Joie savvy, savvy air Manual

Child Usage Requirements

This carrier is suitable for use with children who meet the following requirements:
Weight: 8 lb. up to 33 lb. (3.5 kg up to 15 kg)
Height: at least 20 in. (51 cm)

Parts List

Please make sure there are no missing parts. Some features may vary depending on model. Please contact Joie Consumer Service if anything is missing.

1. Magnetic Shoulder Buckles
2. Magnetic Shoulder Buckle Release Buttons
3. Head Support
4. Head Support Buttons
5. Leg Opening Adjustment Buttons
6. Leg Buckles
7. Newborn Seat Adjustment Button Hooks
8. Privacy Shield and Sun Protection Pocket
9. Newborn Seat Adjustment Buttons
10. All-Season Shield Pocket
11. Privacy Shield and Sun Protection Snaps
12. Shoulder Strap Adjustment Buckle
13. Shoulder Strap Adjustment Sliders
14. Shoulder Length Adjustment Straps
15. Lumbar Support Buckle
16. Bib (x2)
17. Harness Covers (x2)

Usage Modes

This carrier has four usage modes. To ensure the safety of your child, please follow the age and weight requirements along with the use instructions for each mode.

DO NOT use carrier for newborns under 8 lb. (3.5 kg) or 20 in. (51 cm).

Ergonomic Child Positioning

Hip-Healthy
For hip-healthy baby-wearing, baby's thighs should be supported from the hip to the knee joint. This ergonomic "M-shaped" seating reduces forces on the hip joint. Never force baby's legs into a position that is not easily achieved. (See figures. 11, 20, 28, or 39 for more details.)

Spine-Healthy
For spine-healthy baby-wearing, proper support is needed.
The baby's spine should be allowed to naturally form a "C" shape. Never force baby into a position that is not easily achieved.

Newborn Mode with Integrated Newborn Seat

Birth up to 4 months • 8 lb. up to 14 lb. (3.5 kg up to 6.5 kg) • at least 20 in. (51 cm)

Child should be positioned close to you and high on your body.
Keep your child's face visible to you at all times.
Use head support for children weighing 8-14 lb. (3.5-6.5 kg).
Your baby's head should be supported until he or she has a strong head control (approximately 4 months of age).
Leg opening adjustment buttons MUST be used for children less than 15 lb. (7 kg) to decrease the size of the leg opening and prevent sliding without pinching or chafing your child's leg.

Loop newborn seat adjustment button hooks around the newborn seat adjustment buttons.

Fasten leg opening adjustment buttons to the smallest comfortable size.

Fasten the two upper head support buttons to use the head support.

Put your head through the opening with the shoulder strap adjustment buckle (A) landing on your back. Adjust the buckle, shoulder strap adjustment sliders (B), and shoulder length adjustment straps (C) to a comfortable position.

Tip
Have a second person assist for easier adjustments.

Fasten the lumbar support buckle and adjust to fit snugly around your waist.

Place child in the carrier and hold snugly against you with one hand. Use your other hand to fasten the magnetic shoulder buckles, one at a time.

Tip
It is recommended to sit while securing your child in the carrier as it provides better control.

Fasten the leg buckles and adjust to the appropriate size.

Optional: roll up the unused length of the adjustment straps. Secure the roll by wrapping the small elastic loop around it.

For smaller children, tighten the straps so the child is positioned at a height that makes it possible to kiss the top of their head.

Carrier is ready to use in newborn mode with integrated newborn seat. Make sure that the child's legs fall in the "M-shaped" position as recommended by The International Hip Dysplasia Institute.

When removing child, unfasten the magnetic shoulder buckles, one at a time, while holding child snugly against you. Push the magnetic shoulder buckle release button (D) while pulling the buckle away (E).

DO NOT remove the carrier while your child is in it.

Infant Facing-In Mode

4+ months • 14 lb. up to 30 lb. (6.5 kg up to 14 kg)

Leg opening adjustment buttons MUST be used for children less than 15 lb. (7 kg) to decrease the size of the leg opening and prevent sliding without pinching or chafing your child's leg.

Newborn seat adjustment buttons are not required for infant facing-in mode.

