ROOMS TO GO SSIO 5077-SC Assembly Instructions

Manufactured by SSIO for Rooms To Go
*** Caution. Please read all instructions carefully before starting assembly process. These parts are cumbersome
and heavy. Therefore, two people are recommended in order to prevent personal injury and ensure the parts are not
damaged during the assembly.
No. PARTS LIST
A
B
C
D
E
F
Step 1
Attach Seat Box w/ Wood Seat (B) to Chair Back (A) by inserting Short Bolt/ Lock Washer/ Flat Washer (3)
into the holes of the center of the Seat Box w/ Wood Seat (B). Tighten with Allen Key (5).
Insert Long Bolt/ Lock Washer/ Flat Washer (1) into the holes of the corner of the Seat Box w/ Wood Seat.
Tighten with Allen Key (5). Do not fully tighten.
A
CLEANING INSTRUCTION: Clear with a soft and warm water with a diluted mild detergent.
Follow with a soft cloth and clear water rinse. Then dry throughly with a soft cloth
Hardware pack location
5077 - SC SIDE CHAIR - SKU#: 42450774
ASSEMBLY INSTRUCTIONS
SSIO 5077 - SC SIDE CHAIR - SKU#: 42450774
1
Chair Back
Seat Box w/
1
Wood Seat
1
Left Front Leg
1
Right Front Leg
1
Left Stretcher
Right Stretcher 1
5
B
No. HARDWARE LIST
Long Bolt Ø5/16"-18 x 75mm
1
Lock Washer Ø5/16" x 13mm
Flat Washer Ø5/16" x 19mm
Medium Bolt Ø5/16"-18 x 60mm
Lock Washer Ø5/16" x 13mm
2
Flat Washer Ø5/16" x 19mm
Short Bolt Ø1/4"-20 x 40mm
3 Lock Washer Ø5/16" x 13mm
Flat Washer Ø5/16" x 19mm
4
Screw Ø4 x 40mm
5
1
3
MADE IN VIETNAM | Page 1 of 2
Version #1 - 2024/05/15
4
4
4
4
4
4
3
3
3
4
1
Allen Key 4mm
5
