Aircap, Nozzle and Needle Guide
Orifi ce Size
1.0 MM
1.2 MM
1.5 MM
1.8 MM
2.0 MM
2.5 MM
C.A.Technologies
Tel: 303.438.5707
337 S. Arthur Ave.
Toll: 888.820.4498
Louisville, CO 80027
Fax: 303.438.5708
www.spraycat.com
1
Air Cap Part No.
Air Cap Description
V1071136105
Air cap 1.0 mm HVLP
V1071136125
Air cap 1.2 mm HVLP
V1071136155
Air cap 1.5 mm HVLP
V1071136185
Air cap 1.8 mm HVLP
V1071136205
Air cap 2.0 mm HVLP
V1071136255
Air cap 2.5 mm HVLP
COATING EQUIPMENT TECHNOLOGY, INC
46890 Continental Drive
Chesterfield, MI 48047
United States of America
(586) 210-0555
MAVERICK
MAVERICK
The Maverick adhesive spray gun is
exclusively
sold
Equipment Technology, Inc. (CET). The
gun
utilizes
the
Xpress spray gun body and Walther
Pilot adhesive air caps, needles and
nozzles. All specifically machined for
water and solvent based materials.
Nozzle and Needle Set
V15103M0103
V15103M0123
V15103M0153
V15103M0183
V15103M0203
V15103M0253
Adhesive Spray Gun
Product Information
through
Coating
C.A. Technologies
Nozzle and Needle Set
Description
1.0 mm ADH Nozzle
Needle Set
1.2 mm ADH Nozzle
Needle Set
1.5 mm ADH Nozzle
Needle Set
1.8 mm ADH Nozzle
Needle Set
2.0 mm ADH Nozzle
Needle Set
2.5 mm ADH Nozzle
Needle Set
CAT-Xpress Part Sheet
