Summary of Contents for Kogan KA12BICEMKA

  • Page 1 12KG ICE CUBE MAKER WITH SELF-CLEANING KA12BICEMKA...
  • Page 3: Safety And Warnings

    • Place the power cord in such a way that it is not in contact with hot surfaces. • The use of attachments not recommended or sold by Kogan.com may cause fire, electric shock, or injury. • Do not touch the evaporator when using the ice maker or making ice to avoid frostbite.
  • Page 4 • Do not use with water that is microbiologically unsafe or of unknown quality. • Do not clean your ice maker with any flammable fluids. The fumes may create a fire hazard or explosion. • Do not overturn the ice maker. If the ice maker is overturned accidentally, stand it up steadily for 2 hours before powering it on again.
  • Page 5 OVERVIEW Control Panel Top Lid Front Cover Shell Body Infrared Light - Receiving Diode Infrared Light - Emitting Diode Filter ‘Max’ Water Level...
  • Page 6 Evaporator Ice Tray Ice Shovel Ice Basket...
  • Page 7 Control Panel Icon Button/Indicator Function Power Button/Indicator Press to start or stop the ice maker. Ice Full Indicator Illuminates when the ice basket is full. Add Water Indicator Illuminates when the water reservoir is low. Small Ice Indicator Illuminates when small ice is selected. Large Ice Indicator Illuminates when large ice is selected.
  • Page 8: Before First Use

    •  U npack the ice maker, then ensure that all the accessories, including the ice basket and ice scoop, are included. Contact help.Kogan.com if any accessories are missing. •  E nsure the ice maker is level and on a stable table or platform to avoid malfunction.
  • Page 9: Operation

    OPERATION  E nsure that the drain plug at the bottom of the water reservoir is securely closed.  P lug the ice maker into an electrical outlet. The ‘Large Ice’ indicator will illuminate Allow the ice maker to rest for 30 minutes before plugging it in if it has been moved.
  • Page 10: Cleaning And Care

    CLEANING & CARE To keep your ice tasting fresh and your ice maker looking great, it is recommended to clean the ice maker once a week.  S top the ice-making cycle by pressing the ‘Power’ button, unplug the ice maker from the electrical outlet, and allow it to warm up to room temperature.
  • Page 11 Ensure the drain plug is securely closed. Fill the water reservoir with clean water, press the ‘Select’ button until the ‘Cleaning’ indicator flashes, then press the ‘Power’ button. The pump will start to pump water and keep running for 6 minutes. After 6 minutes, the ice maker will enter standby mode.
  • Page 12: Specifications

    SPECIFICATIONS Applicable climate ST/SN/N/T Class Power input 220-240V/50Hz Rated power 170W Refrigerant/refrigerant amount R600a/13g Foaming agent Net weight 6.1kg Housing Dimensions 286 x 206 x 278mm...
  • Page 13: Troubleshooting

    The ‘Ice Full’ diode & light-receiving diode indicator and restart the ice maker. Infrared light-emitting illuminates. • Contact help.Kogan.com if the diode & light-receiving infrared light-emitting diode & diode do not work. light-receiving diode still don’t work after wiping up the foreign objects on them and restarting the ice maker.
  • Page 14 The ice-making high. 32°C and fill the water reservoir cycle seems with some cold water. normal, but no ice Contact help.Kogan.com for Refrigerating system leak. is produced. support. Contact help.Kogan.com for Refrigerating system block. support. Leave a 15cm clearance on all Poor heat dissipation.
  • Page 15 NOTES...
  • Page 16 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your ice maker, as well as any additional assistance you may require, head online to help.kogan.com...
