  • Page 1 SafeAir M-600 INSTALLATION GUIDE Supported models: SafeAir M-600 SafeAir M-600 V2 SafeAir M-600 V2 Auto-ARM...
  • Page 2: Table Of Contents

    10.5 Troubleshooting ..........................36 List of Figures Figure 1 – SafeAir M-600 System ........................4 Figure 2 – SafeAir M-600 Package Contents ....................5 List of Tables Table 1 – SafeAir M200 Package Contents ....................5 SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 3 No part of this publication may be reproduced in any form whatsoever or used to make any derivative work without prior written approval by ParaZero Drone Safety Systems. All other trademarks are the property of their respective owners. Other company and brand products and service names are trademarks or registered trademarks...
  • Page 4: Chapter 1 - Safety Instructions

    Make sure to follow the instructions relevant to your model. The ParaZero SafeAir M-600 is a safety system designed to deploy almost instantaneously, by using a special pyrotechnic mechanism, which must be handled with caution. Figure 1 – SafeAir M-600 System The system incorporates two safety elements –...
  • Page 5: Chapter 2 - Package Contents

    Twelve + one M3 nylock nuts to connect the TerminateAir electric connection to the bottom electric board Pyro-dummy (used only for troubleshooting purposes). Six + one M3\8 screws and washers for physical connection of the TerminateAir to the body of the M-600 Syringe with Loctite. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 6: Chapter 3 - Smartair Connectors Overview

    B – RC Connector C – Serial Connector D – Future Use A – SD Card Slot B – Future Use C – Parachute connector A – Buzzer connector B – USB connector C – Future Use SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 7: Chapter 4 - Installation

    Gently pull it upwards along the “Pull” indications stickers. Insert the long screw in order to connect the TerminateAir to the left arm, and close it firmly at the bottom using the provided toolset. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 8 VOUT and connect accordingly: Red wire to the VOUT (+), and black wire to the GND (-). Failing to do so, may create a short circuit in the power supply and damage the drone. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 9 Make sure to pull the landing gear power cable through the plastic cover as shown, and make sure that the TerminateAir cable comes out through the corner of the cover pointing the M5 arm. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 10: Connecting The Rc Cable To The Pwm Channels In The Ap (Some Models)

    ARM connector (Fx), and the Fire (triggering) connector (Fy). Pull the back of the cable alongside the cable of the left GPS antenna (left relative to single antenna when looking towards the two antennas). Close the plastic cover. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 11: Connecting The Parachute System To The Drone

    SafeAir M-600 v2 legs. Connect all 4 legs to the main plate of the drone, each with 3 screws. Before screwing them, apply some Loctite to the screws. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 12: Connecting The Power Cable And The Rc Cable To The Smartair (Some Models)

    SmartAir. Proper connection of the power cable/ RC cable is demonstrated in the photo Improper connection of the power cable Warning could result in detachment during the flight, which would result in a drone crash. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 13: Connecting The Power Cable To The Smartair (Some Models)

    Proper connection of the power cable is demonstrated in the photo. Improper connection of the power cable Warning could result in detachment during the flight, which would result in a drone crash. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 14: Configuring The Dji M-600 Rc Extension (Some Models)

    SafeAir M-600 model + SafeAir M-600 V2 model 4.6 Configuring the DJI M-600 RC extension Connect the drone and open DJI Assistant 2 Select DJI M-600 Pro and proceed to the next screen SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 15 Important notice: make sure to activate the “Rev” checkbox on the Fire channel. At the end of the installation, both slider indicators (blue bars) should be on the left side. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 16: Chapter 5 - System Led Indications (Safeair M-600 V2 Auto-Arm Model)

     Verify that the parachute connector is connected correctly. See SmartAir’s back side socket c on SmartAir Connectors Overview chapter Otherwise contact Parazero for  further instructions  Power down the system  Power down the system After arming: System deployed ...
  • Page 17: Chapter 6 - Operating Guidelines (Safeair M-600 V2 Auto-Arm Model)

    After the pin is secure, place the safety cover over the parachute system. Caution It is advisable to insert the safety pin back, before turning the drone’s power off. This will prevent unintentional parachute deployment SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 18: Troubleshooting

