SPECIFICATIONS
Part Number: 118020
Set Up Size: 93"L x 72W x 79"H
Packed Size: 72"L x 40"W x 26"H
W e i g h t: 119 lbs.
Fishable Area: 26 sq.ft
Instructions: 107345
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
IMPORTANT-PLEASE READ:
This product is warranted to the original retail purchaser (from an authorized dealer) and is non-transferable.
Clam Outdoors has a three-year manufacturer's defect warranty from the date of original purchase. Warranty
does not cover cracked or worn bases (if runner kits have not been installed as recommended), cracked
windows, tent tears or cuts, or broken or bent hoops due to high wind weather conditions or unattended use.
Defective parts will be replaced or repaired (at the manufacturer's option) if found to be defective within three
years from the date of original purchase. Warranty will be void if product has been subject to neglect, misuse,
improper installation, misapplication, alteration, accident including but not limited to improper maintenance, or
use of unauthorized parts or attachments. Please read the entire owner's manual to ensure proper installation,
use, storage and care of your Clam Shelter.
To submit a warranty claim request, please use one of the following methods:
https://clamoutdoors.com/pages/warranty-form
▪ Email:
customerservice@clamcorp.com
In your request, please include your full name, address, phone number, a copy of your receipt, a brief description
of the problem, and pictures to clearly show the area(s) of concern. Our Warranty Department will review your
request, and a Clam representative will contact you regarding your claim status. All returns must be shipped to
us postage pre-prepaid.
It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of
warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is
not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss
of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to
use, or the repair or replacement of Clam products. Clam reserves the right to make alterations or
modifications in its products at any time, which in its opinion, may improve the performance and efficiency of
the product. Clam shall not be obligated to make such alterations or modifications to products already in service
Clam contact information
Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
Clam Outdoors
Attn: Customer Service
12135 Brockton Lane
Rogers, MN 55369
Phone: 763-231-4120
FISH TRAP BUILD VIDEO
CLAMOUTDOORS.COM
WARRANTY INFORMATION
** REGISTER YOUR PURCHASE ONLINE AT CLAMOUTDOORS.COM **
LIMITATION OF LIABILITY
MODEL 16675

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICE TEAM VOYAGER THERMAL XT and is the answer not in the manual?

Questions and answers

Summary of Contents for Clam ICE TEAM VOYAGER THERMAL XT

  • Page 1 It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or replacement of Clam products.
  • Page 2: Parts List

    PARTS LIST QTY. PART NO. DESCRIPTION 103883 BASE, JM THERMAL X/VOYAGER 106888 HOOP POLE, VOYAGER XT 106889 EXTENSION HOOP POLE, VOYAGER XT (Green Zip Tie) 106890 HALF HOOP POLE, VOYAGER XT 114271 LARGE DIMMABLE LIGHT STICK 106935 TENT, VOYAGER THERMAL XT ICE TEAM 102506 SEAT RAIL 108829...
  • Page 3 HARDWARE FASTENERS REFERENCE...
  • Page 4: Step 1 - Seat Assembly

    STEP 1 - SEAT ASSEMBLY Parts Needed for Step 1 Part Number Description Quantity 101652 SEAT TUBE 101429 SEAT TUBE PLUG 101048 BLOCK, SLIDE (CIRCLE) 104674 BLOCK, SLIDE (OVAL) 101146 EXTRUSION CHANNEL 105478 SWIVEL, SEAT 102759 DELUXE SEAT 101420 FRONT RETAINER BRACKET 102430 REAR RETAINER...
  • Page 5 D. Rotate Seat Swivel #105478 45 degrees so its star shaped and all slotted holes are accessible. E. Use #106286 bolts and #106284 nuts to secure Extrusion Channels to Swivel. F. Attach swivel assembly to bottom of Deluxe Seat #102759 with #101470 screws and tighten. G.
  • Page 6 H. Installing the Front Retainer #101420 and Rear Retainer #102430 brackets – Line up holes of retainer brackets to seat rail tubes and insert #106456 bolts. NOTE: REAR RETAINER BRACKET CONTAINS THE SEAT LATCH CLIP I. Locate Hammock #101466, which is a fabric accessory included inside the tent bag. J.
  • Page 7 STEP 2 – LIGHT STICK ASSEMBLY DO NOT CUT ANY OF YOUR POLES Parts Needed for Step 2 Part Number Description Quantity 106890 HALF HOOP POLE LIGHT STICK LARGE, 114271 DIMMER LIGHT CORD STORAGE 106410 A. Install Light Stick #114271 into the #106890 Half Hoop Poles to make the light stick hoop assembly.
  • Page 8 STEP 3 – EXTENSION HOOP POLE DO NOT CUT ANY OF YOUR POLES NOTE: The Extension Hoop Pole #106889 is identified with a green zip tie. This pole is also shorter in length than the other hoop poles included with the shelter. Parts Needed for Step 3 Part Number Description...
  • Page 9 Collar tab is placed on inside of tube TIP: Twist the lever on the RPSX Collars 90 degrees to allow for easier installation onto Hoop Pole. D. Attach Extension Support Poles #106896 with the notch of the pole facing inward. Use hardware provided with the Extension Clamps to secure.
  • Page 10: Step 4 - Seat Rail

