Summary of Contents for SAN HIMA SH-1N8/N12-CON
- Page 2 At San Hima, we have wild souls and we are committed to providing products that are tough enough to take on any adventures and at the same time, making them safe and easy to use.
-
Page 3: Warning And Safety Instructions
The Mgroup Light App allows modifications to the system functionality of your SAN HIMA Bluetooth Switch Panel. Only use this app if you have thoroughly read and understood all the instructions in this manual. - Page 4 Avoid operating the Bluetooth Switch Panel or Mobile Application under the influence of alcohol or drugs to prevent personal injury or property damage. Never alter or disassemble the system. All services or repairs must be done by SAN HIMA to avoid the risk of electric shock, fire, or voiding the warranty.
-
Page 5: What's Included
WHAT'S INCLUDED PARTS LIST 1 PC(s) SAN HIMA Bluetooth 8/12 Gang Switch 2 PC(s) M6 x 16mm Cross Head Screws Panel 2 PC(s) M5 x 10mm Hex Socket Screws 1 PC(s) Control Box 2 PC(s) M5 x 10mm Cross Head Screws... -
Page 6: Product Features
PRODUCT FEATURES Control up to 8 or 12 circuits effortlessly using the Switch Panel or Bluetooth app. Enjoy a dynamic switch panel experience with RGB color-changeable backlight. 5-level brightness control Personalize your Switch Panel with 140 graphic labels for a unique touch. System voltage: 12V/24V DC. - Page 7 125mm Switch Panel 8 Gang 72mm 125mm 165mm Switch Panel 12 Gang 125mm 90mm 125mm 165mm...
-
Page 8: Control Box Installation
CONTROL BOX INSTALLATION Use supplied (2x) M6x16mm cross head bolt(①), washers(⑧) and nuts(⑦) to secure bracket to fix Control Box to bracket. Method ① Align the bracket with Tighten the screws. Installation completed. the screw holes. Method ② Align the bracket with Tighten the screws. - Page 9 SWITCH PANEL INSTALLATION Use supplied (2x）M3x6mm cross head bolt to fix Switch Panel to bracket. Method ① Align the bracket with Tighten the cross head Installation completed. the screw holes. screws.
- Page 10 Method ② 1. Screw part of bracket to back of Switch Panel as shown with the (4x）M3x6mm cross head screws(⑥or⑨). 2. Use the supplied Allen key tool and (2x）M5x10mm cross head bolt(③) or (2x） M5x10mm hex socket bolt(②) to attach the two parts of the adjustable bracket together. 3.
-
Page 11: Wiring Installation
WIRING INSTALLATION Caution: Before powering on the Switch Panel, make sure that all power cables are correctly wired according to the provided instructions, and all connections are securely fastened. For optimal performance, install the circuit breaker in close proximity to the battery, using the shortest cable length possible. - Page 12 WIRING INSTALLATION 12 Gang Wiring Diagram: The Control box switch offers two power sources: connecting to ACC or directly to the battey. It is recommended to draw power directly from the battery. The Switch Panel control system features twelve switched circuits, each with a maximum current rating.
-
Page 13: Wiring Method
Wiring Method: Connect the circuit breaker to the positive terminal of the battery. Connect the negative terminal to the control box's negative terminal. Connect the ACC to the control box. Connect the control box to the switch panel. Connect the light to the control box, and negative wires can be connected to the common cathode. - Page 14 SWITCH MODE PROGRAMING 1. CONSTANT LIGHT: Default Constant Light No Setup Needed 2. MOMENTARY MODE: Press the ON/OFF button again Press the button you want to Long press the brightness button for to exit the setting mode. set, followed by pressing the 1 second.
-
Page 15: Button Introduction
Button Introduction: ON/OFF It has memory function that automatically retains the last setting. 1.Short Press - 5-level brightness adjustment(100%, 75%, 50%, 25%, 10%) Each press toggles the brightness to a different level. 2.Long Press - Enter the setting mode, and choose between momentary mode and strobe mode. -
Page 16: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Q1: What's the maximum operating current? A1: The 8 Gang Switch Panel is rated at 60A, and the 12 Gang Switch Panel is rated at 80A. Q2: If it’s connected to the battery and the power indicator stays on, will it drain the battery? A2: No, it won't. -
Page 17: App Introduction
SMART PHONE CONTROL AVAILABLE App Introduction The Mgroup Light App supports both BLE and SPP Bluetooth protocols, enabling seamless connectivity. With Bluetooth connection, you can effortlessly control and personalize Smart LED Lighting products featuring RGBW multi-colors, creating amazing atmospheres. Ideal for automotive and various applications. -
Page 18: How To Use
3. How to Use:... - Page 22 Reasons for Bluetooth connection failures Situation 1 : The Bluetooth device signal is not detectable within the app. 1. Verify the correct installation by checking the line fuse. The indicator should be illuminated under normal power-on conditions. 2. Ensure that the search is conducted within a 15-meter radius of the phone's wireless range in an open environment.
- Page 23 Individuals under the influence of alcohol or drugs, lacking experience, or lacking professional knowledge are prohibited from using this unit. Avoid using or storing this VSR near heat sources, open flames, or exposure to flammable chemicals, vapors, or corrosive gases. Avoid disassembling the charger, as this may not only cause potential harm to you and the unit but also void the warranty.
-
Page 24: Warranty
Hima switch panel that is correctly installed on the vehicle for which it is intended. San Hima will either replace the product or provide you with a refund at our discretion provided that the fault is found to have been caused by a design or manufacturing defect that results in its failure to perform correctly as described.
