Futon ST LN NRW CAB TMBR Assembly Instructions

Assembly Instructions
Storage - Oak Rounded Leaning
Narrow Tambour Cabinet
ROPO no:
PLEASE READ THESE INSTRUCTIONS VERY CAREFULLY BEFORE
YOU BEGIN,TO ENSURE THAT YOUR FUTON COMPANY PRODUCT
WILL GIVE YOU MANY YEARS OF SATISFACTION
Thank you for buying a Futon Company product.
We are constantly striving to improve everything we do, but occasionally mistakes
do occur. In the unlikely event that you find any part missing, please call your
nearest Futon Company store and we will arrange for the despatch of an immediate
replacement. Please keep all packaging until you have checked every part and
assembly of your Futon Company product is complete.
Version number: Product code: ST LN NRW CAB TMBR
1 Right side rail x 1
2 Left side rail x 1
Small shelf x 1
3
4 Medium shelf x 1
5 Large shelf x 1
Cabinet x 1
6
7
Cabinet shelf x 1
a
Small Wooden Dowel x 6
d
Anti-slip pad x 4
h
Nut x 2
Date: 26/11/24
l Wooden Cap x 2
Parts Checklist
Please count and check every component very carefully before you begin
2
3
4
5
Fittings Checklist
Please count and check every component very carefully before you begin
b
m6 x 20 Allen Head Bolt x 12
e
f Bolt x 2
Shelf Support x 4
j
Barrel Nut x 2
Small Spanner x 1
i i
* Cross head and flat head Screwdriver
also required for assembly
1
3
4
5
6
7
c
Allen Key X 1
g
Pressure Plate x 2
k k m6 x 60 Allen Head Bolt x 2