Put your head through the opening with the shoulder strap adjustment buckle (A) landing on your back. Adjust the buckle, shoulder strap adjustment sliders (B), and shoulder length adjustment straps (C) to a comfortable position.

Tip
Have a second person assist for easier adjustments.

Fasten the lumbar support buckle and adjust to fit snugly around your waist.

Place child in the carrier, facing towards you, and hold snugly against you with one hand. Use your other hand to fasten the magnetic shoulder buckles, one at a time.

Tip
It is recommended to sit while securing your child in the carrier as it provides better control.

Fasten the leg buckles and adjust to the appropriate size.

Optional: roll up the unused length of the adjustment straps. Secure the roll by wrapping the small elastic loop around it.

For smaller children, tighten the straps so the child is positioned at a height that makes it possible to kiss the top of their head.

Carrier is ready to use in infant facing-in mode. Make sure that the child's legs fall in the "M-shaped" position as recommended by The International Hip Dysplasia Institute.

When removing child, unfasten the magnetic shoulder buckles, one at a time, while holding child snugly against you. Push the magnetic shoulder buckle release button (D) while pulling the buckle away (E).

DO NOT remove the carrier while your child is in it.

Infant Facing-Out Mode

6+ months • 19 lb. up to 30 lb. (9 kg up to 14 kg)
Newborn seat adjustment buttons are not required for infant facing-out mode.

Put your head through the opening with the shoulder strap adjustment buckle (A) landing on your back. Adjust the buckle, shoulder strap adjustment sliders (B), and shoulder length adjustment straps (C) to a comfortable position.

Tip
Have a second person assist for easier adjustments.

Fasten the lumbar support buckle and adjust to fit snugly around your waist.

Place child in the carrier, facing away from you, and hold snugly against you with one hand. Use your other hand to fasten the magnetic shoulder buckles, one at a time.

Tip
It is recommended to sit while securing your child in the carrier as it provides better control.

Fasten the leg buckles and adjust to the appropriate size.

Optional: roll up the unused length of the adjustment straps. Secure the roll by wrapping the small elastic loop around it.

Carrier is ready to use in infant facing-out mode. Make sure that the child's legs fall in the "M-shaped" position as recommended by The International Hip Dysplasia Institute.

When removing child, unfasten the magnetic shoulder buckles, one at a time, while holding child snugly against you. Push the magnetic shoulder buckle release button (D) while pulling the buckle away (E).

DO NOT remove the carrier while your child is in it.

Infant Back Carry Mode

9+ months • 25 lb. up to 33 lb. (11 kg up to 15 kg)

It is recommended to practice the back carry mode steps a few times without a child in the carrier before attempting it with a child.
Child should NEVER be facing out in back carry mode.

Start with your child in the carrier facing in and properly restrained.

One at a time, loosen both shoulder straps.

With your left hand cradling the child, slide your right arm out of the shoulder strap.

Slide your left arm under the left shoulder length adjustment strap.

Carrier should be hung by one strap over the left shoulder with child secured with your right hand against your right hip. With your right hand securing the child to your hip, use your left hand to slide the waist band and shoulder straps around.

Hold child against your back with your left hand and loop your right arm through the right shoulder strap.

Hold child with right arm and loop your left arm through left shoulder strap.

Pull down on the shoulder length adjustment straps to tighten for a snug fit.

Adjust the shoulder strap adjustment buckle for a snug fit.

CHECK that all buckles and snaps are fastened for a secure and safe fit. Carrier is ready to use in back carry mode. Make sure that the child's legs fall in the "M-shaped" position as recommended by The International Hip Dysplasia Institute.

Optional: roll up the unused length of the adjustment straps. Secure the roll by wrapping the small elastic loop around it.

When removing child, reverse the steps for back carry mode so child is back in front of you. Unfasten the magnetic shoulder buckles, one at a time, while holding child snugly against you. Push the magnetic shoulder buckle release button (A) while pulling the buckle away (B).

DO NOT remove the carrier while your child is in it.

Using Privacy Shield & Sun Protection

Ensure that the privacy shield is not covering the child's mouth or secured too tightly over their head.
Make sure the head support is fully fastened and pull the privacy shield/sun protection out of the pocket on the top of the head support flap.

Fasten the privacy shield/sun protection straps to the snaps on the shoulder straps.