    E. Clip green zip tie and install RPSX Collars #103605 onto Extension Hoop Pole #106889. F. Install Extension Hoop Pole #106889 onto Extension Support Poles #106896. Extension D. Install completed Extension Hoop Pole assembly onto Hoop Pole #106888. Hoop Pole #106889 Light Stick Hoop Pole...
  • Page 11 A. Line up Rail Support Bracket #102083 with predrilled holes on interior wall of sled. B. Insert #106286 bolt through the top hole and line up bracket so it’s straight. C. Once bracket is straight, insert another bolt into bottom hole and tighten all secure bolts with #106284 nuts.
  • Page 12 STEP 5 – POLE MOUNTING BRACKETS Parts Needed for Step 5 Part Number Description Quantity 106800 MOUNTING BRACKET 106286 SCREW, 1/4-20 X 0.75 106284 NUT, 1/4-20, NYLOCK A. Run #106286 bolts through Mounting Bracket #106800 and predrilled holes. Hand tighten #106284 nuts onto bolts, straighten bracket, then tightly secure.
  • Page 13 STEP 6 – CANOPY SUPPORT POLES NOTE: Ensure that all Canopy Support Poles (#103597 and #103599) have slots facing inward. Parts Needed for Step 6 Part Number Description Quantity 103597 BENT PORCH SUPPORT POLE 103599 STRAIGHT CANOPY SUPPORT POLE 106331 SCREW, 1/4-20 X 2.50 106284 NUT, 1/4-20, NYLOCK...
  • Page 14 STEP 7 – BATTERY BRACKET A. Choose which location you’d prefer to have the battery located (battery not included). Light stick cord will need to be able to reach battery. B. Install Battery Bracket #108829 as shown below. Refer to the installation manual included with the kit for additional information.
  • Page 15 STEP 8 – HOOP POLES Parts Needed for Step 8 Part Number Description Quantity 106888 HOOP POLE 103605 LARGE RPSX COLLAR 107266 ROOF SPREADER POLE 101840 REAR SPREADER POLE EXTENSION HOOP POLE ASSEMBLY A. Put the remaining RPSX Collars #103605 onto the Hoop Poles #106888. B.
  • Page 16 STEP 9 – PUTTING SEATS INTO SHELTER A. Put seat assembly into shelter. Connect the front retaining bracket around the lip of the tub first, then the rear bracket. The rear retaining bracket has the spring latch. USE LATCH TO SECURE SEAT ASSEMBLY STEP 10 –...
  • Page 17 Soaking the U-Channel #102814 in hot water will make it much more pliable and easier to wrap around shelter DETAIL-B 8” Approx. BOTH SIDES DETAIL-A The front Hoop Pole should touch the Remove Spreader floor when the tent is set correctly with Poles while some slack in the front part of the tent installing U-Channel...
  • Page 18: Tips For Use

    NOTE: Pulling behind an ATV or snowmobile may result in premature wear of the base. ▪ In windy conditions it is advised to secure your shelter to the ice using Clam’s Ice Anchor Kit (PN 108064) and Ice Anchor Installation Tool (PN 108348).
  • Page 19: Safety Instructions

    SAFETY INSTRUCTIONS Please fully understand and follow all safety instructions as outlined. Failure to do so could result in severe injury or death. ▪ DO NOT USE OPEN FLAME HEATERS IN YOUR ICE SHELTER. INJURY OR DEATH MAY RESULT FROM FIRE IF TENT FABRIC IS EXPOSED TO OPEN FLAME. THE TENT IS NOT FIREPROOF, BUT THE FABRIC IS TREATED WITH A FIRE RETARDANT THAT MEETS CPAI-84 SPECIFICATIONS.
  • Page 20: Frequently Ask Questions

    FREQUENTLY ASK QUESTIONS Fish Trap FAQ’s Q: Should I install a runner kit/hyfax to the base of my shelter? A: The warranty on our shelters does not cover cracked or worn bases if a runner kit has not been installed. Additionally, bases will wear much quicker without a runner kit installed. Q: The zipper on my shelter freezes up and/or sticks.
  • Page 21 Q: There are cracks on the inside finish of the fabric of my shelter. Is this normal? Can anything be done to fix this? A: It is normal for some of the dark colored coating to come off the inside of the tent, particularity on a non-thermal tent.
