solarcentre ECO WEDGE ELITE Manual

W E
S
Ensure your solar
panel is South facing
or as near as possible
YOUR ECO WEDGE ELITE WILL NOT CHARGE CORRECTLY IF THE PANEL IS CHARGED BEHIND GLASS OR
USING ARTIFICIAL LIGHT.
Thank you for choosing the Solar Centre's Eco Wedge Elite Light. Please read these instructions carefully before using your light.
Always take care when installing your light, especially when mounting it in high places.
Installation
The Eco Wedge Elite has a powerful solar panel that charges the internal high capacity battery during the day. At night the charge in
the internal battery powers the lamp enabling it to illuminate when it detects motion. Before installing you'll need to consider the best
place for it to receive the most amount of sunlight. For the best performance install the light in a South facing location that is not
obstructed by buildings, fences, trees, sheds, bushes or the shadows that these create. Please note that a poor installation location
will drastically reduce the performance of your Eco Wedge Elite Solar Motion Light.
The Eco Wedge Elite should be installed onto a vertical surface. Use the template to mark and drill the two screw holes. Drill the
marked holes, insert wall plugs and screw the Eco Wedge Elite Solar into position.
Please note the PIR motion sensor (the white "bubble" on the front of the light unit) needs to be pointing to where you want any
motion detected to operate the light.
Using your Eco Wedge Elite
Please remove the plastic tab from the remote control battery compartment before using the remote. We recommend using the
remote to control the lamp operation and suggest doing this at night when you are familiarising yourself with the unit.
Point the remote control at the lamp unit from in front of the lamp. The remote is designed to operate up to 5m away from the lamp.
Press the ON button to turn the lamp on - it will default to mode 1 or the previously selected mode.
Press the OFF button to turn the lamp off.
Charge Indicator Lights
After pressing the ON button on the remote, during the day, you should see the yellow micro LEDs to the bottom left of the diffuser
lit up to indicate charging is taking place.
Once you have installed your light we advise switching it off for 3-5 days to allow it to charge before first use. When the unit is
switched off the yellow charge indicator lights may not illuminate, but the unit will still charge.
For customer support please contact:
The Solar Centre Ltd
Unit 5, Dencora Centre
Campfield Road
St Albans
AL1 5HN E: info@solarcentre.co.uk
ECO WEDGE ELITE
Clean your solar
panel from time
to time
o
R HS 
Made in China to Solar Centre Specification
Do NOT place your
solar panel in shaded
areas.
Do NOT charge
behind glass
