U-Line H-7896 Quick Start Manual

H-7896
WIRE GARMENT
RACK
TOOL NEEDED
Phillips Screwdriver
Post x 4
Hanging Bar x 1
INSTALLATION OF SELF-LEVELERS AND OPTIONAL CASTERS
Figure 1
Figure 2
PAGE 1 OF 9
1-800-295-5510
uline.com
PARTS
Shelf x 2
Hanging Hook x 2
TO INSTALL SELF-LEVELERS
NOTE: If installing casters, do not install self-levelers.
1. Make sure post is positioned as shown. (See Figure 1)
2. Insert self-leveler into open end of post.
3. Tap on ground until self-leveler slides into post.
4. Repeat steps 2 and 3 for other posts.
TO INSTALL OPTIONAL CASTERS
1. Make sure post is positioned as shown. (See Figure 2)
2. Engage the wheel brakes to keep casters from rolling during
assembly. Use a rubber mallet to tap caster stems into posts.
(See Figure 2)
Pour le français, consulter les pages 7-9.
Shelf Support x 8 Sets Self-Leveler x 4
Bolt x 2
Para Español, vea páginas 4-6.
Locking Caster x 4
Lock Washer x 2
0721 IH-7896
