Foreword ----------------------------------------------------------- 0-1
Emission-related components warranty
(USA and CANADA only) --------------------------------- 0-1-1
Before servicing this machine --------------------------- 0-2
EC regulation approved ------------------------------------ 0-3
Table to enter S/No and distribution --------------------- 0-4
Safety labels ------------------------------------------------------ 0-5
Machine data plate -------------------------------------------- 0-21
Guide (direction, S/No, symbol) ------------------------ 0-22
1. Before operating the machine -------------------- 1-1
2. During operating the machine -------------------- 1-6
3. During maintenance ----------------------------------- 1-13
4. Parking -------------------------------------------------------- 1-16
1. Major components -------------------------------------- 2-1
2. Specifications --------------------------------------------- 2-2
3. Working range -------------------------------------------- 2-16
4. Weight --------------------------------------------------------- 2-22
5. Lifting capacities ----------------------------------------- 2-24
6. Bucket selection guide ------------------------------- 2-32
7. Undercarriage --------------------------------------------- 2-36
9. Recommended oils ------------------------------------ 2-44
1. Cab devices ------------------------------------------------ 3-1
2. Cluster -------------------------------------------------------- 3-2
3. Switches ----------------------------------------------------- 3-34
4. Levers and pedals -------------------------------------- 3-38
5. Others --------------------------------------------------------- 3-40
1. Suggestion for new machine ---------------------- 4-1
3. Starting and stop the engine ---------------------- 4-3
4. Mode selection system ------------------------------- 4-7
5. Operation of the working device ----------------- 4-12
6. Traveling of the machine ---------------------------- 4-13
7. Efficient working method ---------------------------- 4-16
9. Normal operation of excavator ------------------- 4-22
10. Attachment lowering ---------------------------------- 4-23
11. Storage -------------------------------------------------- ---- 4-24
12. RCV lever operating pattern ---------------------- 4-26
1. Preparation for transportation -------------------- 5-1
2. Dimension and weight ------------------------------- 5-2
3. Loading the machine --------------------------------- 5-10
4. Fixing the machine ------------------------------------ 5-12
6. Disassemble for transportation ------------------ 5-14
1. Instruction ------------------------------------------------- 6-1
2. Tightening torque --------------------------------------- 6-6
3. Fuel, coolant and lubricants ----------------------- 6-10
4. Maintenance check list ------------------------------ 6-12
5. Maintenance chart ------------------------------------ 6-17
6. Service instruction ------------------------------------- 6-19
7. Electrical system ---------------------------------------- 6-46
8. Air conditioner and heater -------------------------- 6-49
1. Engine -------------------------------------------------- ------ 7-1
2. Electrical system ---------------------------------------- 7-2
3. Others -------------------------------------------------------- 7-3
1. Selecting hydraulic breaker ------------------------ 8-1
2. Circuit configuration ----------------------------------- 8-2
3. Maintenance ---------------------------------------------- 8-3
5. Quick clamp ----------------------------------------------- 8-6
------------------------------------------------------------- 9-1
CONTENTS
