Assembly Instructions
Sofa Bed - Birch Noah Bifold
Ropo no:
Please read these instructions very carefully before
you begin to ensure that your Futon Company sofa bed
will give you many years of satisfaction
Thank you for buying a Futon Company product.
We are constantly striving to improve everything we do, but occasionally mistakes
do occur. In the unlikely event that you find any part missing, please call your
nearest Futon Company store and we will arrange for the despatch of an immediate
replacement. Please keep all packaging until you have checked every part and
assembly of your Futon Company product is complete.
version number:1
product code: SB3 NOAH BCH SET
1
2
4 Back panel x1
Fittings Checklist
Please count and check every component very carefully before you begin
a Bolt x4
a Bolt x4
d Pressure Plate x4
Date: 11/02/24
h Dowel x8
Part Checklist
Please count and check every component very carefully before you begin
Cross Rail x 2
LH Side arm x 1
b Allen Head Bolt x4
e Pin X2
f
i Allen Key x1
3
RH Side arm x 1
5 Seat panel x1
c Runner Wheel x4
g Nut x4
Small Washer x4
j Small Spanner x1
