Item # 1001 888 570
Model # FRS61025T-ST2
Scan for easy 3D instructions
Tap. Zoom. Rotate
USE AND CARE GUIDE
Harrisview Steel Wicker 5pc Sectional Set -
Right Arm Sofa
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this sofa. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
