HARDWARE
HARDWARE
A
BOLT M6 X 60mm - 16 pcs
B
BOLT M6 X 45mm - 8 pcs
C
BARREL NUT - 16 pcs
D
WOOD SCREW - 4 pcs
E
WOOD BUTTON - 8 pcs
F
ALLEN KEY - 1 pc
G
WOODEN DOWEL - 32 pcs
Page 1 of 4
SESAMO BED
SESAMO BED
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
Before assembling your Day Bed, please read through these instruction
carefully, familiarising yourshelf with the different parts.
Assembling by Adult
SOFA
FRONT VIEW
Phillips Head
Screwdriver
Costumer Supplied
LOUNGE
BED
A A
TO
TO
Advertisement
Table of Contents
Related Manuals for Futon SESAMO BED
Summary of Contents for Futon SESAMO BED
- Page 1 SESAMO BED SESAMO BED ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Before assembling your Day Bed, please read through these instruction carefully, familiarising yourshelf with the different parts. Phillips Head HARDWARE HARDWARE Screwdriver Assembling by Adult Costumer Supplied BOLT M6 X 60mm - 16 pcs...
- Page 2 PARTS LIST PARTS LIST STEP 1 STEP 1 BOX 1 0F 2 FRONT LEG 1 PC Attach Slat Arm Rails (8) and the Bottom Arm Rails (9) to the Left,Right HARDWARE 1 BOX BACK LEG 1 PC Arm Rails (6)(7) as shown. Using Bolts (A) and Barrel Nuts (C). SIDE RAIL 2 PCS Tighten with Allen Key (F).
- Page 3 STEP 2 STEP 2 STEP 3 STEP 3 Attach Side Rails (3) and the Stretcher (4) to the Front, Back Legs(1)(2) Insert the Arm Rest into the locator hole will receive Plastic Runner. as shown. Using Bolts (A) and Barrel Nuts (C). Insert one end first, then gently the other end into position.
- Page 4 Lift up Pull Lounge to Bed position. BACK VIEW Phillips Head Screwdriver Your Sesamo Bed is now ready for use. We recommend that you recheck that all screws are tightened. Assembling by Adult Bolt M6 X 45mm Cross Dowel Allen Key...
