Or visit our web site 24 hours a day, 7 days a week for product assistance at www.whalenstyle.com Or e-mail your request to parts@whalenfurniture.com THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Whalen Furniture Manufacturing Page 1 Factory No. 16650 Date 2014-11-24 Rev. 1 Factory: GOSHWO...
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
Page 3
(12+1 extra) T-handle Allen Wrench (1) Open-end Wrench (1) Touch-up Pen (1) Tools required: Allen wrench and open-end wrench (provided) and Phillips screwdriver (not provided). 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Manufacturing Page 3 Factory No. 16650...
Page 4
5. Repeat the same procedure to attach one Right Front Leg (D) to the right front corner block of the Seat Frame (B). Be sure the mortise on Right Front Leg (D) fit onto the tenon of the Front Stretcher (G) properly. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Manufacturing Page 4 Factory No. 16650...
Page 5
9. Secure the Seat Frame (B) to the Backrest (A) by inserting two 1-1/2” Bolts (1) with the Washers (4 and 5) into the drilled holes on the rear rail of the Seat Frame. NOTE: DO NOT fully tighten the bolts. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Manufacturing Page 5 Factory No. 16650...
Page 6
12. Stand the assembled unit upright on a flat surface. Press down the Seat Cushion (B) to even all legs. Now, tightly fasten all bolts with the provided Allen wrench. 13. Repeat the same process to assemble the other chair. 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Manufacturing Page 6 Factory No. 16650...
A Touch-up Pen has been provided to repair any small nicks or scratches that may occur during assembly or shipping. We hope you enjoy your purchase for many years. Thank you for your purchase! 1-866-942-5362 Please call for replacement parts or assistance: Whalen Furniture Manufacturing Page 7 Factory No. 16650...
