  • Page 1 Mavic 3 Parachute ASTM F3322- 22...
  • Page 2 ParaZero Ltd. Any use, disclosure, reproduction or copy by any method of this document or parts thereof is not allowed, except by the prior written authorization of ParaZero, and then only to the extent authorized. version 3.34...
  • Page 3 Please fly responsibly and in accordance with the rules and regulations defined by authorities in the area where you are operating. https://parazero.com/ Visit the ParaZero website ( ) on a regular basis for the latest information and updates.

  • Page 4: Main Features

    General ParaZero’s SafeAir Mavic 3 is a low altitude, autonomous parachute-based safety system. The SafeAir Mavic 3 System Kit is compatible with the Mavic 3 series. The average measured descent rate of the Mavic with an open parachute is 4.11 meters per second (13.48 feet per second).

  • Page 5: Safety Instructions

    Safety Instructions The ParaZero SafeAir Mavic 3 is a drone safety system, designed to deploy instantaneously by using a powerful spring-based mechanism. Be careful not to lean against, press or drop the system. It is imperative to perform system updates on a regular basis through the desktop application.
  • Page 6 SafeAir System Package Content SafeAir Mavic 3 System Safety insert Placement stamp x 2 and connected safety catch USB-C cable Alcohol pad...
  • Page 7 SafeAir System Package Content DANGER stickers Remote controller...
  • Page 8 SafeAir System Ports & Switches System USB-C button port Power switch...
  • Page 9 RC 2.0 System Ports and Switche Trigger switch Belt clip Main screen Control keys Power switch Charging port...

  • Page 10: Installation Step

    Installation Step Before you start the installation, make sure to update your device using the desktop application. Place the drone with the battery facing towards you and unfold its arms Caution Follow installation instructions carefully. Systems that are not installed correctly may interfere with the spinning rotors.
  • Page 11 Installation Step Clean the upper surface of the drone, where the sticker should be placed using the alcohol pad. Remove adhesive backing and hold stamp to prepare placement. Take the placement stamp and align the stamp’s notch with the middle fin on the rear grate of the Mavic 3 (see photo).
  • Page 12 Installation Step Slide the placement stamp along the surface of the rear grate, pointed at an upward angle, being careful not to let the adhesive surface touch anything at this point. Continue sliding until you reach the end. This is the final attachment point. Press firmly down on the adhesive stamp from all surface area, being careful to create a strong bond.
  • Page 13 Installation Step Remove the safety catch from the bottom of the system and store it in a safe place for reuse during transport...
  • Page 14 Installation Step Place the harness cord under the center of the drone with the SafeAir Mavic 3 System placed upside-down to the left of the drone, while the string holder is adjacent to the drone...

