PulseTech XTREME CHARGE XC450 Quick Start Manual

Features
PULSE
Patented Pulse Technology increases
the duty and life cycles of all 6V, 12V,
AGM, Wet, Gel lead-acid and LiFeP04
batteries.
DESULFATE
The unique application of patented
PULSE conditioning provided by Pulse-
Tech™ increases the performance and
life cycle of any size or type of 6V or 12V
lead-acid battery. The patented pulse
wave minimizes the size and buildup of
damaging lead sulfate crystals.
CHARGE
Xtreme Charge evaluates the battery
®
during initial connection and tests it
continually to determine the appropri-
ate charge rate based on your battery's
current capacity and condition. This
TEST step also includes a "Bad Battery"
indication if it determines the battery is
faulty and cannot be re-charged.
MAINTENANCE
The XC450 is also designed to be a
MAINTENANCE charger for any type
of 6V, 12V lead-acid or lithium battery.
Through application of our proprietary
charge algorithms and high frequen-
cy pulsing processes, your battery is
maintained safely at its proper operat-
ing voltage indefinitely. If the charger is
connected to a discharged battery, its
BULK charge capability (4 amps) will re-
charge the battery rapidly and safely so
it can be put back into service quickly.
Quick Start Guide
Quick Start Guide
CONNECTION
Connect the black battery clip to the negative (-)
battery post. Then connect the red battery clip to the
positive (+) battery post.
If the clamps are reversed, all the lights will be flash-
ing, and a warning buzzer will be initiated for you to
correct the clamp connection.
Once you've connected the battery cables properly,
you can begin the charging process. Plug Xtreme
Charge into a 120V AC power source.
BATTERY SELECTION
Once you have plugged in your unit and connected
your battery, you will select your batteries voltage
(6V or 12V) and type: STD for Flooded Lead Acid, AGM
for Absorbed Glass Mat or LiFeP04 for Lithium. Once
you have made your selection, click the Start button.
BATTERY CHARGING
OPERATION
The battery charger will test the battery for several
seconds to check the battery's current condition.
From there, the battery will select the best charging
mode for the battery at that moment. Depending on
the battery's state of health, voltage, and amperage,
you will see different light patterns that indicate
the charging mode selected for that battery. The
LED Chart on the next page shows what mode your
charger is in.
Model: XC450 Part #: 300X010
Flower Mound, TX 75028
Patent Numbers: 7,834,592B2 and
8,269,466B2 and 8,269,465B2
XTREME
CHARGE
®
XC450
300X010
pulsetech.com
