Assembly Instruction Manual
Please read instructions thoroughly before beginning assembly.
Check boxes carefully for contents listed. Some parts are packaged inside of others.
Assemble on a clean, flat, non-abrasive surface to prevent scratching.
In the event of missing or damaged parts please call or email our customer service department at
115 Vision Parkway
P.O. Box 122
Sheboygan Falls, WI 53085
the contact info below.
Tools Required
-Battery or Electric Drill (#2 phillips bit)
-Tape Measure
-Hammer or Rubber Mallet (Recommended)
-Shovel or Post Hole Digger (Recommended)
QUESTIONS? COMMENTS? CONTACT US!
Bakersfield Arbor
11197
Model#
W221122-A5080
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
*W201121-A2040*
www.dura-trel.com
sales@dura-trel.com
1-877-258-6020
Advertisement
Related Manuals for DuraTrel Bakersfield Arbor 11197
Summary of Contents for DuraTrel Bakersfield Arbor 11197
- Page 1 Bakersfield Arbor 11197 Model# W221122-A5080 *W201121-A2040* *W201121-A2040* *W201121-A2040* *W201121-A2040* *W201121-A2040* *W201121-A2040* Assembly Instruction Manual Please read instructions thoroughly before beginning assembly. Check boxes carefully for contents listed. Some parts are packaged inside of others. Assemble on a clean, flat, non-abrasive surface to prevent scratching. In the event of missing or damaged parts please call or email our customer service department at the contact info below.
- Page 2 72" 82" 78" 57" 28" Bakersfield Arbor - Page 2...
- Page 3 Lay out one right post (part 2). Starting at bottom, insert one top/bottom cross rail (part 3) and four center cross rails (part 4). Insert three vertical rails (part 5) through center rails and into bottom rail. Insert second top/bottom rail (part 3) into post and slide vertical rails into top rail.
- Page 4 Using ¾" screws, screw together BOTTOM 3 spots of arbor panel. DO NOT screw together top spot of each post. Be sure that all parts are fully inserted into posts before securing. REPEAT steps 1-5 to complete the other side panel.
- Page 5 Slide three overhead rails (part 8) through holes each top cross rail. Overhead rails should stick out equally on both sides. Using remaining ¾" screws, screw remaining arbor panel spots and screw arbor panels to arbor top rails. Using super glue tube, glue four arbor top end caps onto ends of arbor top rails.
-
Page 6: Ground Anchor Installation
Ground Anchor Installation *Ground anchors are made of recycled material-color will vary* Option 1 (soft ground) Slide one ground anchor (part 10) 4" into bottom of each post. Using two 1” self- tapping screws per post, screw the post to ground anchor using the pilot holes for guides. - Page 7 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
