Please read these instructions carefully and check the contents of the pack before attempting to
Pack Contents
Pack Content
Pole
Serrated
Length
Bay Pole
400cm
2
Should any component be missing, please call the Customer Care Department on
DO NOT over reach. Always move the step ladder so that you are in a safe working position.
We recommend you use two people for installation of larger poles.
Take care when using power tools, use of a Residual Current Device (RCD) is recommended.
Always use eye protection when drilling. Beware of hidden pipe runs and cables.
No liability will be accepted for damage or injury caused by incorrectly installed or assembled product.
PLEASE KEEP OUT OF THE REACH OF YOUNG CHILDREN. SMALL PARTS - CHOKING HAZARD
PLEASE KEEP THESE INSTRUCTIONS AND THE BATCH CODE ON THE PACKAGING FOR FUTURE
28MM BAY POLE KIT
Fitting Instructions
Please keep for future reference
Tools required
assemble and fit this product.
Adjustable
Finial
Bracket
2
Safety Recommendation
Always use a step ladder when working at heights.
DO NOT hold or lean on the pole to support your weight.
REFERENCE IN CASE OF ANY QUERIES
Joiner
Piece
5
1
01543 272605
Optional
Wall
Screws
Plugs
15
15
Allen Key
1
7734L--02
Advertisement
Related Manuals for Dunelm Trinity 1000182933
Summary of Contents for Dunelm Trinity 1000182933
- Page 1 28MM BAY POLE KIT Fitting Instructions Please keep for future reference Tools required Optional Please read these instructions carefully and check the contents of the pack before attempting to assemble and fit this product. Pack Contents Pack Content Pole Serrated Adjustable Joiner Wall...
- Page 2 Bracket & Pole Cut Positions See diagram which matches your bay window style. Please note the distance from each pole end to the centre of the cuts. Orientate your pole to suit your bay. All measurements are approximate. Finial position is a guide only. Total pole length (when two poles are joined) 82.5cm 235cm...
- Page 3 Bending the bay pole 1. Before you begin to bend the pole here’s a practical tip - Ensure the cuts are to the inside of the bend. Use your knee to ease the bending process to create a smooth bend. Gently apply pressure throughout the length of the bend. Please ensure there is adequate padding on your knee when bending the pole and be careful to not cause any strain or injury.
- Page 4 Hanging the bay pole 1. Slide the centre bracket front a little way up the first pole. Insert the joining piece halfway into the first pole. Slide the second pole over the insert to make the join. (Fig. 10) 2. Move the centre bracket front to cover the pole join. Locate the bracket fronts into the bracket bases and slide the pole into its final position.
