DEAR CUSTOMER
Thank you for purchasing your new piece of furniture from Dunelm.
We put a lot of effort in the design and construction of our products to ensure they set
the standard for quality, durability and ease of assembly.
If for any reason you feel we haven't lived up to the high standards we set ourselves,
please don't hesitate in contacting us on 08451 656565 where our team will be very
keen to understand what has gone wrong and, more importantly, put it right.
DEAR CUSTOMER
The next step...
There is no need to feel daunted by the number of parts and fittings in front of you, we have
compiled this straight forward, step-by-step guide to make sure that assembling your furniture
is as easy as 1, 2, 3.
Before you begin, we advise that you check that you have everything you need to get started.
TOP TIP
Find a space to spread these out across the floor before you begin
assembling them. Lay each panel down in position, ready to build.
It is recommended that two people assemble this product together.
The full list of furniture parts, fixtures and fittings, as well as the tools you will need for assembly,
can be found on page 2 and 3 of this manual.
TOP TIP
Identify all of the fittings, make sure that you have them all prepared
and familiarise yourself with each component, to make things easier
when you are putting it all together.

Safety and Care Advice

IMPORTANT - The first step you need to take is to ensure your safety!
Please take the time to read and understand these instructions before assembling your
furniture.
Keep children and animals away from the assembly area.
This furniture contains small parts that could cause choking if swallowed.
Keep all plastic wrapping materials way from children to avoid danger of suffocation.
Ensure that all packaging is disposed of carefully and responsibly.
Make sure that you allow enough space to move around when assembling your furniture.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30151830 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dunelm 30151830

  • Page 1 DEAR CUSTOMER Thank you for purchasing your new piece of furniture from Dunelm. We put a lot of effort in the design and construction of our products to ensure they set the standard for quality, durability and ease of assembly.
  • Page 2 Parts & Fittings for the Indiana 4 Drawer Chest White (30151830), Black (30152651) Panels - exploded view Panels - plan view Rail 995 x 78mm X 3 Top 995 x 388mm L/H drawer side R/H drawer side Left side Right side...
  • Page 3 Fittings 15mm 30mm 12mm Cam pin x 18 Euro screws x 16 Metal cam x 10 Wooden dowel x 10 Metal cam x 8 Drawer peg x 16 Panel pins x 30 Drawer wedge x 16 Handle x 4 Handle screw x 8 Soft close runner x 4 pair Tools required Cross slot screwdriver...
  • Page 4 Front edge Note: Insert metal dowels as far as shown. Front edge...
  • Page 5 Front edge Ensure the cam is pressed full y into the hole and arrow pointing towards the short edges Rear edge 10 mm...
  • Page 6 Front edge Front edge Cam lock in open Cam lock in closed position position Front edge Front edge These panels must be supported until the next step Cam lock in open Cam lock in closed position position...
  • Page 7 Front edge Front edge Cam lock in open Cam lock in closed position position Two people required to turn unit over Back of unit Front edge Front edge...
  • Page 8 Front edge Two people required to stand unit upright Ensure the cam is pressed full y into the hole and arrow pointing towards the short edges...
  • Page 9 Note: Insert metal dowels as far as shown. Cam lock in open Cam lock in closed position position...
  • Page 10 BEFORE ATTACHING THE HANDLES REMOVE THE PROTECTIVE FILM FROM THE FRONT AND EDGES OF THE DRAWER FRONTS LEFT AND RIGHT DRAWER RUNNERS...
  • Page 11 Drop drawers onto the runners and position the pegs into the holes at the back (FIG A) and on the underside of the drawer sides (FIG B). SECOND FIRST FIG. B UNDERNEATH DRAWER FIG. A REPEAT PROCEDURE FOR THE REMAINING DRAWERS...
  • Page 12 Lift green clip up and push towards the runner (arrowed below), this secures the drawer onto the drawer runner and prevents the drawer from popping out. TO SECURE DRAWER UNDERNEATH REPEAT PROCEDURE DRAWER FOR THE REMANING DRAWERS Nearly there! TO ADJUST TO RELEASE DRAWER DRAWER HEIGHT FIRST SECOND...
  • Page 16 From time to time check that there are no loose screws on this unit. This product should not be discarded with household waste. Take to your local authority waste disposal centre. Finally, we hope you enjoy your furniture for many years to come and thanks again for your purchase. dunelm.com...
