Harper Extendable Dining Table
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Stock # PW1425004710037
# PW1425004710075
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenstyle.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2024-10-11
LOT NUMBER:
DATE PURCHASED:
Rev. 0001-A
/
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the The Pioneer Woman Harper PW1425004710037 and is the answer not in the manual?

Questions and answers

Related Manuals for Whalen The Pioneer Woman Harper PW1425004710037

Summary of Contents for Whalen The Pioneer Woman Harper PW1425004710037

  • Page 1 LOT NUMBER: DATE PURCHASED: Harper Extendable Dining Table Stock # PW1425004710037 # PW1425004710075 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
  • Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S 1. Maximum load weight 181.4 kg (400 pounds). THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM WEIGHTS INDICATED.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Table Top (Qty. 1) B- Table Leaf C- Leg (Qty. 1) (Qty. 4) (1) 5/16” x 70 mm Bolt (2) Lock Washer (Qty.
  • Page 4 Assembly Instructions ② x 8 ③ x 8 ① x 8 DO NOT fully tighten the bolts initially until all the bolts are ready to assemble. To avoid causing damages to the thread, DO NOT over-tighten the bolts. 1. Unpack the unit and confirm that you have all the hardware and required parts listed. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch.
  • Page 5 Assembly Instructions Hold by the table top. Table top. DO NOT hold the DO NOT lean the table by the legs. table by the legs. Turn over table like this. Floor Leveler 4. With the help of another adult, hold the Table Top (A) to turn the unit upright and position it at the desired location.
  • Page 6 Assembly Instructions Flip up leaf apron Unlock Ball catch Metal peg Lock 6. To add the Table Leaf (B), unlatch the halves of the Table Top (A) and pull them wide open equally from both ends. 7. Flip up leaf apron and rest the Table Leaf (B) on the top surface of wood sliders carefully. Make sure that the metal pegs and sockets are properly aligned.
  • Page 7 To Store the Leaf Extension When Not in Use Flip down leaf apron Unlock Adjust with the screwdriver Metal peg Lock 9. To remove the Table Leaf (B), unlatch it from the Table Top (A). Pull the Table Top (A) wide open equally from both ends to separate the halves of the Table Top (A).

  • Page 8: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
  • Page 9 NÚMERO de LOTE:__________ FECHA de COMPRA: Mesa para comedor entendible Harper Modelo # PW1425004710037 # PW1425004710075 ENSAMBLE REQUERIDO POR ADULTO Si tienen alguna pregunta acerca del ensamble o si alguna parte está faltante, no retorne esté producto a la tienda donde lo compro. Por favor llame a nuestro departamento de ayuda al cliente teniendo su instructivo y lista de partes para proveer el modelo, nombre de parte o el número de fábrica: 1-866-942-5362 Hora estándar del Pacífico: 8:30 a.m.
  • Page 10 M Á X I M O P E S O R E C O M E N D A D O 1. Carga máxima de 181.4 kg (400 libras). ESTA UNIDAD DEBE UTILIZARSE CON LOS PESOS MÁXIMOS INDICADOS. SI SE EXCEDE EL PESO MÁXIMO, PODRIA RESULTAR EN UNA INESTABILIDAD DE LA UNIDAD CAUSANDO POSIBLES LESIONES.
  • Page 11 Lista de partes y material de ferretería Por favor lea completamente las instrucciones y verifique que estén todas las partes y partes de ferretería antes de iniciar el ensamblado A- Tapa de la mesa (Cant. 1) B- Complemento de la mesa C- Pata (Cant.
  • Page 12 Instructivo de ensamble ② x 8 ③ x 8 ① x 8 NO apriete los pernos hasta que todos los pernos estén listos para el ensamble. Para evitar daños a la rosca, NO sobre apriete los pernos. 1. Desempacar la unidad y confirmar que se tiene todo el material de ferretería y partes requeridas. Ensamblar la unidad en un piso alfombrado o en el cartón vacío para evitar rasguños.
  • Page 13 Instructivo de ensamble Mantener por la tapa. Tapa de la mesa. No agarrar la mesa No inclinar la mesa por las patas. por las patas. Voltear la mesa de esta forma. Nivelador de piso 4. Con la ayuda de otro adulto, tomar la tapa de la mesa (A) para poner la unidad en posición vertical y poner cerca del lugar deseado.
  • Page 14 Instructivo de ensamble Levantar el delantal del complemento Desbloquear Retén de bola Clavija de metal Trabar 6. Para agregar el complemento de la mesa (B), desconectar las mitades de la tapa de la mesa (A) y jalarlas aparte de forma nivelada de ambos extremos. 7.
  • Page 15 Para guardar el complemento cuando no está en uso Desbloquear Bajar el delantal del Ajuste con el complemento desarmador Clavija de metal Trabar 9. Para retirar el complemento de la mesa (B), desconectarlo de la tapa de la mesa (A). Jalar la tapa de la mesa (A) hacia afuera igualmente de ambos extremos para separar las mitades de la tapa de la mesa (A).

  • Page 16: Mantenimiento Y Cuidados

    Si esté producto tiene algún defecto de ensamble o material, o si tiene alguna falla en uso normal, nosotros lo repararemos o lo re-emplazaremos hasta por un año a partir de la fecha de compra. Todo producto de Whalen Furniture es diseñado para alcanzar sus expectativas más altas. Nosotros le garantizamos que inmediatamente podrá...