    Verify that the parachute connector is connected correctly. See SmartAir’s back side socket c on SmartAir Connectors Overview chapter.  If the problem persists, contact Parazero for further instructions. System powers up and stays on yellow LED blinking once ...
  • Page 19: Chapter 7 - System Activation (Safeair M-600 V2 Model)

    Verify that the parachute connector is connected correctly. See SmartAir’s back side socket c on SmartAir Connectors Overview chapter  Otherwise contact Parazero for further instructions  Power down the system  Power down the system After arming: System deployed ...
  • Page 20 The DJI M-600 system LED may show a RED light. In this case, you should unlock using the DJI assistant application BLUE LED light will appear on the SmartAir and a short beep sound will be heard. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 21 Wait 3 seconds, and then move the switch back down. Verify that the LED turns BLUE. Now the system is installed and ready for operation. Now the system is installed, and you are ready for operation! SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 22: The First Flight

    Remove the safety cover. Remove the Safety Pin. Turn the drone’s power on, and keep a 5-meter safety distance. Wait about 30 seconds. BLUE LED light appears on the SmartAir. A short beep will be heard. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 23 M-600 landing gear. Using the DJI remote: Pull both sticks towards the center OR use the landing gear switch to lower the legs. Both options are fully functional after the flight termination system cuts the motor power SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 24 After the pin is secure, place the safety cover over the parachute system. Caution It is advisable to insert the safety pin back, before turning the drone’s power off. This will prevent unintentional parachute deployment SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 25: Chapter 8 - Operating Guidelines (Safeair M-600 V2 Model)

    Verify that the LED on the SmartAir turns GREEN, followed by a long beep.  Important notice: The system will not arm if the Fire channel is activated. Make sure the Fire switch is in its safe position and repeat the sequence. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 26: Before Landing

    After the pin is secure, place the safety cover over the parachute system. Caution drone It is advisable to insert the safety pin back, before turning the ’s power off. This will prevent unintentional parachute deployment SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 27: Troubleshooting

    Verify that the parachute connector is connected correctly. See SmartAir’s back side socket c on SmartAir Connectors Overview chapter.  If the problem persists, contact Parazero for further instructions. System powers up and stays on yellow LED blinking once ...
  • Page 28: Chapter 9 - System Activation (Safeair M-600 Model)

    Verify that the parachute connector is connected correctly. See SmartAir’s back side socket c on SmartAir Connectors Overview chapter  Otherwise contact Parazero for further instructions  Power down the system  Power down the system After arming: System deployed ...
  • Page 29 The DJI M-600 system LED may show a RED light. In this case, you should unlock using the DJI assistant application BLUE LED light will appear on the SmartAir and a beep sound will be heard. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 30 Wait 3 seconds, and then move the switch back down. Verify that the LED turns BLUE. Now the system is installed and ready for operation. Now the system is installed, and you are ready for operation! SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 31: The First Flight

    Remove the safety cover. Remove the Safety Pin. Turn the drone’s power on, and keep a 5-meter safety distance. Wait about 5 seconds. BLUE LED light appears on the SmartAir. A beep will be heard. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 32 M-600 landing gear. Using the DJI remote: Pull both sticks towards the center OR use the landing gear switch to lower the legs. Both options are fully functional after the flight termination system cuts the motor power SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 33 After the pin is secure, place the safety cover over the parachute system. Caution drone It is advisable to insert the safety pin back, before turning the ’s power off. This will prevent unintentional parachute deployment SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 34: Chapter 10 - Operating Guidelines (Safeair M-600 Model)

    Verify that the LED on the SmartAir turns GREEN, followed by a beep.  Important notice: The system will not arm if the Fire channel is activated. Make sure the Fire switch is in its safe position and repeat the sequence. SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 35: Before Landing

    After the pin is secure, place the safety cover over the parachute system. Caution drone It is advisable to insert the safety pin back, before turning the ’s power off. This will prevent unintentional parachute deployment SafeAir™ M-600 Installation Guide www.parazero.com...
  • Page 36: Troubleshooting

     Check that the safety pin is removed, and perform a power cycle.  If the problem persists, contact Parazero for further instructions. System powers up and stays on yellow LED  Check that both RC channels are in their safe (deactivated) position.
  • Page 37 Operate Drones Everywhere, Safely Tel – +972-36885252 30 Dov Hoz Kiryat Ono, Israel 5555626 www.parazero.com...
