as a required part to the Warranty activation, and complete it online. Customer Data: First Name: Last Name: Address: Postal Code: City / Country: Email: Contact Tel:...
- Page 10 Leave the disposal of the packaging to the installer who installed the product or to Dispos special waste stations. Do not dispose of used products with normal household waste. It must be disposed of at a special waste station or dealer who provides this type of service. Improper disposal of the product by the user results in administrative penalties in accordance with current legislation.
