- Page 1 Faro Bar Stool Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - Sep 2023...
- Page 2 ● Regularly check and ensure that all bolts and fittings are tightend properly. • Maximum user weight 100kg ● This product is compliant EN12520 Habitat, Argos limited and Sainsbury’s Supermarkets Ltd, London EC1N 2HT, UK. Argos(N.I.) Ltd and Sainsbury’s (NI) Ltd. Forestside Shopping Centre, Upper Galwally, Belfast, BT8 6FX, UK...
- Page 3 Fittings (Shown to scale) Bag 1 Spring Washer x 12 Flat Washer x 12 M6x50mm Bolt x 12 Ø10x15mm Nut x 12 Ø8x40mm Wooden Dowel x 12 25x15mm Felt pad x 4 M4 Alley Key x 1...
-
Page 4: Tools Required
Tools required Phillips screwdriver (small & medium) - Page 5 Parts Right Leg Frame x 1 Left Leg Frame x 1 (1020 x 560mm) (1020 x 560mm) Back x 1 ( 370 x 200mm) Seat x 1 425 x 370mm) Support Rail x 2 370 x 35mm)
- Page 6 Spring Washer x 12 M6x50mm Bolt x 12 Flat Washer x 12 Ø8x40mm Wooden Dowel x 12 Ø10x15mm Nut x 12 Ø8x40mm Wooden Dowel x 12 25x15mm Felt pad x 4 M4 Alley Key x 1 5 x2 M6x50mm Bolt x 6 Spring Washer x6 Flat Washer x6 Ø10x15mm Nut x6...
- Page 7 M6x50mm Bolt x 6 Spring Washer x6 Flat Washer x6 Ø10x15mm Nut x6 25x15mm Felt pad x 4...
- Page 8 Turn Product 100% Warning! Please do fully tighten all the bolts in this step. Assembly is complete.
