1 - SAFETY WARNINGS
CAUTION – to ensure personal safety it is important to follow these
instructions and keep them for future reference. Read the instructions
carefully before proceeding with installation. The design and manufacture
of the devices making up the product and the information in this manual
are compliant with current safety standards. However, incorrect installation
or programming may cause serious injury to those working on or using the
system. Compliance with the instructions provided here when installing the
product is therefore extremely important.
2 - PRODUCT INTRODUCTION
The RXM5A is a universal receiver at 433.92 MHz with 2 relay outputs of 5 A,
compatible with fixed or rolling code transmitters from Key Automation. It can
be mounted on a wall/panel using the (removable) mounting tabs or installed
flush (e.g., in junction boxes). It can be powered directly by connecting it to
Key Automation control units or via a dedicated AC/DC power supply.
Warning: any use other than as specified herein or in environmental con-
ditions other than as stated in this manual is to be considered improper
and is prohibited.
TECHNICAL SPECIFICATIONS
Decoding
Transmitter compatibility
Frequency
Storable codes
Power supply
Maximum power
Duty cycle
Maximum current per output
Maximum voltage per output
Output OUT 1 behavior
Output OUT 2 behavior
Protection rating
Electrical insulation class
Operating temperature
Dimensions with fixing tabs
Dimensions without fixing tabs
Weight
Fixed code or rolling code (not simultaneous)
SUB - PLAY - TIP
433.92 MHz
12-24 VAC 50/60 Hz 12-35 VDC
0.6 W (both relays active)
Continuous
5 A @ 30 V (resistive load)
35 VAC / 50 VDC
Monostable impulsive
Monostable or bistable
-20 +55 °C
70x60x31 mm
50x50x31 mm
0,045 kg
1000
IP 4X
III
