Hyundai R140W-9 Manual

Table of Contents

Advertisement

Quick Links

Download this manual

Foreword ----------------------------------------------------------- 0-1

Before servicing this machine --------------------------- 0-2

EC regulation approved ------------------------------------ 0-3

Table to enter S/No and distribution --------------------- 0-4

Safety labels ------------------------------------------------------ 0-5

Machine data plate -------------------------------------------- 0-18

Guide (direction, S/No, symbol) ------------------------ 0-19

1. Before operating the machine -------------------- 1-1

2. During operating the machine -------------------- 1-16

3. During maintenance ----------------------------------- 1-23

4. Parking -------------------------------------------------------- 1-26

1. Major components ------------------------------------- 2-1

2. Specifications -------------------------------------------- 2-2

3. Working range ------------------------------------------- 2-3

4. Weight ------------------------------------------------------- 2-5

5. Lifting capacities ---------------------------------------- 2-6

6. Bucket selection guide ------------------------------- 2-8

7. Specification for major components ----------- 2-10

8. Recommended oils ------------------------------------ 2-14

CONTROL DEVICES

1. Cab devices ----------------------------------------------- 3-1

2. Cluster ------------------------------------------------------- 3-2

3. Switches ---------------------------------------------------- 3-23

4. Levers and pedals ------------------------------------- 3-32

5. Air conditioner and heater ------------------------- 3-35

6. Others -------------------------------------------------------- 3-42

1. Suggestion for new machine ---------------------- 4-1

2. Check before starting the engine --------------- 4-2

3. Starting and stop the engine ---------------------- 4-3

4. Mode selection system ------------------------------ 4-6

5. Operation of the working device ----------------- 4-11

6. Traveling of the machine ---------------------------- 4-12

7. Efficient working method --------------------------- 4-18

8. Operation in the special work sites ------------- 4-23

9. Normal operation of excavator ------------------- 4-25

10. Attachment lowering ---------------------------------- 4-26

11. Storage -------------------------------------------------- --- 4-27

12. RCV lever operating pattern ----------------------- 4-29

13. Switching hydraulic attachment circuit -------- 4-31

1. Road traveling -------------------------------------------- 5-1

2. Preparation for transportation -------------------- 5-2

3. Dimension and weight ------------------------------- 5-3

4. Loading the machine --------------------------------- 5-5

5. Fixing the machine ------------------------------------ 5-7

6. Loading and unloading by crane --------------- 5-8

1. Instruction ------------------------------------------------- 6-1

2. Tightening torque --------------------------------------- 6-6

3. Fuel, coolant and lubricants ----------------------- 6-9

4. Maintenance check list ------------------------------ 6-11

5. Maintenance chart ------------------------------------ 6-16

6. Service instruction ------------------------------------- 6-18

7. Electrical system --------------------------------------- 6-44

8. Air conditioner and heater -------------------------- 6-47

TROUBLESHOOTING GUIDE

1. Engine -------------------------------------------------- ----

2. Electrical system --------------------------------------- 7-2

3. Others ------------------------------------------------------- 7-3

HYDRAULIC BREAKER AND QUICK CLAMP

1. Selecting hydraulic breaker ------------------------ 8-1

2. Circuit configuration ----------------------------------- 8-2

3. Maintenance --------------------------------------------- 8-3

4. Precaution while operating the breaker ------ 8-4

5. Quick clamp ---------------------------------------------- 8-6

------------------------------------------------------------ 9-1

CONTENTS

7-1

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the R140W-9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai R140W-9

