- Page 1 Hedge Trimmer 450W 45cm NMHT450 BX220IM CAUTION: Read the instructions before using the product. No name_MNL_NMHT450_Electric Hedge Trimmer_GB_V3_210918_UK.indd 1 9/22/21 4:31 PM...
-
Page 2: Table Of Contents
Let’s get started These instructions are for your safety. Please read through them thoroughly before use and retain them for future reference. started... Getting Safety information Your product Before you start detail... more Product functions Operation Care and maintenance Troubleshooting Recycling and disposal Guarantee Technical specifications... -
Page 3: Safety Information
NMHT450 Safety information Safety warnings General power tool safety warnings WARNING! Read safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. - Page 4 Safety information NMHT450 Safety warnings 2. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. 3. Do not expose power tools to rain or wet conditions.
- Page 5 NMHT450 Safety information 3. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
- Page 6 Safety information NMHT450 Safety warnings 3. Disconnect the plug from the power source and/ or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
- Page 7 NMHT450 Safety information Service 1. Have your power tools serviced by a qualified repair person using only identical replacement parts. This will ensure that safety of the power tool is maintained. Hedge trimmer safety warnings: 1. Keep all parts of the body away from the blade. Do not remove cut material or hold material to be cut when blades are moving.
- Page 8 Safety information NMHT450 Safety warnings 6. Keep all power cords and cables away from cutting area. Power cords or cables may be hidden in hedges or bushes and can be accidentally cut by the blade. 7. Do not use the hedge trimmer in bad weather conditions, especially when there is a risk of lightning.
- Page 9 NMHT450 Safety information Emergency Familiarise yourself with the use of this product by means of this instruction manual. Memorise the safety directions and follow them to the letter. This will help to prevent risks and hazards. 1. Always be alert when using this product, so that you can recognise and handle risks early.
- Page 10 Safety information NMHT450 Safety warnings WARNING! This product produces electromagnetic field during operation! This field may under some circumstances interfere with active or passive medical implants! To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their...
- Page 11 NMHT450 Safety information Wear protective, slip-resistant footwear. Wear tight-fitted protective clothes. Switch the product off and disconnect it from the power supply before assembly, cleaning, adjustments, maintenance, storage and transportation. Do not expose the product to rain or wet conditions (moisture).
-
Page 12: Your Product
Your product NMHT450 Your product 1. Cutting device 6. Rear handle (blade) 7. On/off switch 2. Front safeguard 8. Rear safeguard 3. Safety switch 9. Cord retainer 4. Front handle 10. Power cord with plug 5. Air vents 11. Blade cover No name_MNL_NMHT450_Electric Hedge Trimmer_GB_V3_210918_UK.indd 12... - Page 13 NMHT450 Before you start Unpacking 1. Unpack all parts and lay them on a flat, stable surface. 2. Remove all packing materials and shipping devices if applicable. 3. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact your dealer.
-
Page 14: Before You Start
Before you start NMHT450 Setup Fig. 1 NOTE: Always attach the blade cover (11) when the product is not in use, for storage and transportation. To attach the blade cover (11), align and push the blade cover onto the cutting device (blade) (1). - Page 15 NMHT450 Before you start Fig. 2 Fig. 3 3. Connect the plug of power cord (10) with a suitable socket. WARNING! Check the voltage! The voltage must comply with the information on the rating label! If using an extension cord it must be suitable for outdoor use with sockets protected against water splashing.
- Page 16 Product functions NMHT450 Intended use This electric hedge trimmer NMHT450 is designated with a rated power input of 450 Watts. The product is intended for cutting and trimming of hedges, bushes and shrubs in domestic gardens. The maximum cutting capacity must be observed. Do not cut branches exceeding the stated maximum capacity.
-
Page 17: Product Functions
NMHT450 Product functions General operation 1. Check the product, its power cord and plug as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. 2. Double check that the accessories and attachments are properly fixed. - Page 18 Operation NMHT450 Trimming 5. First cutting both sides from the bottom upwards to the top. This will prevent any of the cuttings falling into the path of the area still to be cut (Fig. 5). 6. After cutting the sides proceed to the top. Try to keep the cutting device angled at approximately 15°...
