Using the Direct-2 output
To make the ProMS2 as flexible as possible, the DIRECT-2 output allows
you to split the signal to a third destination. It also features a ground LIFT
switch that can be effective at reducing noise caused by ground loops. If
you hear hum or buzz after connecting the DIRECT-2 output try depressing
the LIFT switch.
Using with line level source
The ProMS2 can also be used to split a balanced +4dB line-level source by
engaging the -30dB PAD at the input. This attenuates the signal from line-level
devices to match microphone signals and make them compatible with the
preamp input of mixing consoles. An application for the PAD would include
sub-mixing where the output of one console is fed into the input of another.
J-RAK 8
The optional J-RAK 8 is a 19" rack chassis that lets you mount up to eight
Radial devices in a neat 2RU rackmount package. The D.I.'s and splitters
can be mounted with either the input side or output side facing the front.
Ideal for creating high-density groups of direct boxes and mic splitters for
the studio or live touring.
J-RAK 4
The optional J-RAK 4 is a 19" rackmount chassis that lets you package
four Radial devices in one rack space (1RU). Like the J-RAK 8, the DI's
and splitters can be mounted with either the input side or output side facing
the front.
J-CLAMP
The optional J-CLAMP lets you mount
a single Radial device to virtually any
surface. It's perfect for hiding away a mic
splitter or direct box in a rack or podium
or under a table.