Page 1: Table Of Contents
CONTENTS Foreword ----------------------------------------------------------- 0-1 7. Efficient working method --------------------------- 4-18 Before servicing this machine --------------------------- 0-2 8. Operation in the special work sites ------------- 4-23 EC regulation approved ------------------------------------ 0-3 9. Normal operation of excavator ------------------- 4-25 Table to enter S/No and distribution --------------------- 0-4 10.
Page 2: Foreword
3. Use genuine Hyundai spare parts for the replacement of parts. We expressly point out that Hyundai will not accept any responsibility for defects resulting from non- genuine parts or non workmanlike repair. In such cases Hyundai cannot assume liability for any damage.
Page 3: Before Servicing This Machine
The procedures in this manual do not supersede any requirements imposed by federal, state, provin- cial or local laws. Hyundai can not anticipate every possible circumstance or environment in which this machine may be used and serviced. All personnel must remain alert to potential hazards.
Page 4: Ec Regulation Approved
EC REGULATION APPROVED Noise level (EN474-1 : 2006 and 2000/14/EC) are as followings. : 99dB (EU only) : 72dB The value of vibrations transmitted by the operator's seat are lower than standard value of (EN474-1 : 2006 and 2002/44/EC)
Page 5 EC Declaration of Conformity 1. HYUNDAI CONSTRUCTION EQUIPMENT EUROPE N.V VOSSENDAAL 11, 2440 GEEL (Belgium), as authorized representative in the European Community of HYUNDAI CONSTRUCTION EQUIPMENT Co. Ltd.(Korea) certiﬁ es that the construction equipment machinery. Machine Type : ******* Brand : HYUNDAI...
Page 6 TABLE TO ENTER SERIAL NO. AND DISTRIBUTOR Machine Serial No. Engine Serial No. Manufacturing year Manufacturer Hyundai Construction Equipment co., Ltd. 12th, Fl., Hyundai Bldg. 75, Yulgok-ro, Jongno-Gu, Address Seoul, 03058, Korea Hyundai Construction Equipment U.S.A, Inc Distributor for U.S.A 6100 Atlantic Boulevard Norcross...
Page 7: Safety Labels
SAFETY LABELS SAFETY LABELS 1. LOCATION 1. LOCATION Always keep these labels clean. If they are lost or damage, attach them again or replace them with a new label. 36 16 12 BATTERY COVER SCREEN PLATE CAB INSIDE-RH CAB INSIDE-LH LH CONSOLE BOX BATTERY BOX INSIDE PUMP SCREEN...
Page 8 2. DESCRIPTION There are several specific warning labels on this machine please become familiarized with all warn- ing labels. Replace any safety label that is damaged, or missing. AIR CLEANER FILTER (Item 1) This warning label is positioned on the air cleaner cover.
Page 9 BATTERY ACCIDENT (Item 4) This warning label is positioned on the bat- tery cover. Electrolyte containing sulfuric acid cause severe burns. Avoid being in contact with skin, eyes or clothes. In the event of accident flush with sufficient water, call a physician immediately.
Page 10 HYDRAULIC OIL LUBRICATION (Item 6) This warning label is positioned on the top of the hydraulic tank. Do not mix with different brand oils. Never open the filler cap while engine running or at high hydraulic oil tempera- ture. Loosen the cap slowly and release inter- nal pressure completely.
Page 11 KEEP CLEAR-SIDE (Item 11) This warning label is positioned on the LH side cover. To prevent serious personal injury or death keep clear of machine swing radi- Do not deface or remove this label from the machine. 21070FW13 STAY FIX (Item 12) This warning label is positioned on the both side cover.
Page 12 NO STEP-ENGINE HOOD (Item 14) This warning label is positioned on the engine hood. Do not step on the engine hood. 21070FW16 TRANSPORTING (Item 15) This warning label is positioned right side of upper frame. Study the operator's manual before transporting the machine, if provided and tie down arm and track to the carrier with lashing wire.
Page 13: Emergency Exit
MAX HEIGHT MAX HEIGHT (Item 20) This warning label is positioned on the right side window of the cab. Serious injury or death can result from Serious injury or death can result from contact with electric lines. contact with electric lines. An electric shock being received by An electric shock being received by merely coming into the vicinity of an...
Page 14 AIR CONDITIONER FILTER (Item 23) This warning label is positioned on the air conditioner cover. Periodic and proper inspection, cleaning and change of filter prolong air conditio- ner life time and maintain good performa- nce. 21070FW26 CONSOLE BOX TILTING (Item 24) This warning label is positioned on the LH console box.
Page 15 DOZER/OUTRIGGER IDEOGRAM (item 27) This warning label is positioned on the LH console box. See page 4-11 for details. Guidlines for using the general dozer blade. Be careful not to apply an excessive 92K4-07430 load when using a blade. Avoid impacts and loads on the bot- tom due to machine modification or excessive working conditions.
Page 16 FALLING (Item 29) This warning label is positioned on the top of the hydraulic tank. Falling is one of the major cause of per- sonal injury. Be careful of slippery conditions on the platforms, steps and handrails when standing on the machine. 14070FW30 KEEP CLEAR-BOOM/ARM (Item 30) This warning label is positioned on both...
Page 17 SWING LOCK (Item 33) This warning label is positioned on the right side frame of the cab. Before you leaving the machine, always place the swing lock pin securely in the LOCK position. 20W70FW64 CONNECTOR (Item 41) W A R N I N G This warning label is positioned on the bat- tery cover.
Page 18 A special air bleed valve is nec- essary for this operation, so please con- tact your Hyundai distributor. CONTROL IDEOGRAM (item 46) This warning label is positioned inside of LH side cover.
Page 19 RCV LEVER PATTERN (item 47) This warning label is positioned on the screen plate. See page 4-29 for details. 14W90FW47 SWING BEARING (item 48) This warning label is positioned in the front of swing ring gear. See page 6-35 for details. 38090FW02 BATTERY POSITION (item 49) This warning label is positioned right side of...
Page 20 FUEL SHUT OFF (item 51) This warning label is positioned on the left side of the hydraulic tank. Fill only the hydraulic oil. Do not fill the diesel fuel. 140WH90FW51 WATER SEPARATOR (item 52) This warning label is positioned in right win- dow of the cab.
Page 21: Machine Data Plate
The machine serial number assigned to this particular machine should be used when requesting information or ordering service parts for this machine from your authorized HD Hyundai information or ordering service parts for this machine from your authorized HD Hyundai Construction Equipment dealer.
Page 22: Guide (Direction, S/No, Symbol)
GUIDE 1. DIRECTION Forward The direction of this manual indicate forward, back- ward, right and left on the standard of operator when the dozer blade is in the rear and machine is on the traveling direction. Left Right Dozer blade Backward 14W90SG01 2.
Page 23: Safety Hints
SAFETY HINTS SAFETY HINTS 1. BEFORE OPERATING THE MACHINE 1. BEFORE OPERATING THE MACHINE Think-safety first. In special situation, wear protective clothing including a safety helmet, safety shoes, gloves, safety glasses and ear protection as required by the job condition. Almost every accident is caused by disregard- ing the simple and fundamental safety hints.
Page 24 Check daily according to the operation manual. Repair the damaged parts and tighten the loos- ened bolts. 17W31SH05 Check for leakage of engine oil, hydraulic oil, fuel and coolant. Keep machine clean, clean machine regularly. 17W31SH06 Do not operate the machine if it requires repairs. Operate after complete repair.
Page 25: Fops (Falling Object Protective Structure)
UNAUTHORIZED MODIFICATION Any modification made without authorization from Hyundai can create hazards. Before making a modification, consult your Hyundai distributor. Hyundai will not be respon- sible for any injury or damage caused by any unauthorized modification. PREPARE FOR EMERGENCY PREPARE FOR EMERGENCY...
Page 26: Safety Rules
Do not use attachments that are not authorized by Hyundai or your Hyundai distributor. Use of unauthorized attachments could create a safety problem and adversely affect the proper opera- tion and useful life of the machine.
Page 27: Safety Features
SAFETY FEATURES SAFETY FEATURES Be sure all guards and covers are in their prop- er position. Have guards and covers repaired if damaged. Use safety features such as safety lock and seat belts properly. Never Never remove any safety features. Always Always keep them in good operating condition.
Page 28: Fire Prevention And Explosion Prevention
FIRE PREVENTION AND EXPLOSION PREVENTION Regeneration The exhaust gas temperatures during regeneration will be elevated. Follow proper fire prevention instructions and use the disable regeneration function when appropriate. General All fuels, most lubricants, and some coolant mixtures are flammable. To minimize the risk of fire or explosion, the following actions are recommended.
Page 29 Store fuels and lubricants in properly marked containers away from unauthorized personnel. Store oily rags and flammable materials in protective containers. Do not smoke in areas that are used for storing flammable materials. 3001SH02 Use caution when you are fueling a machine. Do not smoke while you are fueling a machine.
Page 30 Fire on a machine can result in personal injury or death. Exposed battery cables that come into contact with a grounded connection can result in fires. Replace cables and related parts that show signs of wear or damage. Contact your Hyundai dealer. Wiring Check electrical wires daily.
Page 31 Do not operate a machine when a fire hazard exists. Repair any lines that are corroded, loose, or damaged. Leaks may provide fuel for fires. Consult your Hyundai dealer for repair or for replacement parts. Ether Ether (if equipped) is commonly used in cold weather applications.
Page 32 Fire Extinguisher As an additional safety measure, keep a fire extinguisher on the machine. Be familiar with the operation of the fire extinguisher. Inspect the fire extinguisher and service the fire extinguisher regularly. Follow the recommendations on the instruction plate. Consider installation of an aftermarket Fire Suppression System, if the application and working conditions warrant the installation.
Page 33 Do not weld the ROPS structure in order to install the fire extinguisher. Also, do not drill holes in the ROPS structure in order to mount the fire extinguisher on the ROPS. Consult your Hyundai dealer for the proper procedure for mounting the fire extinguisher. 1-11...
Page 34 THE EUROPEAN UNION PHYSICAL AGENTS (VIBRATION) DIRECTIVE 2002/44/EC Vibration Data for Earth-moving Machines Information Concerning Hand/Arm Vibration Level When the machine is operated according to the intended use, the hand/arm vibration of this machine is below 2.5 m/s Information Concerning Whole Body Vibration Level The highest root mean square value of weighted acceleration to which the whole body is subjected, is less than 0.5 m/s This section provides vibration data and a method for estimating the vibration level for earth moving...
