SECOLink PAS8 Series Wiring Manual page 5

Intruder alarm system
Normally closed
contact contact with one
(NC)
PAS8xx or module PAS8xx or module
+AUX COM Z1 COM +AUX COM
12V T1 T2 NC C 12V
Tamper
Detector
Wiring of double zones (PAS816, PAS832 only)
PAS816, PAS832
+AUX COM Z1 COM
300W 1kW
12V T1 T2 NC* C
Tamper
Detector A
* - Detector contact must be NC or NO.
To COM
PAS8xx
+PGM COM Z5 COM
To zone
Terminals of smoke detector
12V NO C
Note: smoke detectors, produced
by different manufacturers,
may have a different terminals
layout. For more information
check detector wiring manual
Detector
from manufacturer.
Normally closed Normally closed
contact with two
resistor resistors
(NC/EOL) (NC/DEOL)
PAS8xx or module
Z1 COM +AUX COM
1kW
T1 T2 NC C 12V
Tamper Tamper
Detector Detector
620W
12V T1 T2 NC* C
Tamper
Detector B
Wiring of 4-wire smoke detector
Smoke detectors can be triggered by dust so in order to
To COM
prevent false alarms it is recommended to make fire alarm
verification. For the verification some system settings must be
active. Below is an example for +PGM:
- "Fire verification" attribute must be assigned to fire zone.
(Zone Z5 used in template as fire zone);
- fire (smoke) detector must be powered by +PGM;
- "Fire Power Supply" definition must be set for +PGM;
- zone selected to be as fire zone must be pointed as trigger
source for +PGM;
- +PGM reset time (pulse length in keypad menu) must be set;
- "Detector settling time" (global time setting) must be set;
To +PGM
- "Fire verification time" (global time setting) must be set;
Operation: In order to check triggered fire detector,
detector's power supply has to be turned OFF and turned ON
again. System turn OFF +PGM for a PGM reset time. When
reset time expires the system turns ON the +PGM again and
waits for detector settling ("detector settling time"). Then
system checks detector
verification time". If fire detector is triggered again it means an
alarm was true.
Wiring of zones
Wiring of single zones
Normally open contact
(NO)
PAS8xx or module
Z1 COM +AUX COM
1kW 1kW
T1 T2 NC C 12V T1 T2
Tamper
Detector
PAS816, PAS832
Detector B
Detector A
Wiring samples
again by period equal to "Fire
Control Panels PAS8xx
Normally open contact
with one resistor
(NO/EOL)
PAS8xx or module
Z1 COM +AUX COM Z1 COM
1kW
NO C 12V T1 T2 NO
Tamper
Detector
ATTENTION! Avoid power supply loops
Correct wiring
Detector
Cable
Detector
Cable
PAS8xx
Wrong wiring
Detector
Cable
Detector
Cable
PAS8xx
PAS8xx or module
+PGM COM
D1
Relay
NC NO
It is recommended to use
supress voltage surges on relay.
Wiring manual
Normally open contact
with two resistors
(NO/DEOL)
PAS8xx or module
+AUX COM Z1 COM
1kW 1kW
C 12V T1 T2 NO C
Tamper
Detector
Detector
Cable
EXM800
Detector
EXM800
Wiring of relays
PAS8xx or module
+AUX -PGM
D1
Relay
NC NO
diode to
Page 5
