ROOMS TO GO 5093-85PHR Assembly Instructions

Manufactured by SYNE for Rooms To Go
Parts and Hardware List
NO.
A
B
C
D
STEP 1.
1. Unzip the dust cover in the bottom, remove the legs from the red bag.
2.Attach the plastic legs by turning clockwise until tight. Do not over-tighten.
STEP 2.
1.Slide the metal receiver over the metal post. Press both sides of back firmly downward
until locked in place.
2.Locate the power cord A attached to the bottom back and connect to plug B located at
the rear of seat.
3. Connect one end of the L shape cord firmly into the DC adaptor located in the lower
back corner,and plug the other end of the L shape cord into a power outlet/wall socket.
4. Connect wall plug transformer to outlet.
1
Assembly Instructions
Description Image
Body
Red bag
DC adaptor
plastic legs
and washer
L shape
cord
2
SYNE
5093-85PHR recliner w/pwr headrest
SKU:
18550930/18550942/18550954
Qty
1
1
4
1
3
Note: Make sure all PLUGS are connected on
the product before plugging power cord into
power outlet. If not damage can occur.
The USB ports (where applicable) are
designed with working voltage of 5V, and can
NOT be used to supply power for laptop
computers (neither PC or Mac). Plugging a
laptop computer to the USB port may end up
damaging either the computer or the USB port
due to unmatched working voltage.
4