Page 35 All vibration levels are in meter per second squared. ※ ISO Reference Table A – Equivalent vibration levels of whole body vibration emission for earthmoving equipment. Vibration Levels Scenario Factors Machine Typical operating Machine kind family condition X axis Y axis Z axis X axis Y axis...
Page 36 Guidelines for Reducing Vibration Levels on Earthmoving Equipment Properly adjust machines. Properly maintain machines. Operate machines smoothly. Maintain the conditions of the terrain. The following guidelines can help reduce the whole body vibration level : Use the right type and size of machine, equipment, and attachments. Maintain machines according to the manufacturer’s recommendations.
Page 37 Modifications may be considered to be officially approved, if at least one of the following conditions has been met : 1. The attachment, the accessory, or the spare part has been made or distributed by Hyundai Heavy Industries and has been installed according to approved methods described in a publication available from Hyundai Heavy Industries;...
Page 38: During Operating The Machine
2. DURING OPERATING THE MACHINE Use the handle and footstep when getting on or off the machine. Do not jump on or off the machine. 17W31SH09 Sound the horn to warn nearby personnel before operating the machine. Remove all the obstacles like frost on the win- dow before operating the machine for the good visibility.
Page 39 Provide proper ventilation when operating engine in a closed area to avoid the danger of exhaust gases. 17W31SH13 Check the locations of underground gas pipes or water line and secure the safety before oper- ation. 17W31SH14 The operating near the electrical lines is very dangerous.
Page 40 Watch out for obstacles. Be particularly careful to check the machine clearance during the swing. 17W31SH17 When using the machine as breaker or working in a place where stones may fall down, cab roof guard and head guard should be provided for proper protection.
Page 41 Avoid traveling in a cross direction on a slope as it can cause the danger of rolling over and slid- ing. 17W31SH21 Traveling on a slope is dangerous. Be sure to operate slowly when traveling down a slope and maintain the bucket at a height of 20~30 cm (1 ft) above the ground so that it can be used as brake in an emergency.
Page 42 The operation on a slope is dangerous. Avoid operating the machine on a slope of over 10 degree. 17W31SH25 Operate the machine after making ground flat when operation is required on a slope. 17W31SH26 The swing on the slope can be danger of rolling over.
Page 43 Before traveling the machine, sound the horn to warn nearby personnel. Operate forward and backward correctly with confirming the location of the travel motor. 17W31SH29 Slow down when traveling through obstacles or uneven ground. 17W31SH30 When operating in water or when crossing shal- low, check the bed soil condition and depth and flow speed of water, then proceed taking care that water is not above axle center.
Page 44: Mounting And Dismounting
When mounting or dismounting, always face the machine and use the handrails, machine or foot steps. In this case please contact your Hyundai distributor. Do not hold any control levers when getting on or off the machine.
Page 45: During Maintenance
3. DURING MAINTENANCE Stop the engine immediately when the trouble of the machine is found. Inspect immediately the cause of trouble such as vibration, overheating and trouble in the clus- ter then repair. 17W31SH32 Park on a flat place and stop the engine for inspecting and repairing.
Page 46 There is the danger of fire in fuel and oil. Store in cool and dry area, away from any open flames. 13031SH37 Do not touch exhaust pipe, or may cause severe burn. 13031SH38 Do not open the engine hood and covers while the engine is running.
Page 47 Be careful that the front window may be promptly closed. Be sure to support stay, when the side door needs to be opened. Be careful that the open side door may closed by the external or natural force like strong wind. 13031SH41 The antislip protection should be replaced if they have become worn or have been printed...
Page 48: Parking
4. PARKING When leaving the machine after parking, lower the bucket to the ground completely and put the safety lever at parking position then remove the key. Lock the cab door. 17W31SH43 Park the machine in the flat and safe place. 17W31SH44 Hope you can work easily and safely observing safety rules.
Page 49: Specifications
SPECIFICATIONS SPECIFICATIONS 1. MAJOR COMPONENTS 1. MAJOR COMPONENTS Tooth Bucket Battery box Fuel tank Hydraulic tank Main pump Engine Radiator Oil cooler Tire Turning joint Swing motor Main control valve Arm cylinder Boom Boom cylinder Muffler Counterweight Dozer cylinder Dozer blade Bucket cylinder Connecting rod Front axle...
Page 50: Specifications
2. SPECIFICATIONS 4.6 m (15' 1") ONE PIECE BOOM, 2.1 m (6' 11") ARM AND REAR DOZER BLADE I(I') B(L) 14W92SP02 Description Unit Specification Operating weight kg (lb) 13700 (30200) Bucket capacity (SAE heaped), standard 0.58 (0.76) Overall length 7760 (25' 6") Overall width 2500 ( 8' 2") Overall height...
Page 51: Working Range
3. WORKING RANGE 4.6 m (15' 1") MONO BOOM 14W92SP03 Description 1.9 m (6' 3") Arm 2.1 m (6' 11") Arm 2.5 m (8' 2") Arm 3.0 m (9' 10") Arm Max digging reach 7750 mm (25' 5") 7920 mm (26' 0") 8320 mm (27' 4") 8780 mm (28'10") Max digging reach on ground 7530 mm (24' 8") 7700 mm (25' 3") 8120 mm (26' 8") 8590 mm (28' 2") Max digging depth...
Page 52 4.9 m (16' 1") HYDRAULIC ADJUSTABLE BOOM 14W92SP04 Description 1.9 m (6' 3") Arm 2.1 m (6' 11") Arm 2.5 m (8' 2") Arm Max digging reach 8140 mm (26' 8") 8310 mm (27' 3") 8720 mm (28' 7") Max digging reach on ground 7930 mm (26' 0") 8110 mm (26' 7") 8530 mm (28' 0")
Page 53: Weight
4. WEIGHT 4. WEIGHT R140W-9 Item Upperstructure assembly 4680 10320 Main frame weld assembly 1150 2540 Engine assembly 1230 Main pump assembly Main control valve assembly Swing motor assembly Hydraulic oil tank assembly Fuel tank assembly Counterweight 1700 3750 Cab assembly...
Page 54: Lifting Capacities
5. LIFTING CAPACITIES 5. LIFTING CAPACITIES 1) 1) ROBEX 140W-9 ROBEX 140W-9 4.60 m (15' 1") boom, 2.1 m (6'11") arm equipped with 0.58 m (SAE heaped) bucket and rear dozer blade down with 1700 kg counterweight. · · : Rating over-front : Rating over-side or 360 degree Load radius At max.
Page 55 2) 2) ROBEX 140W-9 ROBEX 140W-9 ADJUST BOOM ADJUST BOOM 4.90 m (16' 9") hydraulic adjustable boom, 1.9 m (6' 3") arm equipped with 0.58 m (SAE heaped) bucket and rear dozer blade down with 1700 kg counterweight. · · : Rating over-front : Rating over-side or 360 degree Load radius...
Page 56: Bucket Selection Guide
6. BUCKET SELECTION GUIDE 6. BUCKET SELECTION GUIDE 1) 1) GENERAL BUCKET GENERAL BUCKET 0.52, ※0.58, 0.65, 0.71 m 0.23 m 0.40, 0.46 m heaped bucket heaped bucket heaped bucket Recommendation Capacity Width 4.6 m (15' 1") 4.9 m (16' 9") Mono boom Hyd adjustable boom Weight...
Page 57 2) 2) Special bucket Special bucket Slope finishing bucket Ditch cleaning bucket ◎ 0.55 m 0.45 m heaped bucket heaped bucket Recommendation Capacity Width 4.6 m (15' 1") 4.9 m (16' 9") Mono boom Hyd adjustable boom Weight CECE Without With 1.9 m arm 2.1 m arm...
Page 58: Specification For Major Components
7. SPECIFICATIONS FOR MAJOR COMPONENTS ENGINE Item Specification Model Cummins QSB 6.7 / HYUNDAI HE6.7 Type 4-cycle turbocharged diesel engine, low emission Cooling method Water cooling Number of cylinders and arrangement 6 cylinders, in-line Firing order 1-5-3-6-2-4 Combustion chamber type Direct injection type Cylinder bore×stroke...
Page 59: Main Control Valve
GEAR PUMP Item Specification Type Fixed displacement gear pump single stage Capacity 15cc/rev Maximum pressure 40 kgf/cm (570 psi) Rated oil flow 31.5 l/min (8.3 U.S. gpm/6.9 U.K. gpm) MAIN CONTROL VALVE Item Specification Type 11 spools two-block Operating method Hydraulic pilot system Main relief valve pressure 350 kgf/cm...
Page 60: Power Train
POWER TRAIN Item Description Specification Type 2 speed power shift transmission Transmission 4.87 Gear ratio 1.20 Type Multi disc brake integrated in transmission Parking brake Maximum braking torque 2124 kgf·m (15360 lbf·ft) Type 4 wheel drive with differential Axle Gear ratio 15.43 Brake Multi disc brake...
Page 61 9) 9) BUCKET BUCKET Capacity Width Tooth Item quantity SAE heaped CECE heaped Without side cutter With side cutter ※ 0.58 m Standard 1030 mm (40.6") 1130 mm (44.5") (0.76 yd 0.50 m (0.65 yd 520 mm (20.5") 620 mm (24.4") 0.23 m (0.30 yd 0.20 m...
Page 62: Recommended Oils
8. RECOMMENDED OILS Use only oils listed below or equivalent. Do not mix different brand oil. Ambient temperature C( F) Service Capacity Kind of fluid l (U.S. gal) point (-58) (-22) (-4) (14) (32) (50) (68) (86) (104) SAE 5W-40 Engine 24 (6.3) oil pan...
Page 63: Control Devices
CONTROL DEVICES CONTROL DEVICES 1. CAB DEVICES 1. CAB DEVICES The ergonomically designed console box and suspension type seat provide the operator with com- fort. 2) 2) ELECTRONIC MONITOR SYSTEM ELECTRONIC MONITOR SYSTEM The centralized electronic monitor system allows the status and conditions of the machine to be monitored at a glance.
Page 64: Cluster
2. CLUSTER 2. CLUSTER 1) 1) STRUCTURE STRUCTURE The cluster consists of LCD and switches as shown below. The LCD is to warn the operator in case of abnormal machine operation or conditions for the appropriate operation and inspection. Also, The LCD is to set and display for modes, monitoring and utilities with the switches. The switches are to set the machine operation modes.
Page 65 2) 2) GAUGE GAUGE (1) (1) Operation screen Operation screen Engine coolant temperature gauge Default Option Hydraulic oil temperature gauge Fuel level gauge / Speed gauge RPM / Tripmeter display 21093CD07A ※ Operation screen type can be set by the screen type menu of the display. Operation screen type can be set by the screen type menu of the display.
Page 66 (4) (4) Fuel level gauge / Speed gauge Fuel level gauge / Speed gauge ① This gauge indicates the amount of fuel in the fuel tank. ② Fill the fuel when the red range, or lamp blinks in red. ※ If the gauge indicates the red range or If the gauge indicates the red range or lamp blinks in...
Page 67: Warning Lamps
WARNING LAMPS WARNING LAMPS 3) 3) Battery charging warning lamp Air cleaner warning lamp Check engine warning lamp Overload warning lamp Engine oil pressure warning lamp Brake oil pressure warning lamp Clutch oil pressure warning lamp Emergency warning lamp Fuel level warning lamp Engine coolant Hydraulic oil temperature temperature warning lamp...
