HiPer DSP T1/E1
Network Interface Card
Getting Started Guide
Part No. 1.024.1310-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HiPer DSP T1 and is the answer not in the manual?

Questions and answers

Summary of Contents for 3Com HiPer DSP T1

  • Page 1 HiPer DSP T1/E1 Network Interface Card Getting Started Guide Part No. 1.024.1310-02...
  • Page 2 HiPer DSP T1/E1 ® Network Interface Card Getting Started Guide http://www.3com.com/ Part No. 1.024.1310-02...
  • Page 3 3Com Corporation reserves the right to revise this documentation and to make changes in content from time 95052-8145 to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 4: Table Of Contents

    ONTENTS VERVIEW Contacting 3Com................... 1-1 Document Conventions................1-2 Product Description ................1-3 Product Compatibility ................1-3 NSTALLATION Installation Tools..................2-1 Installation Procedure ................2-1 Installing in a 45A Chassis ..............2-4 ETWORK NTERFACE ABLING Physical Interfaces .................. 3-1 Connecting to the User Interface Console Port ........3-2...
  • Page 5: Overview

    VERVIEW This chapter provides an overview of: Contacting 3Com Document conventions Product description Product compatibility Contacting 3Com Call the appropriate toll free number listed below for technical support. For European countries that do not have a toll free number listed, call +31 30 602 9900.
  • Page 6: Document Conventions

    Refer to the Total Control Hub Documentation CD-ROM for more information regarding product warranty. For information about Customer Service, including support, training, contracts, and documentation, visit our website at http://totalservice.3com.com Document These tables list conventions used throughout this guide. Conventions...
  • Page 7: Product Description

    For more information see the HiPer DSP Product Reference Guide. Product The HiPer DSP T1/E1 NIC is compatible with the HiPer DSP NAC, and will Compatibility only operate with the software found in the Total Control 3.5 release package.
  • Page 8: Installation

    NSTALLATION This chapter contains HiPer Digital Signal Processor (DSP) T1/E1 Network Interface Card (NIC) installation information. Installation Tools To install this NIC in the Total Control chassis, you need a #2 Phillips and flat-head screwdriver. Installation To install this NIC: Procedure ESD: To reduce the risk of electrostatic discharge (ESD), take proper grounding precautions before handling the NIC.
  • Page 9 2: I HAPTER NSTALLATION Use the following tables and figures to configure the jumpers. A IS LP B K O F F Jumper Function AIS T1/E1 Transmitting all Zeros. No jumper present. AIS T1 Transmitting all Ones (AIS) in T1 Mode. This is the T1 package factory setting AIS E1 Transmitting all Ones (AIS) in E1 Mode.
  • Page 10 Installation Procedure When the power is off, the NIC is in high impedance mode, which is different from the original NIC because it executed loopback mode. If you unplug and reset the NIC, be sure to unplug and reset the HiPer DSP NAC after resetting the NIC.
  • Page 11 2: I HAPTER NSTALLATION 4 Insert the NIC between the slot’s upper and lower card guides. 5 Slide the NIC into the chassis, until the front of the NIC is flush with the chassis.
  • Page 12: Installing In A 45A Chassis

    Installing In a 45 Amp Chassis 6 Use a flat-head screwdriver to tighten the screws on the front panel. 7 Cover any unused chassis slots with safety panels. 8 Install the Network Application Card (NAC) corresponding to this NIC. Refer to the NAC’s Getting Started Guide for more information. Installing In a 45 The HiPer DSP NIC and NAC are designed to function with a 70/130 Amp Amp Chassis...
  • Page 13: Network Interface Card Cabling

    HiPer Digital Signal Processor (DSP) T1/E1 Network Interface Card (NIC) and instructions for accessing the corresponding Network Application Card (NAC) through the user interface (UI). Physical Interfaces The HiPer DSP T1/E1 NIC has the following physical interfaces: Callout Number Interface Description Console Port: RJ-45 DTE port Connect to this port to access the HiPer DSP NAC’s UI.
  • Page 14: Accessing The User Interface

    3: N HAPTER ETWORK NTERFACE ABLING Accessing the User To access the UI of the corresponding NAC, connect the following cables Interface to the NIC’s console port. Callout Number Description RJ-45 connector to NIC’s console port DB-25 male connector to modem for remote operations DB-25 female-to-female null modem adapter to PC or terminal COM port...
  • Page 15: Echnical Specifications

    ECHNICAL PECIFICATIONS Certification T1 HiPer Digital EMI/RFI FCC 15A Signal Interface EN55022A Safety UL 1950 C-UL EN 60950 JATE Telco FCC 68 IC CS-03 E1 HiPer Digital EMI/RFI FCC 15A Signal Interface EN55022A AUSTEL VCCI Immunity EN 50082-1 Safety UL 1950 C-UL EN 60950 AUSTEL...
  • Page 16: Appendix A: Technical Specifications

    A: T PPENDIX ECHNICAL PECIFICATIONS Regulatory United States Compliance FCC Part 15 Compliance Statement Statements This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 17: Span 1 Port

    Interface Specifications Span 1 Port Electrical Specifications: T1/E1 Span line interface Connector: RJ-48C, 8 position modular jack Specifications: ANSI T1.408 ANSI T1.403 ITU G.736 ITU G.703 ITU G.823 ITU G.775 ETSI 300-233 ETSI 300-166 I.431/ ETSI ETS 300 011 TBR-12 Framing: T1 (CH T1 and T1/PRI Application Super Frame (SF) or D4...
  • Page 18: Current Draw

    A: T PPENDIX ECHNICAL PECIFICATIONS Current Draw +5.2 VDC @ 600mA typical maximum Typical maximum refers to the maximum current draw under most typical configurations. Environment Shipping and Storage ° ° Temperature -25 to 75 C, -13 to 167 Relative Humidity 0 to 100%, Non-condensing Operating °...
  • Page 19 3Com Corporation 5400 Bayfront Plaza P.O. Box 58145 Santa Clara, CA 95052-8145 ©1999 3Com Corporation All rights reserved Printed in the U.S.A. Part No. 1.024.1310-02...
