- Page 1 EN 18V Cordless Hedge Trimmer ERI1024GHT ORIGINAL INSTRUCTIONS 5059340904894 IMPORTANT - These instructions are for your safety. (UK) Please read through them thoroughly prior to handling the product and retain them for future reference. 5059340904597 (EU) MNL_ERI1024GHT_EN_V01_240705...
-
Page 2: Table Of Contents
EN Parts 01. x1 02. x1 EN You will need EN Contents Product description Safety Technical specification Before you start Functions & Settings Operation Care and maintenance Guarantee Declaration of conformity... -
Page 3: Product Description
EN Product Description Blade Battery docking port Hand guard Blade cover Front trigger 10*. Battery pack Front handle a. Battery release button Head lock button b. Power bar button Rear handle c. Power bar Rear trigger 11*. Charger NOTE: * This may not be included in the supply scope. -
Page 4: Electrical Safety
EN Safety General power machine safety warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this machine. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference The term “machine”... -
Page 5: Personal Safety
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. c) Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock. - Page 6 b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the machine.
- Page 7 Machine use and care a) Do not force the machine. Use the correct machine for your application. The correct machine will do the job better and safer at the rate for which it was designed. b) Do not use the machine if the switch does not turn it on and off.
- Page 8 performed. Use of the machine for operations different from those intended could result in a hazardous situation. h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the machine in unexpected situations.
- Page 9 f) Do not expose a battery pack or machine to fire or excessive temperature. Exposure to fire or temperature above 130°C may cause explosion. g) Follow all charging instructions and do not charge the battery pack or machine outside the temperature range specified in the instructions.
- Page 10 exposed metal parts of the hedge trimmer “live” and could give the operator an electric shock. e) Keep all parts of the body away from the blade. Do not remove cut material or hold material to be cut when blades are moving. Blades continue to move after the switch is turned off.
- Page 11 c) Never allow children to operate the hedge trimmer. d) Never remove or tamper with safety devices. Check their proper operation regularly. Never do anything to interfere with the intended function of a safety device or to reduce the protection provided by a safety device. e) Never operate the hedge trimmer without proper guards, plates, or other safety protective devices in place.
- Page 12 k) Trim only in daylight or in good artificial light. l) Remove or disconnect battery before servicing, cleaning, or removing material from the hedge trimmer. m) Do not wash with a hose; avoid getting water in motor and electrical connections. n) When servicing use only identical replacement parts listed in this manual.
- Page 13 d) After extended periods of storage, it may be necessary to charge and discharge the battery pack several times to obtain the maximum performance. e) Longer life and better performance can be obtained if the battery is charged when the air temperature is between 18°C and 24°C.
- Page 14 3. Use correct application tools for the product and ensure they in good condition. 4. Keep tight grip on the handles/grip surface. 5. Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate). 6. Plan your work schedule to spread any high vibration tool use across a longer period of time.
-
Page 15: Residual Risks
Residual risks Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: 1. Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. - Page 16 Symbols On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations. Familiarise yourself with them to reduce hazards like personal injuries and damage to property. Volt, (direct current voltage) /min or min Per minute Milliampere per hour Millimetre...
- Page 17 The product complies with the applicable Your product European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation Cordless Hedge Trimmer: ERI1024GHT ER = Brand name ( Erbauer) I = 18V Lithium-Ion 1024 = Serial number...
-
Page 18: Technical Specification
EN Technical specifications General: > Rated voltage > Rated no load speed n 2800/min > Max. cutting length 500mm > Blade length 550mm > Max. cutting capacity 25mm > Rear handle adjustment angle ±45°, 0°, ±90° > Weight (without battery pack) approx. 2.8 kg >... -
Page 19: Before You Start
The declared total vibration value(s) and the declared noise emission value(s) may also be used in a preliminary assessment of exposure. WARNING! The vibration and noise emission during actual use of the machine can differ from the declared total value depending on the ways in which the machine is used especially what kind of workpiece is processed;... - Page 20 EN Assembly WARNING! The product must be fully assembled before operation! Do not use a product that is only partly assembled or assembled with damaged parts! WARNING! Disconnect the battery pack from the machine before making any assembly, adjustments, changing accessories, or storing machine. Such preventive safety measures reduce the risk of starting the machine accidentally.