Page 68 Emergency warning lamp Emergency warning lamp (4) (4) This lamp pops up and the buzzer sounds when each of the below warnings is happened. Engine coolant overheating (over 107˚C) Hydraulic oil overheating (over 105˚C) Pump EPPR circuit abnormal or open Attachment flow EPPR circuit abnormal or open 21093CD30 MCU input voltage abnormal...
Page 69 (8) (8) Air cleaner warning lamp Air cleaner warning lamp This lamp blinks when the filter of air cleaner is clogged. Check the filter and clean or replace it. 21093CD35 Overload warning lamp Overload warning lamp (opt) (9) (9) When the machine is overload, the overload warning lamp blinks during the overload switch is ON.
Page 70: Pilot Lamps
4) 4) PILOT LAMPS PILOT LAMPS Message display Work tool mode pilot lamp Auto cruise pilot lamp Work mode pilot lamp Travel speed pilot lamp Power/User mode pilot lamp Auto idle pilot lamp Power max pilot lamp Maintenance pilot lamp Preheat pilot lamp Fuel warmer pilot lamp Warming up pilot lamp...
Page 71 Preheat pilot lamp Preheat pilot lamp (3) (3) Turning the start key switch ON position starts preheating in cold weather. Start the engine after this lamp is OFF. 21093CD39 (4) (4) Warming up pilot lamp Warming up pilot lamp This lamp is turned ON when the coolant temperature is below 30˚C (86˚F ).
Page 72: Switches
5) 5) SWITCHES SWITCHES Power/User mode Auto idle pilot lamp pilot lamp Travel speed pilot lamp Work mode pilot lamp Escape(previous or parent menu) Power mode switch Rear camera(Option) Work mode switch Auto idle/Buzzer stop switch User mode switch Select switch 14W93CD45 When the switches are selected, the pilot lamps are displayed on the LCD.
Page 73 (3) (3) User mode switch User mode switch This switch is used to memorize the current machine operating status in the MCU and activate the memorized user mode. Memory : Push more than 2 seconds. Action : Push within 2 seconds. Cancel : Push this switch once more within 2 seconds.
Page 74 6) 6) MAIN MENU MAIN MENU Press 21093CD64 21093CD64B 21093CD64A Please refer to select switch, page 3-10 for selection and change of menu and input value. Please refer to select switch, page 3-10 for selection and change of menu and input value. (1) (1) Structure Structure...
Page 75 (2) (2) Mode setup Mode setup ① Work tool Work tool 21093CD65 21093CD65A 21093CD65B · A : Select one installed optional attachment. · B : Max ﬂ ow - Set the maximum ﬂ ow for the attachment. Flow level - Reduce the operating ﬂ ow from maximum ﬂ ow. Breaker - Max 7 steps, Reduced 10 lpm each step.
Page 76 Auto power boost Auto power boost 21093CD65L 21093CD65M · The power boost function can be activated or cancelled. · Enable - The digging power is automatically increased as working conditions by the MCU. It is operated max 8 seconds. · Disable - Not operated.
Page 77 (3) (3) Monitoring Monitoring Active fault Active fault 21093CD66 21093CD66A 21093CD66B · The active faults of the MCU or engine ECM can be checked by this menu. Logged fault Logged fault 21093CD66C 21093CD66D 21093CD66E · The logged faults of the MCU or engine ECM can be checked by this menu. Delete logged fault Delete logged fault 21093CD66F...
Page 78 Monitoring Monitoring (digital) 21093CD66M 21093CD66N 21093CD66P · The switch status or output status can be conﬁ rmed by this menu. · The activated switch or output pilot lamps are light ON. Operating hours Operating hours 21093CD66Q 21093CD66R · The operating hour of each mode can be conﬁ rmed by this menu. 3-15...
Page 79 (4) (4) Management Management ① Maintenance information Maintenance information 21093CD67 21093CD67A 21093CD67R 21093CD67Q 21093CD67T 21093CD67S · Alarm( ) : Gray - Normal Yellow - First warning - Second warning · Replacement : The elapsed time will be reset to zero (0). ·...
Page 80 Machine security Machine security 21093CD67C 21093CD67D 21093CD67E · ESL mode ESL mode ESL : Engine Starting Limit ESL mode is designed to be a theft deterrent or will pre- vent the unauthorized operation of the machine. If the ESL mode was selected Enable, the password will be required when the start switch is turned ON.
Page 81 Machine Information Machine Information 21093CD67F 21093CD67G · This can conﬁ rm the identiﬁ cation of the cluster, MCU, engine and machine. A/S phone number A/S phone number 21093CD67J 21093CD67K 21093CD67L 21093CD67Z 21093CD67Y Service menu Service menu 21093CD67M 21093CD67N 21093CD67P Enter the password 21093CD67ZZ ·...
Page 82 (5) (5) Display Display Display item Display item 21093CD68 21093CD68A 21093CD68W 21093CD68E 21093CD68B Center display Center display · The center display type of the LCD can be selected by this menu. · The engine speed or each of the tripmeter (A,B,C) is displayed on the center display. Clock Clock 21093CD68C...
Page 83 Brightness Brightness 21093CD68F 21093CD68G 21093CD68H Manual (1st~10th step) 21093CD68K 21093CD68J Auto (day/night) ※ If "Auto" is chosen, brightness for day and night can be differently set up. Also by using the If "Auto" is chosen, brightness for day and night can be differently set up. Also by using the bar in lower side, users can deﬁ...
Page 84 Screen type Screen type 21093CD68U 21093CD68V 21093CD68W A Type Standard Option 21093CD68Y B Type 21093CD68X (6) (6) Utilities Utilities Tripmeter Tripmeter 21093CD69 21093CD69A 21093CD69B · Maximum 3 kinds of tripmeters can be used at the same time. · Each tripmeter can be turned on by choosing "Start" while it also can be turned off by choosing "Stop".
Page 85 Entertainment Entertainment · Play MP4 or codec ﬁ le of external hard disk through USB port. · The USB port is located under the cluster. 21093CD69F 21093CD69G Camera setting Camera setting 21093CD69J 21093CD69K 21093CD69L · Three cameras can be installed on the machine. ·...
Page 86: Starting Switch
3. SWITCHES 3. SWITCHES Select switch 1 Quick clamp switch Cab light switch Beacon switch Work light switch Overload switch Main light switch Travel pilot lamp Select switch 2 push (Parking/working/traveling) Hazard switch Ram lock switch Creep switch Accel dial switch Horn switch Master switch Breaker operation switch...
Page 87: Master Switch
2) 2) MASTER SWITCH MASTER SWITCH This switch is used to shut off the entire electrical system. I : The battery remains connected to the electrical system. O : The battery is disconnected to the electrical system. Never turn the master switch to Never turn the master switch to O O (OFF) (OFF) with the engine running.
Page 88: Select Switch
7) 7) SELECT SWITCH 1 SELECT SWITCH 1 (outrigger / dozer, option) This switch is used to select dozer blade or outrigger operation. Switch Operation Front left outrigger or front dozer blade Rear left outrigger or rear dozer blade Front right outrigger Rear right outrigger ※...
Page 89 HEATED SEAT SWITCH HEATED SEAT SWITCH (option) This switch is used to heat the seat. · Heater ON (I) : 10±3.5 ˚C · Heater OFF (O) : 20±3 ˚C On pressing the switch, the indicator lamp is turned ON. 21093CD46M HORN SWITCH HORN SWITCH This switch is at the top of right side control lever.
Page 90 RH MULTI FUNCTION SWITCH RH MULTI FUNCTION SWITCH FNR lever FNR lever (1) (1) This lever changes travel direction of machine. Forward F F : Machine moves forward N N : Neutral position R R : Machine moves backward Travel direction will be reversed if lower structure is positioned Travel direction will be reversed if lower structure is positioned Reverse with dozer in front.
Page 91: Wiper Switch
(2) (2) Dimmer switch Dimmer switch This switch is used to turn the head lights direction. Switch positions. Up ( : To flash for passing Middle ( ) : Head lights low beam ON Down ( ) : Head lights high beam ON If you release the switch when it’s in up position, the switch will return Down to middle.
Page 92 RAM LOCK SWITCH RAM LOCK SWITCH This switch activate front axle oscillation cylinder to locking position for increase of stability. : Set front axle to locking position for excavation work or travels even ground. Also, the ram lock pilot lamp comes ON at the travel pilot lamp.
Page 93 TRAVEL TRAVEL PILOT PILOT LAMP LAMP Head light high beam pilot lamp Ram lock pilot lamp Working lock pilot lamp Right turning pilot lamp Parking lock pilot lamp Left turning pilot lamp 14W93CD54 (1) (1) Left turning pilot lamp Left turning pilot lamp This lamp flashes with sound when the LH multifunction switch is move to backward position.
Page 94 (5) (5) Working lock pilot lamp Working lock pilot lamp This lamp lights ON when the select switch 2 (parking / working / traveling) is set to working. Please refer to Please refer to select switch 2 select switch 2 at page 3-29 for details. at page 3-29 for details.
Page 95: Levers And Pedals
4. LEVERS AND PEDALS 4. LEVERS AND PEDALS RH control lever Swing lock pin Dozer & outrigger control lever(option) Steering wheel LH control lever Accelerator pedal or Safety lever 2 way pedal(option) Brake pedal Tilting lever Tilting lever 14W93CD48 1) 1) LH CONTROL LEVER LH CONTROL LEVER This joystick is used to control the swing and the arm.
Page 96 3) 3) SAFETY LEVER SAFETY LEVER All control levers and pedals are disabled from operation by locating the lever to lock position as shown. ※ Be sure to lower the lever to LOCK position when leaving from Be sure to lower the lever to LOCK position when leaving from operator's seat.
Page 97: Brake Pedal
ACCELATOR PEDAL ACCELATOR PEDAL 8) 8) When this pedal is stepped, the machine starts traveling. Before starting the machine with stepping on the pedal, check if Before starting the machine with stepping on the pedal, check if the underframe is certainly in the traveling direction. the underframe is certainly in the traveling direction.
Page 98: Air Conditioner And Heater
5. AIR CONDITIONER AND HEATER 5. AIR CONDITIONER AND HEATER ■ FULL AUTO AIR CONDITIONER AND HEATER FULL AUTO AIR CONDITIONER AND HEATER (standard) Full auto air conditioner and heater system automatically keeps the optimum condition in accordance with operator's temperature configuration sensing ambient and cabin inside temperature. ※...
Page 99: Auto Switch
1) 1) POWER OFF SWITCH POWER OFF SWITCH This switch makes the system and the LED OFF. Just before the power OFF, set values are stored. (2) (2) Default setting values Default setting values Function Air conditioner In/outlet Temperature Mode Value Inlet Previous sw OFF...
Page 100: Temperature Control Switch
5) 5) TEMPERATURE CONTROL SWITCH TEMPERATURE CONTROL SWITCH Setting temperature indication Type A : 17~32˚C, scale : 1˚C Type B : Lo, 18~31˚C, Hi, scale : 1˚C Max cool and max warm beeps 5 times. The max cool or the max warm position operates as following table. 370074CD57 Temperature Compressor...
Page 101: Self Diagnosis Function
8) 8) SELF DIAGNOSIS FUNCTION SELF DIAGNOSIS FUNCTION (1) (1) Procedure Procedure Starting switch ON Press the air recirculation button over 5 times within 2 secondsduring pressing the AUTO switch All symbol of LCD blink 5 times Switch OFF Error check System OFF Press AUTO switch Cancelled diagnosis function(normal function)
