General Information
PLEASE READ THROUGH BEFORE BEGINNING ASSEMBLY.
IMPORTANT: Check boxes for Contents Listed
Check inside of parts as some parts are packaged
inside of others
In the event of missing, damaged or defective parts
please call our customer service dept. at 1-877-258-6020
When assembling components, place on a clean, flat
non-abrasive surface to avoid scratches
Tools Required
... Battery or Electric Drill
... Tape Measure
... Hammer or Rubber Mallet
... Shovel or Post Hole Digger
with #2 phillips bit
(recommended)
(recommended)
Courtyard Arbor
11111
Model#
Part #
1
4" sq. x 84" Left Post
2
4" sq. x 84" Right Post
3
1½ x 4 x 29½" Top/Bottom Cross Rail
4
1½ x 4 x 29½" Center Cross Rail
5
⅝ x 61" Tube
6
1½ x 4 x 84" Arbor Top Rail
7
⅞ x 1½ x 84" Arbor Top Overhead Rail 1
8
2" sq. x 26¾ Arbor Top Cross Rail
9
4" sq. Gothic Cap
10
24" Steel Ground Anchor (U-shaped)
11
Hardware Bag
4" End Cap
⅞ x 1½" End Cap
1¼" Painted Screw
#8 - 1" Painted Self Tapping Screw
Super Glue Tube
150 Birch Road
P.O. Box 122
Sheboygan Falls, WI 53085
Assembly Instructions
Description
Box#
1
1
2
1
1
1
2
2
1
2
(includes:)
1-877-258-6020
www.dura-trel.com
sales@dura-trel.com
Qty
2
2
4
2
10
2
2
5
4
4
1
4
4
34
8
1
1
Advertisement
Table of Contents
Related Manuals for DuraTrel Courtyard Arbor 11111
Summary of Contents for DuraTrel Courtyard Arbor 11111
- Page 1 Courtyard Arbor 11111 Model# Assembly Instructions Part # Description Box# 4" sq. x 84" Left Post 4" sq. x 84" Right Post 1½ x 4 x 29½" Top/Bottom Cross Rail 1½ x 4 x 29½" Center Cross Rail ⅝ x 61" Tube 1½...
- Page 2 Warranty Statement 20 Year Guarantee Please call manufacturer direct with questions concerning missing or defective parts at Toll Free: 877-258-6020. Dura-trel, Inc. products are warranted to be free from manufacturing defects resulting in delaminating, peeling, flaking, corroding, cracking, crazing, or extreme amounts of fading or bleaching causing the PVC to change to its natural color for a period of 20 years from the date of purchase.
- Page 3 Lay out one left post (part 1). Insert one top/bottom cross rail (part 3) into bottom hole of post. Insert one center cross rail (part 4) into middle hole of post. Slide five 61" tubes (part 5) through holes of center cross rail and into bottom cross rail.
- Page 4 Set both arbor panels on end with screw pilot holes facing outside of arbor. Insert ends of each 84" arbor top rail (part 6) through top routed hole in each post. Make sure 2" sq. routed holes face one another. Gently separate tops of each arbor panel few inches.
- Page 5 ARBOR INSTALLATION Option 1 Slide one 24” steel u-channel ground anchor (part 10) into bottom of each post. Slide ground anchor until it meets bottom cross rail. Using 1” self-tapping white-head screw fasten post to ground anchor. Using ground anchor installation layout drawing, dig holes approximately 16”...
