Assembly Instruction Manual
Please read instructions thoroughly before beginning assembly.
Check boxes carefully for contents listed. Some parts are packaged inside of others.
Assemble on a clean, flat, non-abrasive surface to prevent scratching.
In the event of missing or damaged parts please call or email our customer service department at
115 Vision Parkway
P.O. Box 122
Sheboygan Falls, WI 53085
the contact info below.
Tools Required
-Battery or Electric Drill (#2 phillips bit)
-Hammer or Rubber Mallet (Recommended)
-Shovel or Post Hole Digger (Recommended)
-PVC, Super or Crazy Glue
QUESTIONS? COMMENTS? CONTACT US!
Sunburst Trellis
11148
Model#
W221122-A5080
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
www.dura-trel.com
sales@dura-trel.com
1-877-258-6020
Advertisement
Related Manuals for DuraTrel 11148
Summary of Contents for DuraTrel 11148
- Page 1 Sunburst Trellis 11148 Model# W221122-A5080 *W201121-A2040* *W201121-A2040* *W201121-A2040* *W201121-A2040* *W201121-A2040* *W201121-A2040* Assembly Instruction Manual Please read instructions thoroughly before beginning assembly. Check boxes carefully for contents listed. Some parts are packaged inside of others. Assemble on a clean, flat, non-abrasive surface to prevent scratching.
- Page 2 62" 28" Sunburst Trellis - Page 2...
- Page 3 Insert lattice (part 7) through 27½" center cross rail (part 4). Insert one end of lattice into 27½" bottom cross rail (part 3) and other end into 27½" top cross rail (part 5). Insert one end of three cross rails into corresponding holes in left post (part 1).
-
Page 4: Ground Anchor Installation
Ground Anchor Installation Option 1 (soft ground) Slide one ground anchor (part 12) into bottom of each post until it meets bottom cross rail. Using two 1” self- tapping screws per post, screw the post to ground anchor using the pilot holes for guides. Using ground anchor installation layout drawing, dig holes approximately 12”... - Page 5 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