Page 102 SEMI AUTO AIR CONDITIONER AND HEATER SEMI AUTO AIR CONDITIONER AND HEATER (option) ■ Semi auto air conditioner and heater are equipped for pleasant operation against outside tempera- ture and defrost on window glass. ※ Refer to the page 3-35 for full auto air conditioner and heater. Refer to the page 3-35 for full auto air conditioner and heater.
Page 103 POWER SWITCH POWER SWITCH This switch makes the system and the LED simultaneously ON or OFF. (2) (2) Default setting values Default setting values Function Air conditioner Fan speed Temperature Outlet Inlet Value Max cool Face Recirculation 21073CD53 AIR CONDITIONER SWITCH AIR CONDITIONER SWITCH (compressor switch) Operating this switch turns the compressor and the LED simultane- ously ON or OFF.
Page 104 5) 5) OUTLET CHANGE OVER SWITCH OUTLET CHANGE OVER SWITCH There are four steps of air flow. Mode Switch position 21073CD51 Outlet When defroster switch operating, INLET switch turns to FRESH mode and air conditioner switch turns ON. In case of heating range (5~Max warm), air conditioner won't turns 6) 6) INLET CHANGE OVER SWITCH INLET CHANGE OVER SWITCH...
Page 105: Others
6. OTHERS 6. OTHERS Cigar lighter Seat Remote controller Radio & CD/MP3 player Handsfree RS232 & J1939 service socket EMERGENCY Service meter CN-16&16B CN-16A Fuse & relay box CN-16&16A CN-16B Emergency engine connector 14W93CD50 1) 1) CIGAR LIGHTER CIGAR LIGHTER This can be used when the engine starting switch is ON.
Page 106 2) 2) HANDSFREE HANDSFREE Allow you to dial a call or to have a conversation without holding your handset. Use the remote controller when making and answering a calls or ring off. Indicator lamp Private call jack socket Handsfree jack socket USB socket Mobile phone stroage box Service socket...
Page 107 (4) (4) Handsfree jack socket Handsfree jack socket Connect the jack cable when call by handsfree. Use the special adapter when jack cable is not interchangeable. Check the jack type of mobile phone before use. 21093CD51D (5) (5) Indicator lamp Indicator lamp This lamp is turned ON when the handsfree mode selected.
Page 108 3) 3) REMOTE CONTROLLER REMOTE CONTROLLER Handsfree jack MIC Power/Volume switch SEEK Seek button MODE MUTE Mode button Mute button Call button Mode change button CALL 21093CD52 (1) (1) Power and volume switch Power and volume switch This switch is used to turn the audio or handsfree ON or OFF. This switch is turned to right, the handsfree volume is increased over 7 steps.
Page 109 (4) (4) Handsfree jack MIC Handsfree jack MIC This MIC transfers user voice to receiver of the call when making a call by handsfree. SEEK MODE MUTE 21093CD52D (5) (5) Seek button Seek button If this button pressed, the radio automatically stops at the next fre- quency of broadcasting for your listening.
Page 110: Front Panel Presentation
RADIO AND CD/MP3 PLAYER : MACHINE SERIAL NO.: -#0669 CD inserter 21093CD70 FRONT PANEL PRESENTATION -------- Power and volume switch -------- Preset memory button 1 REW ----------- Fast rewind (CD) PWR ----------- Press to power on/off -------- Preset memory button 2 VOL ------------ Turn right/left to adjust the volume FF --------------- Fast forward (CD) -------- AM/FM button (radio)
Page 111 RADIO Power and volume switch Power ON/OFF This switch is used to turn the audio ON or OFF. Volume This switch turned to right or left, the sound is increased or 21093CD71 decreased. FM/AM button You can broadcasting on AM or FM band by pressing this band selection button.
Page 112 Preset memory button Manually storing stations in a preset Six stations per band can be stored and recalled using the preset keys (1 to 6). Tune in to the desired station. Press the desired preset key (1 to 6) for more than 0.8 seconds 21093CD76 to store the current tuned station.
Page 113 CD/MP3 PLAYER CD playback button It is possible to change CD playback during broadcasting. If there was no CD on audio, "NO DISC" displays on LCD during 5 seconds. 21093CD80 Track button CD player Short press : Select the next/previous track Long press : Select the fast forward or rewind MP3 player 21093CD73...
Page 114: Cd Eject Button
Repeat track button (CD) Press this button to activate repeat current track playback. The LCD displays "RPT". It is canceled press one more this button. 21093CD84 Mark button (MP3) Memory Press over 0.8 second, the current file memorized with a beep (max 100 tune memory).
Page 115 RADIO AND USB PLAYER (WITH BLUETOOTH) : MACHINE SERIAL NO.: #0670- 9403CD100 FRONT PANEL PRESENTATION -------- Power ON/OFF, ------- Station preset 5 Volume UP/DOWN button DIR- ----------- Directory down button -------- Manual UP/DOWN Tuning, -------- Station preset 6 File search, SEL button DIR+ ---------- Directory up button -------- Mode button, -------- Scan play button (SCAN)
Page 116 RADIO AND USB PLAYER (WITHOUT BLUETOOTH) : MACHINE SERIAL NO.: #0670- 9403CD101 FRONT PANEL PRESENTATION -------- Power ON/OFF, ------- Station preset 5 Volume UP/DOWN button DIR- ----------- Directory down button -------- Manual UP/DOWN Tuning, ------- Station preset 6 File search, SEL button DIR+ ----------- Directory up button -------- Mode button, -------- Scan play button (SCAN)
Page 117 GENERAL Power and volume button Power ON / OFF button Press power button (1) to turn the unit on or off. Volume UP/DOWN control knob Turn VOL knob (1) right to increase the volume level. Turn VOL knob (1) left to decrease the volume. 9403CD102 After 5 seconds the display will return to the previous display mode.
Page 118 Menu Selection This button can adjust the sound effect and other things. Each time you press this button (2), LCD displays as follows : TREB BAL L=R FAD F=R LOUD ON BEEP 2ND On each setting, the level can be controlled by turning TUNE knob (2). 9403CD103 When the last adjustment is made, after 5 seconds, the display will automatically return to the previous display mode.
Page 119 Loud control When listening to music at low volume levels, this feature will boost the bass and treble response. This action will compensate for the reduction in bass and treble performance experienced at low volume. To select the loudness feature, press button (2) until LOUD is displayed, then turn knob (2) right or left to activate or deactivate loudness.
Page 120 RADIO Mode button Repeat press MODE button to select FM1, FM2 or AM. 9403CD104 Manual tuning button To manually tune to a radio station, simply turn encoder TUNE (2) left or right to increase or decrease the radio frequency. 9403CD105 Auto tuning button To automatically select a radio station, simply press Seek up or Track down button.
Page 121 Preset scan (PS) / Best station memory (BSM) button Press BSM button (12) momentarily to scan the 6 preset stations stored in the selected band. When you hear your desired station, press it again to listen to it. Press BSM button (12) for longer than 2 seconds to activate the Best Station Memory feature which will automatically scan and 9403CD109 enter each station into memory.
Page 122: Usb Player
USB PLAYER USB playback The unit was equipped with a front USB jack and also a rear USB Jack. With a USB device plugged in the front USB jack, it will be detected as front USB mode. And with a USB device plugged in the rear USB jack, it will be detected as rear USB.
Page 123 Track Scan Play (SCAN) button SCAN playback : Simply press SCAN (12) button to play the first 10 seconds of each track. SCAN folder : Press and hold SCAN button for longer than 2 seconds to scan play the tracks in current folder. SCAN off : Simply press it again to cancel SCAN feature.
Page 124: Aux Operation
AUX OPERATION It is possible to connect your portable media player to the audio system for playback of the audio tracks via the cab speakers. To get the best results when connecting the portable media to the audio system, follow these steps : Use a 3.5 mm stereo plug cable to connect the media player headphone socket at each end as follows.
Page 125 BLUETOOTH (if equipped) Using a bluetooth wireless connection Your audio unit supports bluetooth wireless technology. You can set up a wireless link with bluetooth cellular phone. Keep PAIRING the cellular phone with audio unit in a few minutes as the phone are being switched on well enough.
Page 126 ※ Please retry to the pairing instruction if HYUNDAI does not appear on the cellular phone screen. Please retry to the pairing instruction if HYUNDAI does not appear on the cellular phone screen.
Page 127 Bluetooth connection and disconnection When established bluetooth connection between this audio unit and the cellular phone, bluetooth icon on the display appears and then the display shows HF/AV CONN when handsfree & AV profile connected. To disconnect bluetooth link Press and hold CALL END button (4) for 2 seconds, it shows DIS CON and disappears bluetooth Icon on the display.
Page 128 Audio transfer between the audio unit and phone The audio transfer function is for switching the call from the audio unit to the cellular phone for private conversation. Press CALL button (4) briefly during conversation, it appears CALL TRANS on the display. To switch back to the audio unit, press button (4) briefly during private conversation, then it appears CALL TRANS on the display again.
Page 129 Using the audio unit as bluetooth music The audio unit supports A2DP (Audio Advanced Distribution Profile) and AVRCP (Audio Video Remote Control Profile), and both profiles are available to listen music at the audio unit via cellular phone which is supporting the two profiles above. To play music, search the menu on your cellular phone as below : i.e : Menu File manager...
Page 130 RESET AND PRECAUTIONS Reset function Interfere noise or abnormal compressed files in the MP3 disc or USB instrument may cause extraordinary operation (or unit frozen/locking up). It’s strongly recommended to use appropriate USB storage not cause any malfunction to the audio unit. In the unlikely event that the player fails to operate correctly, try out to reset unit by any of following two methods.
Page 131 SEAT The seat is adjustable to fit the contours of the operator's body. It will reduce operator fatigue due to long work hours and enhance work efficiency. Forward/Backward adjustment (A) Pull lever A to adjust seat forward or backward. The seat can be moved forward and backward over 140 mm (5.5") in 13 steps.
Page 132: Fuse & Relay Box
FUSE & RELAY BOX SPARE CLUSTER HEAD LAMP POWER ANTI- BREAKER AC COMP RESTART ROOM LP/ SPARE CASSETTE SPARE 20A 10A 20A 20A 20A 20A 20A 10A 20A 10A 20A 10A 30A 30A 20A 10A 10A 10A 20A 20A WORK LAMP FUEL CABIN LAMP HEATER...
