Sectoriel LYVA-FW Instruction Manual

STAINLESS STEEL ACS FULL WIRELESS ELECTRIC BALL VALVE
FEATURES
The LYVA-FW is a stainless steel full wireless electric valve designed for
automatic shut-off of small-diameter fluid lines. The LYVA-FW, with full
feed-through, is ideal for applications in smart buildings, smart
agriculture, marinas...., where it is costly or complex to install a cable
network. Operation of the actuator powered by 2 long-life 1,5V lithium
batteries, with opening/closing control and long-range remote
monitoring compatible with LoRaWAN
Accompanied by a bubble BOX-type LoRaWAN
gateway (receiver), it makes it very easy to install. Low power
consumption. LYVA-FW has NSF certification for food contact and ACS
drinking water approval.
AVAILABLE MODELS
LYVA-FW : stainless steel body.
Diameters and connections: G 1/2" to G 1" (manual override).
Voltages : 2 x 1.5V lithium batteries - 3000 mAh.
Wiring diagram : wireless.
Operating time : 1 to 60 seconds
LIMITS OF USE
Use prohibited on Group I gases in accordance with EC directive 2014/68.
Use prohibited in explosive atmospheres.
Electrical protection :
Fluid WP :
∆P max :
Fluid WT°:
Ambiant WT°:
DIRECTIVES AND MANUFACTURING STANDARDS
OBJET
Pressure Equipment Directive 2014/68/EC
EC Low Voltage Directive 2014/35
Food fluids
Information given as an indication only, and subject to possible modifications
TYPE LYVA-FW
( )
™ 868 MHz protocol.
( )
™ 868 MHz compatible
IP 67
0 - 10 bar up to 1"
10 bar up to 1"
0°C / +90°C
-10°C / +55°C
Standard
A4 § 3
category I
NSF certificate
SECTORIEL S.A.
45 rue du Ruisseau
38290 SAINT QUENTIN-FALLAVIER – FRANCE
Tél : +33 4 74 94 90 70 - Fax : +33 4 74 94 13 95
www.sectoriel.com / Email : sectoriel@sectoriel.fr
IP 67
OBJET
Material shades
Threaded connection
Drinking water
Pages
Ref.
Rev.
Date
Standard
EN 1503-1
ISO 228
ACS
1/4
TDS8930FW
0
11/2024
