Futon ST LN MIR DRWS V4 Assembly Instructions

Assembly Instructions
Bedroom - Leaning Oak
Mirror Drawers (V4)
ROPO no:
PLEASE READ THESE INSTRUCTIONS VERY CAREFULLY BEFORE
YOU BEGIN,TO ENSURE THAT YOUR FUTON COMPANY PRODUCT
WILL GIVE YOU MANY YEARS OF SATISFACTION
Thank you for buying a Futon Company product.
We are constantly striving to improve everything we do, but occasionally mistakes
do occur. In the unlikely event that you find any part missing, please call your
nearest Futon Company store and we will arrange for the despatch of an immediate
replacement. Please keep all packaging until you have checked every part and
assembly of your Futon Company product is complete.
Version number: 2 Product code: ST LN MIR DRWS V4
1 Mirror with leg x 1
Top x 1
2
Right Side Panel x 1
3
4 Left Side Panel x 1
5 Back Panel x 1
21 Base Rail x 2
6 Right Side of Drawer A (77mm) x 1
Left Side of Drawer A(77mm) x 1
7
8
Back of Drawer A (77mm) x 1
9 Bottom of Drawer A (275mm) x 1
10
Front of Drawer A (110mm) x 1
11 Right Side of Drawer B (115mm) x 1
12 Left Side of Drawer B (115mm) x 1
13
Back of Drawer B (115mm) x 1
14 Bottom of Drawer B (295mm) x 1
15
Front of Drawer B (145mm) x 1
16
Right Side of Drawer C (145mm) x 1
17
Left Side of Drawer C (145mm) x 1
18 Back of Drawer C (145mm) x 1
Date: 22/11/23
19
Bottom of Drawer C (310mm) x 1
20 Front of Drawer C (180mm) x 1
Parts Checklist
Please count and check every component very carefully before you begin
5
4
17
1
3
2
21
21
Drawer A
6
8
9
10
7
Drawer B
11
13
14
12
15
Drawer C
16
18
19
20