Page 133 EMERGENCY ENGINE SPEED CONTROL CONNECTOR When the CAN communication between the ECM and the MCU is abnormal due to malfunction of the MCU, change CN-16 connection from CN-16A to CN-16B and then control the engine speed by rotat- ing accel dial switch. Never connect connector CN-16 with CN-16B when MCU is in normal operation.
Page 134 UPPER WINDSHIELD UPPER WINDSHIELD Perform the following procedure in order to open the upper windshield. Auto lock latch ① Pull both levers with hold both grips that are located at the top of the windshield frame and push the windshield upward. ②...
Page 135: Operation
OPERATION OPERATION 1. SUGGESTION FOR NEW MACHINE 1. SUGGESTION FOR NEW MACHINE It takes about 100 operation hours to enhance its designed performance. Operate according to below three steps and avoid excessive operation for the initial 100 hours. Service meter Load Avoid excessive Until 10 hours...
Page 136: Check Before Starting The Engine
2. CHECK BEFORE STARTING THE ENGINE 2. CHECK BEFORE STARTING THE ENGINE Look around the machine and under the machine to check for loosen nut or bolts, collection of dirt, or leakage of oil, fuel or coolant and check the Check before starting condition of the work equipment and hydraulic...
Page 137: Starting And Stop The Engine
Turn the starting switch to the ON position. Buzzer sounding for 4 seconds with HYUNDAI logo on cluster. If the ESL mode is set to the enable, enter the If the ESL mode is set to the enable, enter the password to start engine.
Page 138: Starting Engine In Cold Weather
3) 3) STARTING ENGINE IN COLD WEATHER STARTING ENGINE IN COLD WEATHER Sound horn to warn surroundings after check- Sound horn to warn surroundings after check- ing if there are obstacles in the area. ing if there are obstacles in the area. Replace the engine oil and fuel referring to Replace the engine oil and fuel referring to recommended oils at page 2-14.
Page 139: Warming-Up Operation
5) 5) WARMING-UP OPERATION WARMING-UP OPERATION The most suitable temperature for the hydrau- The most suitable temperature for the hydrau- lic oil is about 50 lic oil is about 50˚C (122 C (122˚F ). F ). It can cause serious trouble in the hydraulic It can cause serious trouble in the hydraulic 50 C system by sudden operation when the hydraulic...
Page 140: Mode Selection System
MECHATRONICS SYSTEM SYSTEM CAPO, Computer Aided Power Optimization sys- tem, is the name of mode selection system devel- oped by Hyundai. Please refer to chapter 3, cluster for below modes Please refer to chapter 3, cluster for below modes setting.
Page 141 High idle rpm, auto idle rpm and EPPR pres- sure can be adjusted and memorized in the U-mode. ※ Refer to the page 3-12 for setting the user Refer to the page 3-12 for setting the user mode (available on U mode only). mode (available on U mode only).
Page 142 (6) (6) Monitoring system Monitoring system Information of machine performance as moni- tored by the MCU can be displayed on the LCD. Refer to the page 3-11. (7) (7) Self diagnostic system Self diagnostic system MCU ( ( Machine achine Control ontrol Unit) nit) The MCU diagnoses machine status and prob-...
Page 143 After engine start After engine start ① When the engine is started, rpm display indi- cates low idle, 800±100 rpm. ② If coolant temperature is below 30˚C, the warm- ing up pilot lamp lights ON and after 4 seconds START the engine speed increases to 1000±100 rpm automatically to warm up the machine.
Page 144 P mode P mode The accel dial is set 10 and the auto idle mode is canceled. P mode pilot lamp Effect Engine rpm Power mode switch Approximately 120 % of 1500 ± 50 power and speed available than S mode. ※...
Page 145: Operation Of The Working Device
5. OPERATION OF WORKING DEVICE 5. OPERATION OF WORKING DEVICE Confirm the operation of control lever and Confirm the operation of control lever and working device. working device. Left control lever controls arm and swing. Right control lever controls boom and bucket. When you release the control lever, control lever returns to neutral position automatically.
Page 146: Traveling Of The Machine
6. TRAVELING OF THE MACHINE 6. TRAVELING OF THE MACHINE 1) 1) BASIC OPERATION BASIC OPERATION Traveling position (1) (1) Traveling position Traveling position It is the position which the dozer and rear axle is in the rear and the working device is forward. Travel directions will be reversed if lower Travel directions will be reversed if lower structure is positioned with dozer in front.
Page 147 Changing direction Changing direction (forward/reverse) Forward Be sure to stop the machine when changing the direction forward or backward while traveling. Put the FNR lever in the desired position to Reverse change direction. When changing direction, check beforehand When changing direction, check beforehand there is no obstacle in the direction you will there is no obstacle in the direction you will be headed.
Page 148: Parking The Machine
TRAVELING ON A SLOPE TRAVELING ON A SLOPE Never travel down a slope in neutral. Lower the bucket 20 to 30cm(1ft) to the ground so that it can be used as a brake in an emergen- If the machine starts to slide or loses stability, lower the bucket immediately and brake the machine.
Page 149: Towing The Machine
4) 4) TOWING THE MACHINE TOWING THE MACHINE Except for an emergency, do not tow this machine. If it is inevitable to tow this machine, observe the following. (1) (1) General General Parking brake cylinder of the machine is operat- ed by the spring force and released by hydraulic pressure.
Page 150 (2) (2) Towing the machine Towing the machine The emergency device is to interrupt the power flow between input and output in case of control pressure failure or a travel motor defect and thus allows an emergency towing of the machine.
Page 151: Precautions For Operation
2. After using the parking brake as an emer- After using the parking brake as an emer- gency brake, ask Hyundai dealer to check gency brake, ask Hyundai dealer to check complete brake system.
Page 152: Efficient Working Method
7. EFFICIENT WORKING METHOD 7. EFFICIENT WORKING METHOD Do the digging work by arm. Use the pulling force of arm for digging and use together with the digging force of the bucket if nec- essary. 14W74OP19 When lowering and raising the boom operate soft- Operate softy for the begining and the end ly for the beginning and the end.
Page 153 Dig slowly with keeping the angle of boom and arm, 90-110 degree when maximum digging force is required. 90~110 14W74OP23 Operate leaving a small safety margin of cylinder Margin stroke to prevent damage of cylinder when work- ing with the machine. 14W74OP24 Keep the bucket to the dumping position and the arm horizontal when dumping the soil from the...
Page 154 If the excavation is in an underground location or Incorrect in a building, make sure that there is adequate overhead clearance and that there is adequate ventilation. 14W94OP80 Do not use the dropping force of the work equip- Incorrect ment for digging. The machine can be damaged by the impact.
Page 155 Never carry out operations which may damage the machine such as overload or over-impact- load. Never travel while carrying a load. In case you need installing over load warning device for object handling procedure, please con- tact Hyundai distributor. 140W74OP30 4-21...
Page 156: Bucket With Hook
BUCKET WITH HOOK BUCKET WITH HOOK When carrying out lifting work, the special lifting hook is necessary. The following operations are prohibited. Hook Lifting loads with a wire rope fitted around the bucket teeth. Lifting loads with the wire rope wrapped directly around the boom or arm.
Page 157: Operation In The Special Work Sites
8. OPERATION IN THE SPECIAL WORK SITES 8. OPERATION IN THE SPECIAL WORK SITES OPERATION THE MACHINE IN A COLD WEATHER OPERATION THE MACHINE IN A COLD WEATHER Use proper engine oil and fuel for the weather. Fill the required amount of antifreeze in the 50 C coolant.
Page 158 SEA SHORE OPERATION SEA SHORE OPERATION Prevent ingress of salt by securely tightening plugs, cocks and bolts of each part. Wash machine after operation to remove salt residue. Pay special attention to electrical parts, and hydraulic cylinders and track tension cylinder to prevent corrosion.
Page 159: Normal Operation Of Excavator
9. NORMAL OPERATION OF EXCAVATOR 9. NORMAL OPERATION OF EXCAVATOR Followings may occur during operation due to the nature of a hydraulic excavator. When rolling in the arm, the roll-in movement stop momentary at point X X in the picture shown, then recovers speed again after passing point X X .
Page 160: Attachment Lowering
A special air bleed gas from the accumulator. A special air bleed valve is necessary for this operation, so please valve is necessary for this operation, so please contact your Hyundai distributor. contact your Hyundai distributor. 14W94OP40 4-26...
Page 161: Storage
11. STORAGE 11. STORAGE Maintain the machine taking care of following to prevent the deterioration of machine when storing the machine for a long time, over 1 month. BEFORE STORAGE BEFORE STORAGE (1) (1) Cleaning the machine Cleaning the machine Clean the machine and dried.
Page 162: During Storage
Remove the drain port plug and drain the water until the gear oil comes out and then tighten the drain plug. Refer to the service instruction, section 6 for the drain plug location. If the machine is stored without carrying out the monthly lubricating operation, consult your Hyundai dealer for service. 4-28...
Page 163: Rcv Lever Operating Pattern
3 Swing right ① 4 Swing left ④ 5 Boom lower ② 6 Boom raise Right ① 7 Bucket out Hyundai ③ 8 Bucket in ② 1 Boom lower A Type ④ 2 Boom raise Left 3 Swing right ③...
Page 164 PATTERN CHANGE VALVE INSTALL ATTERN CHANGE VALVE INSTALL (option) If the machine is equipped with the pattern change valve, the machine operation pattern can If the machine is equipped with the pattern change valve, the machine operation pattern can be easily changed. be easily changed.
Page 165: Switching Hydraulic Attachment Circuit
13. SWITCHING HYDRAULIC ATTACHMENT CIRCUIT 13. SWITCHING HYDRAULIC ATTACHMENT CIRCUIT The combined hydraulic attachment circuit is capable of providing single action or double action. The position of 3 way valve selects the single action hydraulic attachment circuit or the double action hydraulic attachment circuit.
Page 166: Transportation
TRANSPORTATION TRANSPORTATION 1. ROAD TRAVELING 1. ROAD TRAVELING As this machine can run at the maximum speed of 31 km/h, it is not necessary to transport the machine on trailer in a short distance. But the transportation by the trailer is convenient in a long distance.
Page 167: Preparation For Transportation
2. PREPARATION FOR TRANSPORTATION 2. PREPARATION FOR TRANSPORTATION When transporting the machine, observe the vari- ous road rules, road transportation vehicle laws and vehicle limit ordinances, etc. Overall width Select proper trailer after confirming the weight and dimension from the chapter 2, specification. Check the whole route such as the road width, the height of bridge and limit of weight and etc., which Overall...