  • Page 15: Installation

    Installation Step Slide the metal hook away from the base and place the SafeAir Mavic 3 System by matching the three plugs at the bottom of the system inside the corresponding sockets of the placement stamp, (See close-up on the next page)
  • Page 16 Installation Step Match plugs to sockets. Make sure both strings come out parallel from the left side after placing the system, and not caught by the placement...
  • Page 17 Installation Step Hang the harness on the metal hook and lock the handle upwards, watch your fingers while doing so...
  • Page 18 Installation Step Position the string at the bottom part of the drone as shown in the illustration to avoid sensor interference...
  • Page 19 Installation Step Gently wiggle the system to confirm that it is securely in place. If the harness cord is not tight enough, repeat the last step while placing the harness in a higher position. Caution Overtightening the harness cord might harm the system. Caution Do not lift the drone from the SafeAir System as this may cause the system to deploy unintentionally.
  • Page 20 Installation Step Place the DANGER sticker in the orientation shown below, so that it covers the ParaZero logo. Verify that the rotors can rotate freely...
  • Page 21 System Operation Step Verify that the batteries are charged before each flight. To charge the SafeAir’s battery, use the USB-C port. The minimum charging time before first flight is one hour. Batteries that are not fully charged may not Caution be able to operate towards the end of a long flight.
  • Page 22 System Operation Step Before first use, charge the RC using the provided USB cable for at least one hour. Monitor main screen’s messages to verify proper operation of the RC and SafeAir systems. Warning 1. The control keys are intended for advanced users. 2.
  • Page 23 System Operation Step Prior to takeoff, verify that the system is placed firmly in the center of the drone and that the drone’s propellers can spin freely without touching the system...
  • Page 24 System Operation Step To activate the system, verify that the system is on a level surface and turn the power switch to the ON position. If it is already ON, turn it OFF and then ON again. A starting sequence initiates, and the LED turns green and then yellow for about 20 seconds.
  • Page 25 System Operation Step The system is now ready for flight. After first installation and when required, perform Mavic compass calibration. RC link verification - press the RC trigger switch and verify that the system LED blinks in yellow and/ or blue. When releasing the button make sure it returns to solid blue.
  • Page 26 System Operation Step After landing, the system autonomously disarms, the LED turns blue a few seconds after rotors stop and two beeps will sound. Turn off the rotors and switch the SafeAir’s power switch to the OFF position before moving the drone. As a precaution, always turn the system off before Warning moving it.
  • Page 27 Deployment The SafeAir Mavic 3 includes an Autonomous Triggering System (ATS) that identifies most of the known critical failures and triggers the system autonomously. Should an emergency situation occur, the system deploys the parachute and stops the rotors. The system deploys the parachute, stops the rotors and sounds an audio-warning buzzer to alert bystanders of the falling drone.
  • Page 28 ASTM F3322-22 and are intended for flight over people, parachutes must be packed and repacked by ParaZero (or by an entity that has been certified by ParaZero). The first periodic maintenance and repack schedule is set for one year from the manufacturing date that appears on the product box.
  • Page 29 System Removal Step Unlock the harness by lowering the handle and unhook the harness from the metal hook...
  • Page 30 System Removal Step Remove the system from the drone. Insert the safety catch and store the system in a dry and clean place for reuse...
  • Page 31 SafeAir System Status and Troubleshooting System Status Corrective Action Green Power up Orange Power up Should charge battery Power up Low battery, must charge battery Steady System Yellow initialization sequence Blue Standby mode Steady Armed mode Green Steady System has Turn the power switch to the OFF position and deployed follow the repacking instructions...

  • Page 32: Other Specifications

    SafeAir System Status and Troubleshooting continued System Status Corrective Action Onboard Erase onboard storage using the storage error ParaZero Desktop Application Other Specifications Service Life (before repack required) 1 year Maximum Altitude Above Sea Level 6000 meters (19,700 feet) Maximum Speed 72 kilometers per hour (43.5 miles per...
  • Page 33 RC System Status and Troubleshooting SafeAir Mavic 3 SA Low Bat 0000.0 m...
  • Page 34 RC System Main Screen Messages Icon/Label Label Buzzer Meaning RC is charging battery Battery is at 80-100% level Battery is at 60-80% Short beep Battery is at 20-60% every 20 Battery is critically low 0-20% Signal is at 75-100% RC Signal strength Signal is at 50-75% 3 long beeps...
  • Page 35 RC System Main Screen Messages Icon/Label Label Buzzer Meaning Short beep at Systems is in Idle state, ready SafeAir power up, 2 to operate State short beeps Long beep System is armed and monitoring when system flight Chirp sound for 5 System was deployed due to freefall detection Chirp sound for 5 System was deployed due to...
  • Page 36 RC System Main Screen Messages Icon/Label Label Buzzer Meaning Auto detection and triggering SafeAir Triggering Mode Manual triggering only Battery is at 80-100% SafeAir battery level Battery is at 60-80% Battery is at 20-60% Battery is critically low 0-20% System is connected to a power source The current altitude relative Current...
  • Page 37 RC System Charging Instruction Turn the power switch off and plug the The following indication RC to a charger via the USB C cable. means low power. Charge the The main screen shows the charging RC when this indication shows. status.
  • Page 38 - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. The FCC Compliance Statement is available online at parazero.com/FCC-compliance. EU Compliance Statement The EU Declaration of Conformity is available online at parazero.com/EU-compliance...