- Page 21 Battery pack power bar The Li-Ion battery pack is equipped with a power bar (10c) which is used to give an indication of the battery pack’s remaining charge. Press the power bar button (10b) to check battery charge as below. The LED will stay lit for approximately 5 seconds. 76-100% Charge 51-75% Charge 26-50% Charge...
-
Page 22: Functions & Settings
EN Functions & settings Intended use This hedge trimmer ERI1024GHT is designated with a rated voltage of 18 V . It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. - Page 23 0° +45° +90° -45° -90° To avoid accidental starting, the rear trigger (7) will be locked in OFF position if the head lock button (5) is depressed. And if the rear trigger (7) is depressed, the head lock button (5) will be disabled.
-
Page 24: Switching On/Off
Switching on/off Ensure the battery pack is assembled on the battery docking port (8). Remove the blade cover (9) from the blade (1). Ensure the blade (1) does not come into contact with anything before starting the product. Squeeze and hold the front trigger (3) with one hand. Press and hold the rear trigger (3) with the other hand. -
Page 25: Operation
EN Operation Trimming NOTE: While trimming, the cutting device is possible to be blocked. So the product will turn off automatically due to over current. Therefore release the on/off switch and then press down again to go on with trimming. WARNING! Clear the area to be cut before each use. -
Page 26: Operating Hours
After cutting the sides proceed to the top. Try to keep the cutting device angled at approximately 15° to the cutting surface (Fig. 6). 0-15° 10. Cut in a number of stages if the area being cut is particularly long to achieve a better result;... -
Page 27: Care And Maintenance
EN Care and maintenance The golden rules for care WARNING! Always switch the product off, remove the battery pack and let the product cool down before performing inspection, maintenance and cleaning work! WARNING! Blades are sharp. When handling the blade assembly, wear nonslip, heavy-duty protective gloves. - Page 28 If the upper blades are aligned completely with the lower ones, start the hedge trimmer and then stop it to offset the blades before lubrication. WARNING! This operation must only be performed when the blades have stopped running and the motor is switched off. Repair This product does not contain any parts that can be repaired by the consumer.
-
Page 29: Troubleshooting
Troubleshooting Suspected malfunctions are often due to causes that the users can fix themselves. Therefore check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself! -
Page 30: Recycling And Disposal
Recycling and disposal Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or local store for recycling advice. For further information visit www.recycle-more.co.uk. The product comes in a package that protects it against damage during shipping. Keep the package until you are sure that all parts have been delivered and the product is working properly. -
Page 31: Guarantee
This guarantee is in addition to and does not affect your statutory rights relating to faulty goods as a consumer. Manufacturer: Kingfisher International Products Limited 1 Paddington Square, London, W2 1GG, United Kingdom www.kingfisher.com/products Distributor: B&Q plc Chandlers Ford, Hants, SO53 3LE, United Kingdom www.diy.com... -
Page 32: Availability Of Spare Parts
EN Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the... -
Page 33: Declaration Of Conformity
Nazwa i adres producenta lub jego upoważnionego przedstawiciela: Denumirea și adresa producătorului sau a reprezentantului său autorizat: Nombre y dirección del fabricante o de su representante autorizado: Nome e endereço do fabricante ou do respetivo mandatário: Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands This declaration of conformity is issued under the sole responsibility of the manufacturer. - Page 34 2006/42/EC as amended Machinery Directive 2014/30/EU as amended Directive Electromagnetic compatibility 2000/14/EC as amended Outdoor Noise Directive 2011/65/EU as amended Directive Restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2006/42/CE relative aux machines 2014/30 / UE telle que modifiée Directive Compatibilité électromagnétique Directive 2000/14/CE relative aux émissions sonores extérieures Directive 2011/65/UE relative à...
- Page 35 și deținător al dosarului tehnic/firmante autorizado y titular del expediente tecnico/ signatário autorizado e detentor da ficha técnica Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands...
- Page 36 Product • Cordless Hedge Trimmer • 83011/ERI1024GHT • Serial number 00001-99999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited 1 Paddington Square London W2 1GG United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer.
- Page 38 Manufacturer : EN www.diy.com UK Manufacturer: To view instruction manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom EU Manufacturer: Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands...