Page 168: Dimension And Weight
3. DIMENSION AND WEIGHT 3. DIMENSION AND WEIGHT 1) 1) ROBEX 140W-9 ROBEX 140W-9 (1) (1) Base machine Base machine Mark Description Unit Specification Length mm (ft-in) 4410 (15' 6") Height mm (ft-in) 3140 (10' 4") Width mm (ft-in) 2500 ( 8' 2") Weight kg (lb) 11120 (24515)
Page 169 (5) (5) Boom cylinder Boom cylinder Mark Description Unit Specification Length mm (ft-in) 1760 ( 5' 9") Height mm (ft-in) 210 ( 0' 8") Width mm (ft-in) 310 ( 1' 0") Weight kg (lb) 260 (570) ※ Included piping. 13035TA06 (6) (6) Cab assembly Cab assembly...
Page 170: Loading The Machine
4. LOADING THE MACHINE 4. LOADING THE MACHINE Load and unload the machine on a flat ground. Use the gangplank with sufficient length, width, thickness and gradient. Place block tires of the truck and the trailer not to move the trailer. Place the swing lock device to the LOCK LOCK position before fixing the machine at the bed of trailer and...
Page 171 Lower the working equipment gently after the location is determined. Place rectangular timber under the bucket Place rectangular timber under the bucket cylinder to prevent the damage of it during cylinder to prevent the damage of it during transportation. transportation. Be sure to keep the travel speed switch on the Be sure to keep the travel speed switch on the low speed while loading and unloading the...
Page 172: Fixing The Machine
5. FIXING THE MACHINE 5. FIXING THE MACHINE Place the swing lock device on the LOCK position. Select switch 2 Place the select switch 2 to the parking position. Keep the safety lever on the SAFETY position. Turn OFF all the switches and remove the key. Starting switch Swing lock lever Safety lever...
Page 173: Loading And Unloading By Crane
6. LOADING AND UNLOADING BY CRANE Check the weight, length, width and height of the machine referring to the chapter 2, specification Wire rope when you are going to hoist the machine. Use long wire rope and stay to keep the distance Rubber plate with the machine as it should avoid touching with the machine.
Page 174: Maintenance
Do not allow unauthorized personnel to reset them. Ask to your local dealer or Hyundai for the main- tenance advice if unknown. Drain the used oil and coolant in a container and handle according to the method of handling for industrial waste to meet with regulations of each province or country.
Page 175: Proper Maintenance
Confirm if the cluster is in the normal condition after completion of service. For more detail information of maintenance, please contact local Hyundai dealer. Be sure to start the maintenance after fully Be sure to start the maintenance after fully understand the chapter 1, safety hints.
Page 176 RELIEVING THE PRESSURE IN THE HYDRAULIC SYSTEM RELIEVING THE PRESSURE IN THE HYDRAULIC SYSTEM Spouting of oil can cause the accident when Spouting of oil can cause the accident when loosening the cap or hose right after the oper- loosening the cap or hose right after the oper- ating of machine as the machine or oil is on ating of machine as the machine or oil is on the high pressure on the condition.
Page 177 PRECAUTION WHEN INSTALLING HYDRAULIC HOSES OR PIPES PRECAUTION WHEN INSTALLING HYDRAULIC HOSES OR PIPES Be particularly careful that the joint of hose, pipe and functioning item are not damaged. Avoid contamination. Assemble after cleaning the hose, pipe and joint of functioning item. Use genuine parts.
Page 178 6) 6) PERIODICAL REPLACEMENT OF SAFETY PARTS PERIODICAL REPLACEMENT OF SAFETY PARTS It is desirable to do periodic maintenance the machine for using the machine safely for a long time. However, recommend to replace regularly the parts related safety not only safety but maintain satisfied performance.
Page 179: Tightening Torque
2. TIGHTENING TORQUE 2. TIGHTENING TORQUE Use following table for unspecified torque. 1) 1) BOLT AND NUT BOLT AND NUT (1) (1) Coarse thread Coarse thread Bolt size kg m lb ft kg m lb ft 0.9 ~ 1.3 6.5 ~ 9.4 1.1 ~ 1.7 8.0 ~ 12.3 1.25...
Page 180 2) 2) PIPE AND HOSE PIPE AND HOSE (FLARE type) Thread size (PF) Width across flat (mm) kgf m lbf ft 1/4" 28.9 3/8" 36.2 1/2" 68.7 3/4" 130.2 1" 151.9 1-1/4" 253.2 3) 3) PIPE AND HOSE PIPE AND HOSE (ORFS type) Thread size (UNF) Width across flat (mm) kgf m...
Page 181 4) 4) TIGHTENING TORQUE OF MAJOR COMPONENT TIGHTENING TORQUE OF MAJOR COMPONENT Torque Descriptions Bolt size kgf·m lbf·ft M20 × 2.5 Engine mounting bolt (bracket-frame, FR) 55±3.5 398±25.3 M24 × 3.0 Engine mounting bolt (bracket-frame, RR) 90±7.0 651±50.6 M12 × 1.75 Engine Engine mounting bolt (engine-bracket) 10.0±1.0...
Page 182: Fuel, Coolant And Lubricants
Specification ★ Engine oil SAE 15W-40 (API CH-4), SAE 5W-40 (API CH-4) Hyundai genuine long life hydraulic oil (ISO VG 32, VG 46, VG 68 only) Hydraulic oil ★ Coventional hydraulic oil (ISO VG 15 Swing reduction gear oil SAE 85W-140 (API GL-5)
Page 183 RECOMMENDED OILS Use only oils listed below or equivalent. Do not mix different brand oil. Ambient temperature C( F) Service Capacity Kind of fluid (U.S. gal) point (-58) (-22) (-4) (14) (32) (50) (68) (86) (104) SAE 5W-40 Engine 24 (6.3) oil pan SAE 30 Engine oil...
Page 184: Maintenance Check List
4. MAINTENANCE CHECK LIST 4. MAINTENANCE CHECK LIST DAILY SERVICE BEFORE STARTING DAILY SERVICE BEFORE STARTING Check items Service Page Visual check Fuel tank Check, Refill 6-25 Hydraulic oil level Check, Add 6-30 Engine oil level Check, Add 6-18 Coolant level Check, Add 6-20 Control panel &...
Page 185: Initial 50 Hours Service
INITIAL 50 HOURS SERVICE Check items Service Page Bolts & Nuts Check, Tight Power train mounting bolts Swing motor mounting bolts Swing bearing mounting bolts Engine mounting bolts Counterweight mounting bolts Turning joint locating bolts Hydraulic pump mounting bolts EVERY 100 HOURS SERVICE Check items Service Page...
Page 186: Every 250 Hours Service
EVERY 250 HOURS SERVICE Check items Service Page Battery (voltage) Check 6-44 Aircon & heater fresh air filter Check, Clean 6-48 Front & rear axle differential gear oil Add, Lubricate 6-37 Axle planetary gear oil (front, rear) Add, Lubricate 6-37 Bolts &...
Page 187: Every 1000 Hours Service
Change oil every 600 hours of continuous hydraulic breaker operation. EVERY 5000 HOURS SERVICE Check items Service Page Hydraulic tank 6-30 Change Hyundai genuine long life hydraulic oil Change oil every 1000 hours of continuous hydraulic breaker operation. 6-14 6-14...
Page 188 WHEN REQUIRED WHEN REQUIRED Whenever you have trouble in the machine, you must perform the service of related items, system by system. Check items Service Page Fuel system ·Fuel tank Drain or Clean 6-25 ·Prefilter Clean or Replace 6-26 ·Fuel filter element Replace 6-27 Engine lubrication system...
Page 189: Maintenance Chart
5. MAINTENANCE CHART 8 19 21 1 25 26 16 14W96MA05 Caution 1. Service intervals are based on the hour meter reading. 2. The number of each item shows the lubrication point on the machine. 3. Stop engine while filling oil, and use no open flames. 4.
Page 190 29 Air cleaner element (primary) Replace ★1 ★2 Conventional hydraulic oil Hyundai genuine long life hydraulic oil ★3 Service when the grease inlet exists on the equipment ※ Oil symbol Oil symbol Please refer to the recommended lubricants for specification.
Page 191: Service Instruction
6. SERVICE INSTRUCTION 6. SERVICE INSTRUCTION 1) 1) CHECK ENGINE OIL LEVEL CHECK ENGINE OIL LEVEL Check the oil level with the machine on a flat ground before starting engine. Pull out the dipstick and wipe with a clean cloth. Check the oil level by inserting the dipstick com- pletely into the hole and pulling out again.
Page 192 Apply a light film of lubricating oil to the gasket sealing surface before installing the filters. Fill the filters with clean lubricating oil. Fill the filters with clean lubricating oil. 18036MI09 Install the filter to the filter head. Mechanical over-tightening may distort the Mechanical over-tightening may distort the threads or damage the filter element seal.
Page 193 CHECK COOLANT CHECK COOLANT Check if the level of coolant in reservoir tank is between FULL and LOW. Add the mixture of antifreeze and water after removing the cap of the reservoir tank if coolant is not sufficient. Be sure to add the coolant by opening the cap of radiator when coolant level is below LOW.
Page 194 Wait until the temperature is below Wait until the temperature is below 50 50˚C (122˚F) before removing the coolant system before removing the coolant system pressure cap. pressure cap. Failure to do so can cause personal injury Failure to do so can cause personal injury from heated coolant spray.
Page 195 Fill the cooling system with clean water. Be sure to vent the engine and aftercooler for complete filling. Do not install the radiator cap or the new coolant filter. 18036MI20 Operate the engine for 5 minutes with the cool- ant temperature above 80˚C (176˚F) . Shut the engine off, and drain the cooling sys- tem.
Page 196 13036MI02 6) 6) CHECK CHARGE AIR COOLER CHECK CHARGE AIR COOLER Inspect the charge air cooler for dirt and debris blocking the fins. Check for cracks, holes, or other damage. If damage is found, please contact Hyundai distributor. 14W96MA12 6-23...
Page 197 7) 7) FAN BELT TENSION FAN BELT TENSION Measure the belt deflection at the longest span of the belt. Maximum deflection : 9.5 - 12.7 mm (3/8 to 1/2 inch) 18036MI25 Inspect the drive for damage. NOT OK 13036MI03 Inspect the drive belt, tension bearing and fan hub.
Page 198 9) 9) CLEANING OF AIR CLEANER CLEANING OF AIR CLEANER (1) (1) Primary element Primary element Loosen the clamps and remove the element. Clamp Clean the inside of the body. Clean the element with pressurized air. Remove the dust inside of the element by the pressurized air (below 3 kgf/cm , 40 psi) for- ward and backward equally.
Page 199 PREFILTER PREFILTER Inspect or drain the collection bowl of water Inspect or drain the collection bowl of water daily and replace the element every 500hours. daily and replace the element every 500hours. (1) (1) Drain water Drain water Open bowl drain valve to evacuate water. Close drain valve.
Page 200: Bleeding The Fuel System
REPLACEMENT OF FUEL FILTER REPLACEMENT OF FUEL FILTER Clean around the filter head, remove the filter and clean the gasket surface. Wrench size : 90~95 mm (3.5~3.8 in) Replace the O-ring. Apply engine oil on the gasket of new filter when mounting, and tighten 3/4 to 1 turn more after Cartridge the gasket touches the filter head.
Page 201 BELT TENSIONER, AUTOMATIC ADJUSTMENT BELT TENSIONER, AUTOMATIC ADJUSTMENT Every 1000hours, or 1 year, whichever occurs first, inspect the automatic belt tensioner. With the engine turned off, check that neither the top nor bottom tensioner arm stop is touching the cast boss on the tensioner body. If either of the stops is touching a boss, the alternator belt must be replaced.