Privacy shield/sun protection can be adjusted to the appropriate fit by attaching it with a different snap located on the privacy shield/sun protection.

Using All-Season Shield

Unroll the all-season shield from the pocket at the bottom of the carrier.

Attach the all-season shield by fastening it to the head support buttons. Fasten it to the two upper buttons for a smaller baby.

Fasten it to the two lower buttons for a larger baby.

Using Bib

Before using the bib, make sure that the head support is folded down and secured into place with the lower head support buttons.
Store the extra length of the shoulder adjustment buckle in the pocket on the shoulder buckle strap.

Cover the front of the head support with the bib by attaching it to the two head support buttons.

Wrap the top flaps of the bib around both shoulder buckle straps and fasten the hook and loop fasteners.

The bib is fully attached and ready for use.

Using Harness Covers

Before using the harness covers, make sure that the head support is folded down and secured into place with the lower head support buttons.
Store the extra length of the shoulder adjustment buckle in the pocket on the shoulder buckle strap.

Wrap the harness covers around the shoulder buckle straps, securing them to the top head support buttons. Attach the hook and loop fasteners.

Harness covers are fully attached and ready for use.

Care & Maintenance

Cleaning:
Refer to the care tag attached to carrier fabric for wash and dry instructions. Carrier MUST be washed inside a mesh laundry bag.
DO NOT use bleach.

Maintenance:
It is normal for fabric to fade from sunlight and to show some wear after a long period of use.
Check regularly that everything is functioning properly. If any parts are torn, broken, or missing, STOP using this product.
Worn parts: Replace any worn or damaged parts. Use only Joie replacement parts.
Torn material or stitching: Repair or replace torn fabric or stitching. Use only Joie replacement fabrics.

Storage:
Store carrier, harness covers, and bibs in a mesh laundry bag when not in use.

FALL AND SUFFOCATION HAZARD
FALL HAZARD - Babies can fall through a wide leg opening or out of carrier. Follow instructions for use.

• Adjust leg openings to fit baby's legs snugly.
• Before each use, make sure all buckles, fasteners, and adjustments are secure.
• Take special care when leaning or walking.
• NEVER bend at waist; bend at knees.
• Only use this carrier for babies between 8 lb. (3.5 kg) and 33 lb. (15 kg).

SUFFOCATION HAZARD - Babies under 4 months can suffocate in this product if face is pressed tight against your body.

• DO NOT strap baby too tight against your body.
• Allow room for head movement.
• Keep baby's face free from obstructions at ALL times.

Failure to follow these warnings and instructions could result in serious injury or death.

• Check to ensure all buckles, snaps, straps, and adjustments are secure before each use.
• Check for ripped seams, torn straps or fabric, and damaged fasteners before each use.
• Stop using the carrier if parts are missing or damaged.
• Baby must face towards you until they can hold their head upright.
• This baby carrier is designed for use by adults while walking, standing, or sitting only.
• This baby carrier is not suitable for use during sporting activities.
• Ensure proper placement of child in product, including leg placement.
• Make sure baby's legs are straddling the seat and their arms extend through the arm holes.
• Regularly check that your child is comfortably and securely seated in the baby carrier.
• To prevent fall hazards, ensure that your child is securely positioned in the carrier.
• Hold your baby closely at all times until all buckles are correctly attached.
• Premature infants, infants with respiratory problems, and infants under 4 months are at greatest risk of suffocation.
• When using the soft carrier, monitor your child.
• For low birth weight babies and children with medical conditions, seek advice from a health professional before using the product.
• Be aware of hazards in the domestic environment e.g. heat sources, spilling of hot drinks.
• DO NOT use this soft carrier if you use a pacemaker, as the magnetic buckles can interfere with the pacemaker.
• NEVER use a soft carrier when balance or mobility is impaired because of exercise, drowsiness, or medical conditions.
• NEVER use a soft carrier while engaging in activities such as cooking and cleaning which involve a heat source or exposure to chemicals.
• NEVER wear a soft carrier while driving or being a passenger in a motor vehicle.
• NEVER lie down or sleep with baby in the baby carrier.
• Take care when bending or leaning forward or sideways.
• Your balance may be adversely affected by your movement and that of your child.
