Summary of Contents for Pecron E3600 LFP
- Page 1 E3600 DC OUTPUT DC INPUT 12V-30A 12V~30V 32V~150V 150W(MAX) 1200W(MAX)*2 12V-5A 12V-10A AC OUTPUT - 3600W 100W USER MANUAL Please read the user manual thoroughly before using support@pecron.com...
-
Page 2: Function Introduction
RJ45 Signal Sync Interface External Grounding Port AC 100V~120V Input ⑩ ⑪ ⑫ Wireless Charger DC 12V/USB/ Wireless Switch AC 100V~120V Switch ⑬ ⑭ ⑮ DC12V XT60 Output DC12V Auxiliary Output DC12V(5525)Output ⑯ ⑰ USB-A/USB-C Ports Battery Expansion Port support@pecron.com... -
Page 3: Specifications
USB-C *2 (5V,9V,12V,20V,Max 100W)*1 XT60-F Output *1 DC 12V-30A 360W Max Cigar Port *1 DC 12V-10A DC 5525 Output *1 DC 12V-5A Wireless Charger *2 15W Max AC OUTPUT BS-U20 *4 Pure sine wave 100V~120V Rated 3600W Max TT30-R *1 support@pecron.com... - Page 4 5521 *1 12V~30V Max 7A Max 150W XT60-M *2 32V~150V Max 20A Max 1200W*2 EXTRA BATTERY PORT MJ32 *2 Cascade with max 4 pieces of EP3000-48V HOW TO USE THE E3600 LFP E3600 DC OUTPUT DC INPUT 12V-30A 12V~30V 32V~150V...
- Page 5 Remaining volume of the expansion battery pack ⑥ AC Input Equilibrium state of the ⑦ ③ DC Output main power station and expansion battery pack ⑧ AC Output ④ Disconnection of the main power station and expansion battery pack support@pecron.com...
- Page 6 (Picture 2) 1: Page up/down by clicking "∧"/"∨" on the left side. 2: Click "Time setting" to adjust the time showed as (Picture 3). (Picture 3) 3: Click "Language" to adjust language type. Showed as (Picture 4). (Picture 4) support@pecron.com...
- Page 7 2: Click "√" to reset the WIFI and enter the pairing mode showed as (Picture 6). And then search the device model through the near field on the APP. If you connect to the APP via WIFI successfully, the WIFI symbol will be displayed. (Picture 5) (Picture 6) support@pecron.com...
- Page 8 HOW TO OPERATE THE SETTING OF INPUT AND OUTPUT ? Click "Menu" showed as (Picture 1). Then click "Input Output Settings" showed as (Picture 7). (Picture 1) (Picture 7) Click each option to make the corresponding settings showed as (Picture 8). (Picture 8) support@pecron.com...
-
Page 9: Packing List
Slotted Screwdriver *1 Accessory Pouch *1 User Instruction *1 Optional product accessory (* The following accessories are not included in the standard package and can be purchased separately from PECRON) EP3000-48V 3072Wh Completed set for 30A AC cable *1 EP3000-48V... - Page 10 This UPS function only support protection for loads under 3600W(120V), we recommend that you only connect one device at a time to avoid overload and thus result in protection failure. PECRON is not responsible for any devices damage or loss of data resulting from failing to follow the instructions. E3600...
- Page 11 HOW TO CHARGE THE E3600 LFP BY AC ? A 15A and a 30A cables will come together with the power station as standard accessories. The type of the cable will be automatically detected by the power station. When you charge the power station with a 15A cable.
- Page 12 150V, otherwise, it will damage the unit! Do not wire more than two 36V solar panels in series, or more than four 18V solar panels in series. (18V/36V stands for Vmp of the solar panel) 3. If you have any questions, feel free to contact us：support@pecron.com DC INPUT E3600...
- Page 13 MC4 Solar Charging Cable *1 ※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be less than 150V, and the VMP should be greater than 32V. Use two solar panels in series to charge the E3600 LFP...
- Page 14 1200W(MAX)*2 MC4 Solar Charging Cable *1 ※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be less than 50V, and the VMP should be greater than 11V. support@pecron.com...
- Page 15 (NOTE：This parallel charging cable sold separately) ※ It is recommended to choose PECRON solar panels for optimal user experience! The VOC of a single solar panel should be less than 150V, and the VMP should be greater than 32V. support@pecron.com...
- Page 16 FAQS Q1： What kind of battery is used in E3600 LFP? How long it can last? A： E3600 LFP utilizes high quality UL certified automotive LiFePO4 battery, it can retain 80% of its original capacity at 3500 complete charge cycles.
- Page 17 Q4： Can the E3600 LFP be charged while discharging? A： Yes, E3600 LFP can run devices while it is being charged. The battery will eventually run out if the discharging is greater than the charging during the pass through charging.
- Page 18 6、 It's prohibited to be used as car jump starter, only can be used to charge the car battery. 7、 Do not use accessories or parts other than those provided by PECRON. Please visit our website www.pecron.com or reach our support team for a complete list of accessories and parts.
- Page 19 EXCLUSIONS PECRON’ s warranty does not apply to： Misused, abused, modified, damaged by accident, or used for anything other than normal consumer use as authorized in PECRON’ s current product literature. CUSTOMER SUPPORT：support@pecron.com WEBSITE：www.pecron.com PECRON.LLC support@pecron.com...
- Page 20 POWER IT POSSIBLE www.pecron.com support@pecron.com...