Page 202 A worn tensioner that has play in it or a belt that “walks” off its pulley possibly indicates pulley misalignment. Maximum pulley misalignment is three Maximum pulley misalignment is three degrees. This measurement can be taken degrees. This measurement can be taken with a straightedge and an inclinometer.
Page 203 HYDRAULIC OIL CHECK HYDRAULIC OIL CHECK Red line Stop the engine after retract the arm and bucket cylinders, then lower the boom and set the buck- et on the ground at a flat location as in the illus- Level gauge tration.
Page 204 CLEAN SUCTION STRAINER CLEAN SUCTION STRAINER Clean suction strainer as follows paying attention to the cause to be kept during oil filling. Air breather Remove the cover on the top of the oil tank. Cover Tightening torque : 6.9 1.4 kgf m O-ring (50 10 lbf ft) Pull out the strainer in the tank.
Page 205 REPLACEMENT OF ELEMENT IN HYDRAULIC REPLACEMENT OF ELEMENT IN HYDRAULIC TANK BREATHER TANK BREATHER Cover Loosen the cap and relieve the pressure in the Element tank by pushing the top of the air breather. Loosen the lock nut and remove the cover. Pull out the filter element.
Page 206: Reduction Gear
CHECK THE SWING REDUCTION GEAR OIL CHECK THE SWING REDUCTION GEAR OIL Pull out the dipstick and clean it. Insert it again. Pull out one more time to check the oil level and fill the oil if the level is not sufficient. 14W96MA30 CHANGE SWING REDUCTION GEAR OIL CHANGE SWING REDUCTION GEAR OIL...
Page 207 SWING GEAR AND PINION SWING GEAR AND PINION REAR (1) (1) Drain old grease Drain old grease ① Remove under cover of lower frame. ② Remove drain cover of lower frame. ③ Remove filler cover of upper frame. ④ Operate full turn (360˚) of swing several times. Top of FRONT lower frame...
Page 208 (2) (2) Axle Axle Front axle Front axle : 1 point 14W96MA37 (3) (3) Steering case Steering case : 4 point Front axle 14W96MA38 (4) (4) Outrigger Outrigger : 8 point 20W36MI04 (5) (5) Dozer blade Dozer blade : 12 point 17W76MI23 6-35...
Page 209 TIRE TIRE Air pressure Air pressure (1) (1) It is important to keep air pressure properly for maximizing tire life. Both excessive and insuffi- cient air pressure of tires should be avoided not to damage tires. Specification : 7.0 kgf/cm (100 psi) (2) (2) Handling of tire...
Page 210 CHECK AND SUPPLYING PLANETARY GEAR CHECK AND SUPPLYING PLANETARY GEAR Planetary gear Move the machine to flat ground. Remove the plug and check the oil amount. Set the oil level check line of planetary gear in Set the oil level check line of planetary gear in parallel to the around.
Page 211 CHANGE THE AXLE OIL CHANGE THE AXLE OIL Air breather Place a drain box under drain plug to catch oil. Differential gear Remove the air breather to relieve internal pres- sure. Filling plug Drain oil the differential gear Drain oil the differential gear (3) (3) Remove the filling plug and remove the drain plug to drain oil off.
Page 212 CHECK AND SUPPLYING TRANSMISSION CHECK AND SUPPLYING TRANSMISSION Clutch disc Brake disc breather breather Move the machine to flat ground. Brake breather Open the transmission air breather to relieve internal air pressure. Clutch breather Remove the plug and check the oil amount. If the oil level is at the hole of the plug, it is nor- Emergency device breather...
Page 213 REPLACEMENT OF BUCKET REPLACEMENT OF BUCKET When knocking the pin in with a hammer, When knocking the pin in with a hammer, metal particles may fly and cause serious metal particles may fly and cause serious injury, particularly if they get into your eyes. injury, particularly if they get into your eyes.
Page 214 REPLACEMENT OF BUCKET TOOTH REPLACEMENT OF BUCKET TOOTH (1) (1) Timing of replacement Timing of replacement Check wearing condition as shown in the illus- tration and replace tooth tip before adapter Tooth adapter Tooth tip starts to wear. If excessive use, tooth adapter has worn out, replacement may become impossible.
Page 215 ADJUSTMENT OF BUCKET CLEARANCE ADJUSTMENT OF BUCKET CLEARANCE Lower the bucket on the ground as the picture shown in the right. Swing to the left and keep the arm boss to be contact to the bucket left. Lock the safety lever to the LOCK position and stop the engine.
Page 216 LUBRICATE PIN AND BUSHING LUBRICATE PIN AND BUSHING (1) (1) Lubricate to each pin of working device Lubricate to each pin of working device Lubricate the grease to the grease nipple according to the lubricating interval. Description Lubrication manifold at boom Boom cylinder pin Boom and arm connection pin Arm cylinder pin (Rod side)
Page 217: Electrical System
7. ELECTRICAL SYSTEM 7. ELECTRICAL SYSTEM 1) 1) WIRING, GAUGES WIRING, GAUGES Check regularly and repair loose or malfunctioning gauges when found. 13036MI29 2) 2) BATTERY BATTERY (1) (1) Clean Clean Wash the terminal with hot water if it is contami- nated, and apply grease to the terminals after washing.
Page 218 STARTING THE ENGINE WITH A BOOSTER CABLE STARTING THE ENGINE WITH A BOOSTER CABLE Keep following order when you are going to start engine using booster cable. (1) (1) Connection of booster cable Connection of booster cable Connection of booster cable Use the same capacity of battery for starting.
Page 219 Welding repair Welding repair Before start to welding, follow the below proce- dure. Shut off the engine and remove the starting switch. Fuel tank Disconnect ground cable from battery by mas- Master switch ter switch. Before carrying out any electric welding on the machine, the battery cables should be discon- DISCONNECT SWITCH nected and the connectors pulled out of the...
Page 220: Air Conditioner And Heater
8. AIR CONDITIONER AND HEATER 8. AIR CONDITIONER AND HEATER CLEAN AND REPLACE OF CLEAN AND REPLACE OF FRESH AIR FRESH AIR FILTER FILTER 1) 1) Always stop the engine before servicing. Always stop the engine before servicing. Open the LH side cover. LH side cover 14W96MA40 Remove the fresh air filter.
Page 221 Remove recirculation filter. Recirculation filter 14W96MA43 Clean the recirculation filter using a pressurized air (b b elow 2 kgf/cm , 28 psi) or washing with water. When using pressurized air, be sure to wear When using pressurized air, be sure to wear safety glasses.
Page 222: Troubleshooting Guide
TROUBLESHOOTING GUIDE TROUBLESHOOTING GUIDE 1. ENGINE 1. ENGINE This guide is not intended to cover every conditions, however many of the more common possibil- This guide is not intended to cover every conditions, however many of the more common possibil- ities are listed.
Page 223: Electrical System
2. ELECTRICAL SYSTEM 2. ELECTRICAL SYSTEM Trouble Service Remark Lamp does not glow brightly even Check for loose terminals and open-circuit wiring. when engine runs at high speed. Adjust belt tension. Lamp flickers while engine runs. Battery charging lamp does not Check the alternator.
Page 224: Others
3. OTHERS 3. OTHERS Trouble Service Remark Bucket either rises slowly or not at Add oil to specified level. all. Slow speed of travel, swing, Add oil to specified level. boom, arm and bucket. Unusual noise emitted from pump. Clean the hydraulic tank strainer. Excessive oil temperature rise of Clean the oil cooler.
Page 225: Hydraulic Breaker And Quick Clamp
Become familiar with the manual and select breakers suitable to machine specifications. Make careful selection in consideration of oil quantity, pressure and striking force, to enable satisfied performance. When apply a breaker to the machine, con- sult your local dealer of Hyundai for further explanation.
Page 226: Circuit Configuration
One of spool of the main control valve should be connected to the tank. Select the size of pipe laying considering the back pressure. Shimless tube should be used for the piping. The hose and seal should be used Hyundai genuine parts.
Page 227: Maintenance
★1 : Conventional hydraulic oil Inspect and maintain hydraulic oil and 3 kinds of ★2 : Hyundai genuine long life hydraulic oil filter elements in particular, in order to prolong Replace following filter same time Replace following filter same time machine life.
Page 228: Precaution While Operating The Breaker
4. PRECAUTIONS WHILE OPERATING THE BREAKER 4. PRECAUTIONS WHILE OPERATING THE BREAKER DO NOT BREAK ROCK WHILE LOWERING DO NOT BREAK ROCK WHILE LOWERING Incorrect Incorrect As the breaker is heavy in comparison with buck- et, it must be operated slowly. If breaker is rapidly pushed down, working device may be damaged.
Page 229 DO NOT CONTINUE TO WORKING OVER DO NOT CONTINUE TO WORKING OVER Incorrect Incorrect ONE MINUTE AT SAME POSITION OF BOOM ONE MINUTE AT SAME POSITION OF BOOM For one AND ARM AND ARM minute This will increase the temperature of the oil, and cause problem in the accumulator and seals.
Page 230: Quick Clamp
5. QUICK CLAMP 5. QUICK CLAMP 1) 1) FIXING BUCKET WITH QUICK CLAMP FIXING BUCKET WITH QUICK CLAMP Quick clamp switch Before fixing bucket, remove safety pin of the moving hook. Safety button Pulling safety button, press the quick clamp switch to unlock position. Then, the moving hook is placed on release posi- tion.
Page 231 HYUNDAI will not be responsible for HYUNDAI will not be responsible for any injury or damage in case that safe- any injury or damage in case that safe- ty pin is not installed properly.
Page 232: Index
INDEX INDEX Fuel leakage --------------------------------------------------- 6-29 Fuel system bleeding -------------------------------------- 6-27 Accel dial switch ---------------------------------------------- 3-10 Fuel tank --------------------------------------------------------- 6-25 Accelator pedal ----------------------------------------------- 3-34 Fuel warmer ------------------------------------------------------ 3-9 After engine start ---------------------------------------------- 4-4 Fuse & relay box ---------------------------------------------- 3-53 Air breather element --------------------------------------- 6-32 Air cleaner filter ----------------------------------------------- 6-25 Air conditioner &...
Page 233 Quick clamp ------------------------------------------------------ 8-6 Warming up operation -------------------------------------- 4-5 Warning lamps ----------------------------------------------- 3-4,5 Weight -------------------------------------------------------------- 2-5 Radiator flushing ---------------------------------------------- 6-20 Windshield ------------------------------------------------------- 3-55 Radio & CD/MP3 player ----------------------------------- 3-47 Working device operation -------------------------------- 4-14 RCV lever lubricate ------------------------------------------ 6-34 Working method --------------------------------------------- 4-21 Recommended oils ---------------------------------- 2-14, 6-10 Working range -------------------------------------------------- 2-43 Relieving pressure --------------------------------------------- 6-3...

Save PDF