- Page 19 NMHT450 Operation Trimming WARNING! This operation must only be performed when the blades have stopped running and the product is switched off! Fig. 9 After use 1. Switch the product off, disconnect the product from the power supply and let it cool down.
- Page 20 Operation / Care and maintenance NMHT450 General Cleaning 1. Clean the product with a damp cloth and pH-neutral soap. Use a brush for areas that are hard to reach. 2. In particular clean the air vents (5) after every use with a cloth and brush.
-
Page 21: Care And Maintenance
NMHT450 Care and maintenance UK plug (only for UK market) If you need to replace the fitted plug, then follow the instructions below. IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Blue – Neutral Brown –... -
Page 22: Troubleshooting
Care and maintenance NMHT450 Storage 1. Switch the product off and disconnect it from the power supply. 2. Clean the product as described above. 3. Attach the blade cover (11) onto the cutting device (blade) (1). 4. Store the product and its accessories in a dark, dry, frost-free, well-ventilated place. -
Page 23: Recycling And Disposal
NMHT450 Care and maintenance / Troubleshooting Troubleshooting Problem Possible cause Solution 2. Product does 2.1. Extension cord not 2.1. Use a proper extension not reach full suitable for operation cord power with this product 2.2. Power source 2.2. Connect to another (e.g. -
Page 24: Guarantee
Guarantee related queries should be addressed to the store you purchased this product from. The guarantee is in addition to and does not affect your statutory rights. Manufacturer: Kingfisher International Products Limited 3 Sheldon Square, W26PX London United Kingdom www.kingfisher.com/products No name_MNL_NMHT450_Electric Hedge Trimmer_GB_V3_210918_UK.indd 24... - Page 25 NMHT450 Guarantee Guarantee Distributor: B&Q plc Chandlers Ford, Hants, SO53 3LE, United Kingdom www.diy.com Screwfix Direct Limited Trade House, Mead Avenue, Yeovil, BA22 8RT, United Kingdom www.screwfix.com No name_MNL_NMHT450_Electric Hedge Trimmer_GB_V3_210918_UK.indd 25 9/22/21 4:31 PM...
-
Page 26: Technical Specifications
Guarantee NMHT450 Technical specifications General > Rated voltage, frequency : 230-240 V~,50 Hz > Rated power input : 450 W > Rated no load speed n : 1700 min > Blade length : 45 cm > Max. cutting length : 41 cm >... - Page 27 Proper measures include among others regular maintenance and care of the product and accessories, keeping hands warm, periodical breaks and proper planning of work processes. Rating label explanation Hedge trimmer: NMHT450 NM = Brand name HT = Hedge Trimmer 450 = Rated power (W) No name_MNL_NMHT450_Electric Hedge Trimmer_GB_V3_210918_UK.indd 27...
-
Page 28: Ec Declaration Of Conformity
Type / batch or serial number range 000001 to 999999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited 3 Sheldon Square London W2 6PX United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer. - Page 29 Nazwa i adres producenta lub jego upoważnionego przedstawiciela: Denumirea și adresa producătorului sau a reprezentantului său autorizat: Nombre y dirección del fabricante o de su representante autorizado: Nome e endereço do fabricante ou do respetivo mandatário: Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands This declaration of conformity is issued under the sole responsibility of the manufacturer.
- Page 30 Authorised signatory and technical file holder/signataire et responsable de la documentation technique authorisé/ podmiot uprawniony do wystawienia i adres prezechowywania dokumentacji technicznej/semnatar autorizat și deținător al dosarului tehnic/firmante autorizado y titular del expediente tecnico/ signatário autorizado e detentor da ficha técnica Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam,...
- Page 31 Pour consulter les manuels d’instructions en ligne, www.bricodepot.fr rendez-vous sur le site www.kingfisher.com/products www.castorama.pl Aby zapozna si z instrukcj obs ugi online, odwied stron www.kingfisher.com/products www.bricodepot.es Para consultar los manuales de instrucciones en línea, visite www.kingfisher.com/products www.bricodepot.pt...
