Dunelm Mason Buttoned Instructions Manual page 4

Parts and Fittings
Fittings to scale (actual size）
REF Dimensions
Bolt
A
M8*30mm
Bolt
B
M8*50mm
Nut
C
M8
Flat washer
D
8*22mm
Spring washer
8*12mm
E
Bolt
F
M6*50mm
Nut
G
M6
Allen key
H
M8
Allen key
I
M6
Spanner
J
M8
Spanner
K
M6
Double plastic cap
L
Single plastic cap
M
mm 10 20 30 40 50 60 70 80 90 100
QTY
16
6
4
14
14
2
2
1
1
1
1
Double:
15
King:
16
Double:
30
King:
32
