U-Line H-3900 Manual

π
H-3900
PRODUCE BAG STAND –
STANDARD
TOOL INCLUDED
Wrench
1. Attach bottom pole to base by inserting it through the
hole in the base from the bottom (side with feet).
(See Figure 1)
Figure 1
2. Insert black carriage bolt from top of base and
loosely secure with nuts on underside of base.
Repeat for remaining three bolts. (See Figures 2-3)
Figure 2
PAGE 1 OF 6
1-800-295-5510
uline.com
ASSEMBLY
Figure 3
Pour le français, consulter les pages 5-6.
3. Tighten nuts on bottom of base with wrench.
(See Figure 4)
Figure 4
4. Slide top pole over bottom pole. Insert set screw
through hole of top pole and tighten with wrench.
(See Figure 5)
Figure 5
Para Español, vea páginas 3-4.
0822 IH-3900
