ROOMS TO GO Naja BDPIAZHBQL Assembly Instructions

NAJA BDPIAZHBQL 32352584 5258-3 QUEEN HEADBOARD GRAY OAK
NAJA BDPIAZHBQ 32352560 5256-3 QUEEN HEADBOARD BROWN OAK
Manufactured for Rooms to Go.
NAJA BDPIAZFBQPL 32752582 5258-7 QUEEN FOOTBOARD GRAY OAK
NAJA BDPIAZFBQPB 32752568 5256-7 QUEEN FOOTBOARD BROWN OAK
NAJA BDPIAZRSQ 32952562 5256-9 QN/KG RVS RAILS BROWN OAK
NAJA BDPIAZRSQL 32952586 5258-9 QN/KG RAILS GRAY OAK
Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small
parts,which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the HARDWARE LIST below.
Caution: Please read instructions thoroughly before unpacking assembly parts.
1.We recommend that you assemble this product with the assistance of another person; this will make assembly
easier, and will help to eliminate damage to the product or injury to persons during assembly.
2.Please do not over tighten screws or bolts until the assembly is completed.
3.Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your newly
purchased product correctly and efficiently.
NO.

Parts List

Headboard
A
B
Left headboard leg
C Right headboard leg
D
Head board bottom rail
E
Footboard
F
Side rails
Long support legs for slats
G
Extension short support legs
H
for slat
I
Slats
Assembly Instructions For
Q' TY
1
1
1
1
1
2
5
5
5
A
B

Hardware List

NO
.
F 5/16 " * 2"L Allen Bolt
F 5/16 " Spring washer
1
F 5/16 " *F 19mm Flat washer
Allen wrench (4mm)
F 8 * F4 * 1- 1/4"
2
D
L Wood screw

STEP 1

STEP 2

1
Q' TY
8
8
8
1
10
1
C
Page 1 of 3
