Summary of Contents for Habitat Faro 2013112
- Page 1 Faro Lounge Chair Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 11/10/22...
- Page 2 Safety and Care Advice Product Details Faro Woven Lounge Chair 2013112 Black Faro Woven Lounge Chair 1950991 Natural IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. Assemble the item as close Keep children and animals We do not to its final position (in the same away from the work area, small recommend the parts could choke if swallowed.
- Page 3 Fittings (Shown to scale) Bag 1 Ø10*15mm Nut x 8 M6*50mm Bolt x 8 M4 Alley Key x 1 40x20mm Foot Pad x 4 Ø8*30mm Wooden Dowel x8...
-
Page 4: Tools Required
Tools required Phillips screwdriver (small & medium) Phillips screwdriver (small & medium) - Page 5 Panels Right Leg Frame x 1 Left Leg Frame x 1 ( 770 x 670mm) (770 x 670mm) Back x 1 ( 560 x 340mm) Seat x 1 ( 560 x 540mm)
- Page 6 Ø10*15mm Nut x 8 M6*50mm Bolt x 8 40x20mm Foot Pad x 4 M4 Alley Key x 1 Ø8*30mm Wooden Dowel x8 Ø10*15mm Nut x 8 M6*50mm Bolt x 8 40x20mm Foot Pad x 4 M4 Alley Key x 1 Ø8*30mm Wooden Dowel x8...
- Page 7 Assembly is complete.
