- Page 1 CGK/C-22 380V/50Hz/3ph (Product No: A22223) Installation manual Air source heat pump （heating + hot water) PCB No: CG248027 Operating panel No: CG248028...
-
Page 2: Safety Precaution
Safety precaution To avoid electrical shock, make sure to disconnect power supply 1minute or more before operating the electrical part. Even after 1minute, always measure the voltage at the terminals of main circuit capacitors or electrical parts and, before touching, make sure that those voltages are lower than the safety voltage. - Page 3 To know the product from exterior Electric box Air inlet Air outlet Water outlet Cable hole Water inlet High pressure gauge Low pressure gauge...
- Page 4 Important parts in heat pump Filter...
- Page 5 Important parts in heat pump...
- Page 6 Important parts in heat pump Code Name Remarks Outlet water temp sensor Connect to port CN11 on PCB Floor heating water temp Connect to port CN12 on PCB sensor Outlet gas temp sensor of Connect to port CN8 on PCB compressor Inlet gas temp sensor of Connect to port CN9 on PCB...
- Page 7 Heat pump size 1115 1115...
-
Page 8: Installation Diagram
Installation diagram Room thermostat Special valve for floor heating loop AC water Water separator tank Hot water water outlet tank NRV3 Water collector Connect to Connect to city water city water NRV1 NRV2 Floor heating Heat pump... -
Page 9: Introduction Of The System
Introduction of the system 1. Hot water tank temp sensor (T1) The sensor should be put in the sensor tube which is installed in hot water tank. 2. Floor heating water temp sensor (T2) 2.1 Floor heating temp sensor has been installed on the inlet water pipe inside heat pump before leave factory. - Page 10 Introduction of the system 5. Three way valve (3WV): 5.1 Three way valve is controlled by heat pump controller. 5.2 When room linkage switch is connected: hot water is priority, means if both hot water side and floor heating side need be heated, the three way valve will change to hot water side, until hot water tank reach preset temp, then the valve will change to floor heating side.
- Page 11 Introduction of the system 8. About hot water tank 8.1 Because the three way valve, a coil heat exchanger must be installed in hot water tank. Otherwise, the sanitary hot water will be mixed with floor heating water. 8.2 The coil heat exchanger capacity should be about 18KW. And the inner diameter of coil should be ≥DN25.
- Page 12 Heat pump installation notes The heat pump must be installed in open space. Normally is installed on the roof of house. The unit should be placed in dry and well-ventilated environment. If the environment is humid, electronic components may get corroded or short circuit. Heat pump mustn’t be installed in the environment where corrosive, volatile, or flammable liquid or gas exists.
-
Page 13: Installation
2. Installation 2.4 Distances to barrier and ground ≥0.5 ≥1 Left Right Ground ≥0.5 ≥2 Front Back Ground... - Page 14 Other notes of installation Heat pump must be installed on flat concrete blocks or a raised concrete platform, or steel bracket. Between heat pump and basic or bracket, at leas 4pcs anti-shock pads should be placed Anti-shock pad Steel bracket Concrete basic Expansion bolt 3) Before make basic or bracket, please check heat pump dimension...
-
Page 15: Wiring Diagram
Wiring diagram Crankcase heater motor 4-way valve Transformer room linkage Primary Linkage OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 Fan motor Water pressure switch capacitance Water flow switch AC-N High pressure switch high pressure switch Electric expansion valve Low pressure switch low pressure switch Instant + cycle 1 phase... - Page 16 Terminal details of wiring F a c t o r y s i d e I n s t a l l e r s i d e 1. Floor heating valve: When floor heating side work, 3-way valve coil get electricity. The terminal supply 220V/1ph voltage.
-
Page 17: Water Flow Switch
5. Floor heating electric heater: Max carrying current is 6A. 220V/50Hz/1ph. (This terminal is optional, it can be chassis electric heater of heat pump too. When place your order from factory, If select there is chassis electric heater, then floor heating electric heater will not be included, but will change to chassis electric heater) 6. -
Page 18: Analog Signal Input
Analog signal input CN2 CN3 CN6 CN8 CN9 CN11 CN12 CN13 CN14 Communication: connect operating panel Tank: Hot water tank temp sensor (installer should install the probe in tank) Outlet water: Outlet water temp sensor (has been installed in heat pump) Air HE coil: Source side (air) heat exchanger coil temp sensor (has been installed in heat pump) Outlet gas: outlet gas temp sensor of compressor (has been installed in heat pump) - Page 19 Power supply terminal block Yellow Green Red Blue A B C N Yellow Green Red Blue A.B.C size: 1.5mm2. N: 1.5mm2 Y/G: 1.5mm2 Air circuit breaker: 32A...
-
Page 20: Room Thermostat
Wiring diagram of all room thermostat control water pump (P2) For floor heating system, if want P2 (heating system water pump) stops when all floor heating loops needn’t work, can connect all the room thermostat to P2h, the wiring diagram as below. Water separator Floor heating water separator... - Page 21 Wiring diagram of all room thermostat connect to room linkage terminal If want heat pump only performs at hot water side when floor heating side no need, can connect all room thermostats to “Room linkage” terminal. Water separator Floor heating water separator Room 20C°...
